What´s the name of the game? Formal Specification of Artificial Intelligence Games Vladimir O. Di Iorio Eliseu C. Miguel Alcione P. Oliveira Universidade Federal de Viçosa - Brasil Roberto S. Bigonha Mariza A. S. Bigonha Universidade Federal de Minas Gerais - Brasil

Introduction n Abstract State Machines (ASM): q q n n formal method created by Yuri Gurevich (1994); specification of algorithms at its natural level of abstraction. Artificial Intelligence (AI) games: interesting tool for teaching artificial intelligence techniques. This work presents a framework for the specification of AI games using ASM.

Games and Artificial Intelligence n Agents: q q n perceive the environment through sensors; execute actions upon the environment. Multi-agent games: q q agents interact following predefined rules (the rules of the game); agents are usually called bots.

Extensible Artificial Intelligence n n n Games with extensible AI: it is possible for the user to define the behaviour of bots. Competitors are supposed to write the best code for a bot, to fight against other bots. Examples: q q q Half-life (bot kit using C++); AI Wars (proprietary language); Gamebots (bots defined with Java, using the game Unreal Tournament).

Snapshot of Gamebots

A General Multi-Agent AI Game

A General Multi-Agent AI Game A, B, C : internal bots

A General Multi-Agent AI Game E, F : user bots

A General Multi-Agent AI Game D : internal bot that produces visualization

Framework for AI Games using ASM n Definition of new games: q q n Definition of user bots: q q n description of the rules using ASM; advantage: clear semantics of the rules. using ASM itself; or using C++. Graphical representation with animation: using free graphical library Clanlib.

Example - the Snake Game n n n Snakes grow one cell when they "eat" a "vitamin". Snakes shrink when other snakes "eat" their tail. Goal: grow up to N cells.

The Snake Game using the Framework n Definition of the rules of the game: q q n n write an ASM specification for the rules (how snakes move, when snakes grow and shrink); the specification must prevent user bots from "cheating" (snakes must follow the rules for movement). Definition of the behaviour of user bots: write code to move the snakes (in ASM or C++). Define graphical representation using Clanlib.

The Snake Game using the Framework A C B D user bots: Y R B Output Device

Abstract State Machines n n States are represented by functions over a superuniverse; An execution is a sequence of states. Each state is produced by the application of transition rules over the previous state. Main transition rules: q q q function update conditional rule block rule

Example - State represented by functions size : : Color Int size (yellow) = 4 size (red) = 5 size (blue) = 3 cell : : (Color X Int) (Int X Int) cell (yellow, 1) = (9, 3) cell (yellow, 2) = (8, 3) cell (yellow, 3) = (7, 3) cell (yellow, 4) = (7, 2) cell (red, 1) = (12, 9). . .

ASM Rules n Update rule: q Sintax: function (list_expr) : = expr q Semantics: n n q the function is updated at the location defined by the value of the expressions; the change is visible only in the next step of the exectution. Example: size(yellow) : = size(yellow) + 1

ASM Rules n Conditional rule: q Sintax: if condition then R 1 else R 2 q Semantics: n q if the condition is evaluated to True, rule R 1 is fired; otherwise, rule R 2 is fired. Example: if size(yellow) < max then size(yellow) : = size(yellow) + 1 else. . .

ASM Rules n Block Rule: q Sintax: R 1, R 2, . . . , Rk q Semantics: n q The rules R 1, . . . , Rk are fired in paralel. Example: a : = b, b : = a exchange values of a and b

ASM Rules n Other Rules (rules with variables): q q forall rule; choose rule; let rule; etc.

Machina - an ASM-Based Language n n n Machina: language based in ASM, developed in the PL Lab. , DCC/UFMG. Semantics follows main ASM definitions. Includes primitives for definition of: q q n modules (separated definitions); visibility of objetcs. A compiler from Machina to C++ is available.

Machina - Modules n n In Machina, a module is the main syntax unit. Definitions inside a module: q q q n ASM functions; transition rules; visibility of the functions. To actually execute ASM code, it is necessary to instantiate an agent using a module definition.

Example: Transition Rule for Snake Game let p = new. Position(get. Head(self), get. Direction(self)) in if inside. Limits(p) then try. Move. To(p) else shrink(self) end

Example: Transition Rule for Snake Game let p = new. Position(get. Head(self), get. Direction(self)); in if inside. Limits(p) then try. Move. To(p) else shrink(self) end self is always interpreted as end a reference to the current agent

Example: Transition Rule for Snake Game let p = new. Position(get. Head(self), get. Direction(self)); in if inside. Limits(p) then try. Move. To(p) else The snake tries to move to the direction shrink(self) specified by function get. Direction. end This function will be updated end by each snake bot.

Example: Transition Rule for Snake Game let p = new. Position(get. Head(self), get. Direction(self)); in if inside. Limits(p) then try. Move. To(p) else shrink(self) end actions are abstractions for ASM rules

Example: Action try. Move. To (p) : = if p = vitamin. Pos then grow. To. Position(self, p), def. New. Vitamin. Pos elseif is. Free. Of. Snakes(p) then move. To. Position(self, p) elseif is. Snake. Tail(p) then forall s in set. Of. Snakes do if get. Tail(s) = p then shrink(s) end, grow. To. Position(self, p) else shrink(self) end;

Controlling Concurrent Execution A C B D user bots: Y R B Output Device

Controlling Concurrent Execution A C B • Y, R, B can execute at any time; • A, B, C cannot execute in parallel; • A, B, C should execute "fairly"; • D should be executed after each execution of A, B or C. D user bots: Y R B Output Device

Controlling Concurrent Execution A C B • Y, R, B can execute at any time; • A, B, C cannot execute in parallel; • A, B, C should execute "fairly"; • D should be executed after each execution of A, B or C. D user bots: Y R B Output Device Everything can be specified by ASM rules!

Conclusions n n n Simple AI games developed with our framework have been used in AI classes for undergraduate students. In general, students have considered the rules of the games very easy to understand thanks to the use of the ASM model. The students have extra motivation to learn AI techniques, in order to win the bot competitions.

Future Work n n Develop more sophisticated games; e. g. : virtual versions of sport games as soccer. Develop 3 D games with animated graphic visualization.
