Welding Transportation Mr. O’Rourke

Welding Transportation Mr. O’Rourke

What is Welding? n. A fabrication process that joins metal. This is done by

What is Welding? n. A fabrication process that joins metal. This is done by melting the work pieces and adding a filler material to form a pool of molten material that cools to become a strong joint.

How Does it Work? n Welding uses an energy source (gas flame, electric arc,

How Does it Work? n Welding uses an energy source (gas flame, electric arc, or laser) to heat and melt metals together. This meting causes impurities in the metal which are shielded by various gases to provide a clean weld.

Types of Welding n Gas Metal Arc Welding (metal inert gas or MIG)-is a

Types of Welding n Gas Metal Arc Welding (metal inert gas or MIG)-is a semi-automatic process that uses a continuous wire feed as an electrode and an inert or semi-inert gas mixture to protect the weld from contamination.

MIG Welder Components n Power Switch n Voltage Adjustment n Wire Speed Adjustment n

MIG Welder Components n Power Switch n Voltage Adjustment n Wire Speed Adjustment n Torch n Ground n Wire Spool n Gas tank

How Do We MIG Weld? n Clean weld surface n Ground out work piece

How Do We MIG Weld? n Clean weld surface n Ground out work piece n Set voltage and wire speed n Squeeze trigger keeping torch tip 1/4 -1/2” from work piece n Move torch tip in small circular, U shaped, or zig-zag motion

MIG Weld Problems n Things to consider: Torch distance, travel speed, voltage setting, wire

MIG Weld Problems n Things to consider: Torch distance, travel speed, voltage setting, wire speed setting, torch motion

Safety n n n Safety Glasses Welding Mask Gloves Long sleeves, pants No open

Safety n n n Safety Glasses Welding Mask Gloves Long sleeves, pants No open toe shoes Ventilation Bright Light!!!- High Heat!!! n Yell Cover Before Beginning Your Weld! n

Benefits of MIG Welding n Can be use on carbon steel, stainless steel, aluminum,

Benefits of MIG Welding n Can be use on carbon steel, stainless steel, aluminum, copper, nickel, bronze and more n All position capabilities n Fairly easy to learn

Disadvantages of MIG n Only for thin to medium thicknesses n Less portable than

Disadvantages of MIG n Only for thin to medium thicknesses n Less portable than other forms due need for gas tank n Sloppier than other forms

Other Forms of Welding n Gas tungsten arc welding (tungsten Inert Gas, TIG) n

Other Forms of Welding n Gas tungsten arc welding (tungsten Inert Gas, TIG) n Shielded metal arc welding (stick, arc) n Oxygen-acetylene
