With FRAMES OF Relative REFERENCE Velocity FRAMES OF
- Slides: 18
With FRAMES OF Relative REFERENCE Velocity
FRAMES OF REFERENCE Coordinate system relative to which motion is described or observed Picture that this is where the camera is observing the motion What is the most common frame of reference? Stationary F. O. R. attached to the Earth or ground We generally use the following symbol to describe the frame of reference:
RELATIVE VELOCITY Velocity of an object relative to a specific frame of reference
DESCRIBING FRAMES OF REFERENCE
EXAMPLES - + What is the relative velocity of: a) Stationary man from his frame of reference? b) Train from his frame of reference? c) Yellow shirt man from stationary man’s FOR? d) Stationary man from Yellow shirt’s FOR? e) Train from yellow shirt’s FOR? f) What if yellow shirt was walking towards the opposite side of the train at 1. 2 m/s?
HOW FAST ARE YOU MOVING? A) Calculate your velocity relative to the FOR attached to your chair? B) Calculate your velocity relative to the FOR at the centre of the Earth? C) Calculate the Earth’s velocity relative to the FOR at the centre of the Sun? D) Calculate the Sun’s velocity relative to the FOR at the centre of the Milky Way Galaxy? You will need values, look them up!
HOW FAST ARE YOU MOVING? Calculate your velocity relative to the centre of the Milky way if: 1) All velocities are in the same direction? 2) Earth’s revolution and rotation are in opposite directions where the revolution is in the same direction as the Sun’s rotation.
WHAT IS THE FRAME OF REFERENCE? http: //www. anyclip. com/movies/the-matrix/arming/ https: //www. youtube. com/watch? v=Y 70 vcs 3 o. V 14
FRAMES OF REFERENCE The video!
ADDING AND SUBTRACTING RELATIVE VELOCITIES
EXAMPLE 1: When seen from the shore, the current of a river is moving 12 m/s [S]. A person in a boat is paddling as fast as they can 4 m/s [W]. What is the resultant velocity of the boat?
EXAMPLE 2: A plane has a velocity relative to the air around it of 35 m/s [N 40 o. E]. The pilot sees a tower and does some calculations to determine the tower is moving at 46 m/s [E 55 o. S]. What will the wind speed at the tower be?
Example # 4: From Town A to Town B are on a straight river. Town B is a 150 km down stream of Town A. A boat travelling with its maximum speed can travel from “A to B” in 5. 0 h. The return trip at maximum speed takes 7. 5 h.
a) What is the speed of the current? b) What is the maximum speed of the boat? c) How long would it take to drift from Town A to Town B?
Practice Question #1: A plane is traveling due North with an airspeed of 200 km/h. There is a 50 km/h wind blowing due east. What is the velocity of the plane relative to the ground?
Practice Question #2: A plane wants to head due North, unfortunately there is a wind blowing due west at 50 km/h. The plane has an air speed of 200 km/h. What should the direction of the plane be flying relative to the air? What is the plane’s velocity relative to the ground?
