XCRF 850 FCW Wiegand Demo XCRF 850 FCW

XC-RF 850 -FCW Wiegand Demo • • • XC-RF 850 FCW with data cable Invengo RFID Demo App v. 1. 3. 4 or later Wiegand Controller Software Wiegand Controller Help 12 V Power Supply (I used MW 97/A-27253)

Links from the previous slide just in case http: //www. invengo. com/rfid-product-line/readers-antennas/rain-rfid-uhf-readers/xcrf 850 -integrated-reader/ http: //www. invengo. support/downloads/FAE/Demo Application and software/RFIDDemo-ver-1. 3. 4. rar https: //www. amazon. com/gp/product/B 00 UX 02 DI 4/ref=oh_aui_detailpage_o 00_s 00? ie= UTF 8&psc=1 http: //www. wiegand. com. cn/soft_all_32/MJ_all_en. rar http: //www. wiegand. com. cn/soft_all_32/help_en. rar

XC-RF 850 -FCW Wiegand Demo • Wiring

Configureing the Invengo RFID Demo App

XC-1003 – reading tags

Slow down the read rate using “Repeatedly acquire tag data filter time period” and configuring Session to “S 1” and Target to “A”.

Enable Wiegand, configure the Port, Mode, Antenna and Pointer can click on [Configure].

Access Control Software • • • Download and unzip MJ_all_en. rar Double click on Access. Control. V 7. 83 en/setup. exe to install the software Go to C: Access. Control and click on N 3000. exe to run the app User Name: abc Password: 123

Access Control Software Click on “ 1. Add Controllers By Searching” When the controller is found (in blue) click on [Add Found To Database] Once it is added, click on [Close]

Access Control Software Click on [Operation], click on the icon representing the door (m 001 -1) then click on Monitoring to begin looking for tag reads.

Start Scanning Click on [Scan] to start reading. Present a tag to the reader.

Success! Tag reads should appear in the box in yellow.
