Your Winlink Whitelist Created by Ed VE 7

Your Winlink “Whitelist” Created by Ed, VE 7 ED, ver. 1. 0

Whitelist - Internet � For a Winlink Express user to receive a email message, the sender's e-mail address must be listed in the recipient's ”whitelist ” � All Winlink accounts except “tactical callsigns” have this feature to purposely block mail from the internet that is not permitted. � Note: Winlink Whitelist filter can be bypassed, the mail will be delivered even if the email sender is NOT on the recipient's whitelist by adding //WL 2 K at the beginning of the subject line.

Whitelist Access VHF / UHF / HF Radio � � Winlink Express (client) VHF/UHF KPC 3+ or HF SCS TNC connected to your radio You must have radio path to a VHF/UHF RMS Packet (server) or HF RMS Trimode (server) You must have an active Winlink account and password setup.

WHITELIST - Commands SYSTEM: To: SYSTEM@winlink. org Subject: WHITELIST [In the message body, the following commands are available. ] � � LIST: [will return a list of all whitelist entries] ACCEPT: name@somewhere. com (will allow messages from) � name@somewhere. com to be accepted for delivered. � REJECT: name@somewhere. com (will reject any messages from) � name@somewhere. com to be rejected for delivered. � � DELETE: name@somewhere. com (will remove name@somewhere. com from your Whitelist). Note: Accept & Reject commands can have multiple entries at one time Whitelist address without an "@" will be treated as a "domain". If "ACCEPT: domain (eg. rac. ca)" then ALL emails from that domain will be delivered.

Creating the request Create – Post – Send – Wait – then Retrieve

Posting your Whitelist request

Sending your Whitelist request Send via RMS or Internet

Retrieving your Whitelist Retrieve via RMS or Internet

Your Whitelist

Adding to Whitelist Adding a Email to your Whitelist Adding a domain to your Whitelist

Rejecting from Whitelist Rejecting an email address Reject a domain

Delete entry(s) from Whitelist Delete one or multiple email addresses Delete one or multiple domains

Multiple entries Multiples entries can be done all at the same time. Email’s or Domain’s or both Example: Accept: arrl. net Accept: bchydro. com Accept: benninkdoyle@msn. com Reject: john@smith. com Do not use these Domains: @Hotmail. com, @Gmail. com, @Yahoo. com etc.

Whitelist from the Internet Go to www. winlink. org/user Login to your Winlink account Choose – My Whitelist (password required & it is case sensitive) To Add a Email address or domain, Type it on the address line and click “Save” To Edit an address click on the Edit button beside the address. Click on “Edit” on the upper address line and click “Save” To Delete an address, Click on “Delete” beside the address you want to delete. Note: Delete your old addresses

Q & A

Presentations � History � Hardware � Software � Whitelist � Precedence � Node Scripts � Com. Ports � Diagnostics
