Wireless N Exterior Access Point DAP3310 DAP3410 Wireless

Wireless N Exterior Access Point DAP-3310 / DAP-3410 Wireless & Router Product Division/WRPD D-Link HQ, Dec, 2012

• DAP-3310 (2. 4 GHz)/ DAP-3410 (5 GHz) • Two 10/100 Fast Ethernet Port • Proprietary Po. E Design • Po. E Pass Through (up to 7 watt) • High Gain Sector Antenna • Multiple Operation Modes • Advanced Business Features • IP 65 Water/Dust-Proof • Support 15 k. V ESD Protection * Limited warranty (1 year) and no D-Link after service

Pole Mount Grounding LAN 2 LAN 1 (Po. E) Reset

Long distance wireless networking. Ideal solution for WDS and WISP. - High power design to provide better wireless coverage - Wireless speed up to 300 M (2 x 2) - Built-in High Gain Sector Antenna: 10 d. Bi (DAP-3310) /15 d. Bi (DAP-3410) - Weather-proof design (IP 65)1 - Support 15 k. V ESD protection 3 Multiple operation modes. Different mode for different scenario. - Access Point / WDS 2 / WDS with AP 2 / Wireless Client / WISP Client Router / WISP Repeater Total security. Multiple types for different security level. - WPA/WPA 2 -Personal/Enterprise - WEP 64/128 bit Encryption - 802. 1 X 1. 2. 3. IP 65 standard means the device is protected from dust and low pressure jets of water from all directions - limited ingress permitted. Cannot build WDS with current 11 b/g APs and Air. Premier. N series APs. With optional grounding wire

Advanced feature. Supports various function for SMB need. - Multiple SSID (up to 8) in AP mode and 8 VLANs for network segmentation - Wi-Fi WMM - Qo. S (Bandwidth Control) - SNMP v 1/v 2 c/v 3, Web Management (http, https) Firewall feature. Protect your wireless data in SMB. - MAC Address Filter - Wireless LAN Partition - User Limit - DMZ, Virtual Server, Parental Control and IP routing 4 3. DMZ, Virtual Server , Parental Control and IP routing only support in WISP client router and WISP repeater mode.

Po. E Passthrough. A secondary Ethernet port with Po. E output for IP-Camera. Distance X WDS Po. E Output Distance Y Wired Device Switch 4. Only support up to 7 watt IP surveillance, DCS-3716, DCS-6113 and DCS-7110 5. Distance X+ Distance Y 75 meters Switch Internet

Smart wall mount. Three steps installation design, easy and quickly. 1 2 Wall 3 Click! Mounting Tie Screw wall mount 5 on the wall first 5. Wall mount kit is include in package contents

Pt. P communication. Provide different ways for long distance Pt. P link. WDS WISP WDS Office 1 WISP Base Station WDS Office 2 WISP Building

Pt. MP communication. Up to 8 WDS link available for multi-point facilities deployment. WDS (Up to 8) Factory Office Warehouse IP CAM

Repeater Access Point Wireless Client

WDS WISP
