바코드프린터 사용자매뉴얼 ( Z- 4 M Plus /Z-6 M Plus) Z-4 M Plus Maximum

바코드프린터 사용자매뉴얼 ( Z- 4 M Plus /Z-6 M Plus) Z-4 M Plus Maximum Print Area : Width: 104 mm Resolutions : 203 dpi / 8 dots per mm ( 300 dpi / 12 dots ) Maximum Print Speed : 254 mm / second Physical Characteristics : W×D×H : 278× 475 x 338 mm, Weight : 15 kg Media Specifications : Label and liner width : 25. 4~114 mm Ribbon width : 51 mm to 110 mm Z-6 M Plus Maximum Print Area : Width: 168 mm Resolutions : 203 dpi / 8 dots per mm ( 300 dpi / 12 dots ) Maximum Print Speed : 254 mm / second Physical Characteristics : W×D×H : 341× 475 x 339 mm, Weight : 16 kg Media Specifications : Label and liner width : 51~178 mm Ribbon width : 51 mm to 174 mm IComis TEL: 02)861 -1175 , FAX: 02)861 -1176 http: //www. barcodemart. com

3. Establishing Communication - 이 章에서는 Printer와 Printer 가 설치된 데스크 탑 PC 간의

3. Establishing Communication - 이 章에서는 Printer와 Printer 가 설치된 데스크 탑 PC 간의 통신을 알아 보도록 하겠습니다. • Interface 기본적으로 Parallel port 와 Serial Port 를 장착하고 있습니다. Serial Port 는 RS-232 C/RS-422/RS-485 통신을 할 수 있으며, 옵션인 ‘Zebra. Net Print. Server II’ 를 장착하여 10 Base-T Ethernet Network 를 할 수 있습니다. Printer Network 를 구성하려면 추가적으로 적절한 PC사양이 동반되야 합니다. • Data Specifications Serial Communication Printer 와 PC 가 통신을 하기 위해선 먼저 통신환경이 설정되어야 합니다. 통신 환경은 ‘Baud rate’, ‘Data Bit’, ‘Parity Bit’, ‘Stop Bit’, ‘hand shaking’ 이 선택되어야 합니다. Printer 의 기본 Default 값은 ‘ 9600 Baud rate’, ‘ 7 Data Bit’, ‘Even Parity Bit’, ‘ 1 Stop Bit’, ‘Xon/Xoff’ 입니다. Parallel Communication Printer 와 PC 가 Parallel Cable로 연결되어 있으면 라벨 발행 프로그램에서 Parallel 통신방식으로 변경하십시오.

# 별첨 RS 232/485 Cable 배열 Pin No. Description 1 Chassis Ground 2 TXD

# 별첨 RS 232/485 Cable 배열 Pin No. Description 1 Chassis Ground 2 TXD (RS-232 transmit data) output from printer 3 RXD (RS-232 receive data) input to printer 4 RTS (RS-232 request to send) output from printer 6 DSR (data set ready) input to printer 7 SG (signal ground) for RS-232 9 +5 VDC source output (1 Amp maximum) 11 SGR (signal ground reference) for RS 485 13 Data input A(-) : RS 485 14 Data output A(-) : RS 485 16 Data input B(+) : RS 485 19 Data output B(+) : RS 485 20 DTR (RS-232 data terminal ready) output from printer NOTE : Pins 5, 8, 10, 12, 15, 17 -18, 21 -25 are not used and are unterminated
