INTRODUCTION PRODUCT DESCRIPTION The separators baffle combined type used for removal wet or liquid

INTRODUCTION PRODUCT DESCRIPTION The separators baffle combined type used for removal wet or liquid in the steam. condensate droplets during normal operation and within the steam flow at start up and cooling down. OPERATION The separators has two stage design, the first stage is baffle plate protected and coalesce by bringing foreign material and wet steam droplets together. the second stage wet steam force penetrated to the hole screen in order all the water droplets to the bottom. the condensate exits the separtor from a volute contoured drain. ADVANTAGE § Prevent equipment damage due to erosion and corrosion § Reduction in process efficiency due to lower heat transfer § Reduce wet steam during saturated flow § Prevent from water hammer defect APPLICATIONS § Steam turbine inlet to protect blade damage due to steam wet particle and pipe scales § Boiler outlet, providing guarantied dry steam § Exhaust steam lines § Steam main line, prevent water hammer in pipe line § Protect foreign material direct contact to equipment § Thermal shock

DIAGRAM HOW TO USE THE DIAGRAM § 10 Bar steam pressure and 1000 Kg/h

DIAGRAM HOW TO USE THE DIAGRAM § 10 Bar steam pressure and 1000 Kg/h flow from A-D and § Extend A-B horizontally § Any separator are intersecting with the A-B line in the blue are will be working efficiently 100% (DN 50) § Flow rate is determined by B-C vertical line (19 m/s) § Pressure loss is established by intersecting A-B line to C-D line (0, 03 Bar) § Separators should be chosen by determining the flow rate line diameter and pressure loss

SELECTION DATA INLET /OUT LET CLASS FLANGE PRESSURE TABLE (bar G) SATURATED TEMP (deg

SELECTION DATA INLET /OUT LET CLASS FLANGE PRESSURE TABLE (bar G) SATURATED TEMP (deg C) Up to SUPERHEAT TEMP (deg C) Up to TEST PRESSURE (bar G) WEIGHT APPROX (Kg) SIZE Ø” & LENGTH BODY THICKNESS (mm) 4” PN 25 20 212, 4 280 30 309 16” x 1200 L 13 4” PN 40 30 233, 9 320 45 309 16” x 1200 L 19 4” ANSI 300 30 233, 9 320 45 314 16” x 1200 L 19 4” ANSI 600 40 250, 4 425 60 320 16” x 1200 L 19 6” PN 25 20 212, 4 280 30 321 16” x 1200 L 13 6” PN 40 30 233, 9 320 45 321 16” x 1200 L 19 6” ANSI 300 30 233, 9 320 45 328 16” x 1200 L 19 6” ANSI 600 40 250, 4 425 60 345 16” x 1200 L 19 8” PN 25 20 212, 4 280 30 337 16” x 1200 L 13 8” PN 40 30 233, 9 320 45 341 16” x 1200 L 19 8” ANSI 300 30 233, 9 320 45 350 16” x 1200 L 19 8” ANSI 600 40 250, 4 425 60 356 16” x 1200 L 19 10” PN 25 20 212, 4 280 30 348 20” x 1200 L 13 10” PN 40 30 233, 9 320 45 399 20” x 1200 L 19 10” ANSI 300 30 233, 9 320 45 407 20” x 1200 L 19 10” ANSI 600 40 250, 4 425 60 455 20” x 1200 L 19 PT. VENTURINDO ENGINEERING Maintenance, Engineering & Contractor Head Office & Work Shop : Jl. By Pass jomin No. 46 Cikampek, Karawang, West - Java Telp. 0264 8385523 Fax. 0264 8385523 Email : Didik. haryadi@venturindo. id engineering@venturindo. id
