Windows Security Mechanisms Al Bento University of Baltimore

Windows Security Mechanisms Al Bento - University of Baltimore

Authentication • Challenge/response authentication protocol (CHAP) • LAN Manager: saves passwords as hashes: • as a 128 -bit number, with passwords up to 14 digits, but with two 7 digits parts, not case sensitive, easier to break • change possible combinations from 284 to 2 37 • uses old, easy to break DES encryption • saved on SAM (Windows Security Accounts Manager) at %systemroot%system 32configSAM • NTLM and NTLM 2: improved LAN Manager • NTLM -- MD 4 encryption, case sensitive, password up to 127 characters, supports up 56 bit encryption. • NTLM 2 -- improves NTLM to authenticate by session, and supports up to 128 -bit encryption • Kerberos: uses AES encryption and very secure.

Authentication (2) • Defaults • XP by default uses both LM & NTLM • Vista, Windows 7 defaults to NTML 2 • Active Directory defaults to Kerberos, drops back as needed • Security options • See Microsoft long note on options • Many different options: store LAN Manager, Lan Manager authentication level, etc. • Compatibility issues: • example of Windows 7 and Win 2 k server • example of Windows 7 and Win 2003 server • of course all sort of issues with XP, 98, and other settings in NT, 2 K, etc. • More on authentication : a black hat presentation.

Tokens • What are tokens? • A data structure that contains authentication and authorization information for a user. • Windows creates the access token when the user logs on and the user's identity is confirmed. • The access token contains the user's security ID (SID), the list of groups that the user is a member of, and the list of privileges held by that user. • Each process or thread started for the user inherits a copy of the access token. In some cases a user may have more than one access token, with different levels of authority. • What do they do? • Provide the security context for processes and threads when accessing objects in the system • Securable objects include files, directories, devices, registry keys, etc, and have specific user and group permissions. • Some risks: token kidnapping.

Access Control List • What is an ACL? • is a list of access control entries (ACE). Each ACE in an ACL identifies a trustee and specifies the access rights allowed, denied, or audited for that trustee. The security descriptor for a securable object can contain two types of ACLs: a DACL and a SACL. • DACL: discretionary access control list (DACL) identifies the trustees that are allowed or denied access to a securable object. When a process tries to access a securable object, the system checks the ACEs in the object's DACL to determine whether to grant access to it. • SACL: A system access control list (SACL) enables administrators to log attempts to access a secured object. Each ACE specifies the types of access attempts by a specified trustee that cause the system to generate a record in the security event log. • Tokens and ACL • When a user logs in he/she is assigned a access token; and securable objects have ACLs. When an user attempts to access a securable object the Windows security subsystem compare the information in the token access with the securable object and grant or deny access.
