We protect what you care Surge Protection is

We protect what you care !

Surge Protection is important 电路保护是非常重要的 What is Surge Protection? 什么是电路保护？ Why is it Important? 为什么如此重要？ Protection of circuits and components from electronically harmful occurrences in order to enhance the safety and reliability of electronic and electrical systems and products. 为提高电子和电能系统以及产品的安全 性和可靠性，避免电子伤害的发生，而 对电路和元器件的保护。 Surge Protection helps ensures performance. Surge Protection helps ensure customer satisfaction and reduces costs service and repairs. 电路保护帮助确保性能可靠。电路 保护帮助确保客户满意和减少客服 和维修成本。

Worldwide Operation 迈向国际的君耀电子 Brightking （Shenzhen) Co. , Ltd（Head quarter) Brightking Group(Founded: 2001) 2001年创立君耀电子（深圳）有限公司（总部） Paid-in capital: RMB 20 Million 资本额： 2000万人民币 Employee: 830 persons 雇员： 830人 Location: Shenzhen, Guangdong 地址：广东省深圳市 Factory size: 15000 M² 厂房面积： 15000平方米 USA Brightking (Founded: 2009) 2009年美国君耀成立

Offices and Manufacturing Sites 办公及 厂地址 1996 Brightking (Taiwan) Inc. established； 1996 创立于是台湾新竹； 2001 Brightking (Shenzhen) Co. , Ltd founded(Head quarter)； 2001 君耀电子（深圳）有限公司成立； 2002 Brightking (Shanghai ) Co. , Ltd founded； 2002 君耀电子（上海）有限公司成立； 2004 Brightking (Beijing ) Co. , Ltd founded； 2004 君耀电子（北京）有限公司成立； 2005 Brightking Enterprise (H. K) Co. , Ltd founded. 2005 君耀电子（香港）有限公司成立； 2007 Best. Bright factory founded； 2007 百圳君耀（深圳）电子有限公司成立； 2007 fully managed Lien Shun Electronics； 2007 控股联顺电子（惠州）有限公司。 Manufacturing Sites 厂地址

Group company organization 组织架构 Brightking(Shenzhen) Head Quarter Admin. Domestic Sales Divisions Oversea Sales Divisions Production Divisions R&D QA Shenzhen office Shenzhen , China (staff: 57 ) Hobia, Sol-Tek Seoul, Korea (Agent： 15) Best. Bright Shen. Zhen, China ESD, TVS, SPG, GDT Affiliated to BBE (Staff: 11) QA BBE: staff 6 ZOV: staff 7 Shanghai office Shanghai , China (staff : 48) Shreeji Semi. Bombay, India (Agent，staff : 17) MOV, TMOV Affiliated to ZOV (staff: 12) QC BBE: staff 16 ZOV: staff 17 Beijing office Beijing, China (staff: 33) Croma Sao Paulo, Brasil (Staff : 16 ) Taiwan Branch Taipei, Taiwan (staff: 2) US. Branch California, USA (Staff : 2 ) (MOV, TVS, SPG, GDT) (staff: 372 ) Lien Shun Huizhou , China (MOV, TMOV) (staff: 232) Surge Lab. Affiliated to BBE (staff: 4)

Financial and Operating Highlights 财务及运营数据 Financial Highlights 财务数据: Operating Highlights 运营数据: Total Revenue 销售额 Users 客户数 50% 21% 27% 19% 25% 18% 15% 16% 8% 5%

Main products 主营产品 Capacity 产能数据 Capacity Main products and capacity Product Capacity TVS/TSS 25/3 KK/m MOV/TMOV 100 KK/m SPG 6 KK/m GDT 10 KK/m ESD 3 KK/m Outsource Section 外包组 Outsource Section Product Section Company name TVS/TSS Plating BANDL international MOV/TMOV None SPG Plating BANDL international None GDT None BANDL international ESD * Manufacture Meicer semiconductor Mosel vitelic Inc

