VideoOverlay System for ALCON Surgical Equipment Dr Jaime

Video-Overlay System for ALCON Surgical Equipment Dr Jaime Zacharias Santiago, Chile Dr Jaime Zacharias

Current Video-Overlay • • Embedded Computer based Old / Bulky System Good Image Quality Preservation Rigid overlay format Dr Jaime Zacharias

Current Video-Overlay Old enough to be replaced ! Dr Jaime Zacharias

Video-Overlay System • • Embedded OR Notebook or PC based +box * Box is slim / lightweight easy to install Excellent Image Quality Preservation Flexible Format (user input / easy SW upgrd) * Can be internal Dr Jaime Zacharias

Video-Overlay System SAMPLE OVERLAY TEMPLATE Dr Jaime Zacharias

New Video-Overlay System • Options of connection to Phaco Machines * • Transparent integration to installed base • Upward compatible with NG Phaco Consoles Dr Jaime Zacharias

New Video-Overlay System CONSIDER. . . • Audio Preamplifier for MIC input or • Built-In Microfone Dr Jaime Zacharias

New Video-Overlay System • • Color coding of Interesting Data Color coding of foot-pedal in position Zero Programmable Time-Out or Logo display Fade In and Fade Out to bypass system Dr Jaime Zacharias

New Video-Overlay System ABOVE VACCUM LIMIT HIGHLIGHTING Dr Jaime Zacharias

New Video-Overlay System Precise phaco power analysis * * requires SW / HW modif. Dr Jaime Zacharias

New Video-Overlay System SINGLE US BURST HIGHLIGHTING Dr Jaime Zacharias

New Video-Overlay System • • Data logging and analysis capabilities Time-out auto-save data w/user confirmation Allows Case / Technique / Surgeon comparisons Logged data with Id and Time-Code: Exact match of logged data with case videotape Dr Jaime Zacharias

REAL SAMPLE CASE: US, VAC, Rate, Mode, Bursts, Foot. Pos Dr Jaime Zacharias

REAL SAMPLE CASE: DATA display and analysis program US BURSTS US PULSES Dr Jaime Zacharias

REAL SAMPLE CASE: Individual Bursts depicted (Allows power calculation) Dr Jaime Zacharias

New Video-Overlay System • • • Connection to Surgical Cases database Export data to MS-Excel for manipulation Analysis and graphic construction Useful in Clinical Research and Education Palette of templates for research projects Dr Jaime Zacharias

New Video-Overlay System • Useful in Clinical Research and Education • Templates for research projects CUSTOM TEMPLATE: Label and US power ONLY ( CAVITATION Research Project. ) Dr Jaime Zacharias

New Video-Overlay System NO OVERLAY VIDEO CAMERA MONITOR VCR PHACO CONSOLE Dr Jaime Zacharias

New Video-Overlay System CURRENT OVERLAY VIDEO CAMERA MONITOR VIDEO-OVERLAY CONSOLE VCR PHACO CONSOLE Dr Jaime Zacharias

New Video-Overlay System NEW OVERLAY VIDEO CAMERA MONITOR Notebook (or PC) VIDEO-OVERLAY CONSOLE VCR PHACO CONSOLE Dr Jaime Zacharias

New Video-Overlay System Options for connection to Console: A: • RS-232 serial link cable 9. 600 baud • ESD protected 15 k. Volts • Optically Isolated 1. 5 k. Volts Dr Jaime Zacharias

New Video-Overlay System Options for SAFE connection to Console: A: • RS-232 serial link cable 9. 600 baud • ESD protected 15 k. Volts • Optically Isolated 1. 5 k. Volts i. e. MAX 1480 B ESD Dr Jaime Zacharias

New Video-Overlay System Options for connection to Console: A: • RS-232 serial link 9. 600 baud • ESD protected 15 k. Volts • Optically Isolated 1. 5 k. Volts Data Wire connecting Surgical Equipment to Video Equipment Dr Jaime Zacharias

New Video-Overlay System NEW OVERLAY VIDEO CAMERA MONITOR PC or Notebook VIDEO-OVERLAY CONSOLE VCR WHAT IF ? . . . PHACO CONSOLE Dr Jaime Zacharias

New Video-Overlay System Options for connection to Console: B: • Infrared Link: Ir. DA or other IR protocol (limited range / line of sight concerns, environment dependant) Dr Jaime Zacharias

New Video-Overlay System Options for connection to Console: C: • Radio wave Serial Transmission: Bluetooth or similar (2. 4 GHz) Wireless network adapter (w. LAN) Dr Jaime Zacharias

New Video-Overlay System Good SOLUTION: D: • Radio wave Serial Transmission: 900 MHz or 2. 4 GHz serial peer to peer module, 9. 600 or 19. 200 baud Dr Jaime Zacharias

New Video-Overlay System Good SOLUTION: • Radio wave Serial Transmission: 900 MHz or 2. 4 GHz serial peer to peer Module 9. 600 or 19. 200 baud ELLIMINATES CABLE MESS Dr Jaime Zacharias

New Video-Overlay System Good SOLUTION: • Radio wave Serial Transmission: 900 MHz or 2. 4 GHz serial peer to peer Module 9. 600 or 19. 200 baud ELLIMINATES CABLE MESS COST EFFECTIVE Dr Jaime Zacharias

New Video-Overlay System • Radio wave Serial Transmission: 900 MHz or 2. 4 GHz serial peer to peer Module 9. 600 or 19. 200 baud ELLIMINATES CABLE MESS COST EFFECTIVE MARKETING ADVANTAGE Dr Jaime Zacharias

New Video-Overlay System NEW OVERLAY VIDEO CAMERA PC or Notebook VIDEO-OVERLAY CONSOLE MONITOR VCR Audio Pre-Amp PHACO CONSOLE MIC Dr Jaime Zacharias

New Video-Overlay System NEW OVERLAY Embedded PC VIDEO CAMERA MONITOR VIDEO-OVERLAY CONSOLE PHACO CONSOLE VCR Audio Pre-Amp MIC Dr Jaime Zacharias

New Video-Overlay System NEW DESIGN Dr Jaime Zacharias

New Video-Overlay System NEW DESIGN Dr Jaime Zacharias

New Video-Overlay System WIRELESS Dr Jaime Zacharias

New Video-Overlay System DATA LOGGING and VIDEO - OVERLAY Dr Jaime Zacharias

New Video-Overlay System Status Signals: easy installation Dr Jaime Zacharias

New Video-Overlay System Case Video with Video-Overlay and Audio Dr Jaime Zacharias

New Video-Overlay System EXTERNAL PC Version (Alternative: Embedded PC) Dr Jaime Zacharias

New Video-Overlay System PROGRAMABLE ( Provider defines degree of customization allowed ) Dr Jaime Zacharias

New Video-Overlay System Attached is a 2 minute “demo” video-tape showing the system in operation (VHS-NTSC with voice ) Thank You ! Dr Jaime Zacharias