Laboratory Service 实验室服务 Reliability Test 可靠性测试: (1) High Temperature Storage Life(H. T. S. L) 高低温存储 ; (2) Pressure. Cook. Test(P. C. T) 高温蒸煮; (3) High Temperature Reverse Bias 高温反偏; (4) Temperature Cycling(T/C) 温度循环; (5) Solder Resistance(S/R) 可焊性测试. Surge Test 雷击测试: (1) Peak Pulse Current Test（8/20µs & 10/1000µ）通流量测试; (2) 1, 2/50 μs combination wave Test（1. 2/50µs & 8/20µs）组合波测试; (3) Max. Clamping Voltage Test 限制电压测试; (4) Surge test Test 多次冲击测试. Comparison Test 对比测试: (1) IPP Comparison Test ; (2) Vc Comparison Test.

Advantage Technology 技术优势 Metal Oxide Varistor 压敏电阻: (1) Special formula for low voltage and high surge capability products; (2) Excellent stability for high surge capability products; (3) Flexible customized product design. Transient Voltage Suppressor 瞬态抑制二极管: (1) Patented process for low voltage and low leakage; (2) High reliability; (3) Diverse packages and flexible customized design. SPark Gap protector 强效放电管: (1) Special chip built-in technique enables high voltage and current capability; (2) Special MELF package patent is being applied which is good for network system surge protection; Advantage Patent 相关专利 Patent for a kind of semiconductor wafer; Patent for a kind of Ethernet surge protection circuit; Patent for a kind of low voltage TVS wafer process technique; Patent for a kind of surge protection device.

Certifications and Achievements 认证及荣誉 UL & Safety Certificate: (1) UL Witnessed Test Data Program (WTDP) : UL 1449UL 498 A; (2) UL Certifications: MOVTVSGDTTSSSPG; (3) VDE Certifications: MOV; (4) CSA Certifications: MOV; Glory achievements (prize): (1) Pegatron & Unihan Corporation Green Product Management System Certification No. C-QC 4 -C 00410 (2) Awarded 2009 Top 10 famous semiconductor brand of China

Development prospects 发展前景 Close to the market demands 贴近市场需求 Brightking’s Electro. Static Discharge(ESD) Devices protect against the discharge of electrostatic energy using an array of miniature Transient Voltage Suppressors. ESD surges are typically small, so the protection devices consume little power, allowing them to be made very small. They have small bodies with high levels of integration, leading to many protection lines in one package with low capacitance and fast response times. The nature of the devices provides a great deal of flexibility, allowing for a range of configuration options. 君耀的ESD保护元件具有反应速度快(小于0. 5 ns)、导通电压低、体积小、集成度高(能同时实现多条数据线保护)、电容值较低 (可达 0. 3 p. F)等特点，可以满足当今最高速接口应用的需求。 Creative the new blue ocean 创造新的蓝海 We seized the opportunity that silicon valley sought for attending the front-end of the new products ahead of time to cut into the source, and then, made brightking’s components to be custom made to creative the brand-new blue ocean. 在硅谷寻求提前参与新产品前端开发的机会，从源头切入，将君耀的保护元件定制其中，创造新的蓝海。

Development prospects 发展前景 Integrate with world-class company 跟世界一流厂商接轨 Firstly, perfect the system, enhance the control of the products’ quality and the process, laying a good foundation for the steady development of the company. Reconstruct the system of Brightking to be a world-class management company. 第一是完善公司的制度，加强产品质量控制和流程控制，为公司的稳健发展打下长远的基础；做一个系统的改造，把君耀电 子改造成一个世界管理体系的公司。 Secondly, Prepare for appearing on the market, try to get funds advantages from the capital market before 2015. 第二就是做好上市准备，争取在 2015年之前在资本市场上取得一个资金的优势。 Thirdly, speed up the internationalization promoting, to build our branches and channel of distribution on main market worldwide. 第三是加快国际化的运作推广，在全世界比较主要的市场上建立我们的分公司以及销售渠道。

I/O电路保护 — TVS ARRAY

We protect what you care ! Thanks! www. brightking. com
