Use Kolla for Better Life A real case
Use Kolla for Better Life: A real case study for Kolla Yongsheng Gong gong. yongsheng@99 cloud. net presenting for Weiting Chen weiting. chen@intel. com Jeffrey Zhang zhang. lei. fly@99 cloud. net
AGENDA • Background • Why we use Kolla • How we use Kolla • Kolla’s Future System Technologies & Optimization (STO) 2
BACKGROUND Open. Stack is leading the private cloud solution in the market in recent years. Big data is also growing very fast. Enterprise are looking for a new way to integrate both solutions into the same IT infrastructure. Thru Open. Stack, Big data as a service is on the way to provide an elastic and ease to use solution with unified management. Big Data • Open. Stack Sahara • Open. Stack Kolla • Other Open. Stack Projects System Technologies & Optimization (STO) Cloud 3
Our Focus • • • Develop Big Data-as-a-Service Solutions Contribute to Open Source Projects like Open. Stack. Target for Spark/Hadoop source code development. Focus on Cloud performance tuning. Collaborate with Global ISVs. System Technologies & Optimization (STO) 4
THE MOTIVATION 500+ Servers Software Dev. Large Cluster Scaling Software Version Control Big Data Services Software Testing System Technologies & Optimization (STO) Quick Deploy Cloud Infra. Hardware Maint. 5
WHY USE OPENSTACK KOLLA • Open. Stack helps to resolve multi-tenants problem cross multiple team’s development • Docker helps to cover all the software dependency issue by using container technology. • Kolla use micro service concept to run Open. Stack services, to debug or upgrade services become an easy way. • Quick Open. Stack services deployment with a high availability cloud architecture design. • Open. Stack services maintenance and upgrade. System Technologies & Optimization (STO) 6
Kolla benefits us System Technologies & Optimization (STO) 7
LAB NETWORK TOPOLOGY Gateway(1 Gb) - 10. 239. x. x Other Team’s Servers 172. 16. x. x Public Network(10 Gb) - 10. 0. 0. 1/16 Storage Network(10 Gb) - 30. 0. 0. 1/24 Controller + Network w/ HA Nova Compute x 6 (IVB) Bare Metal for Performance Ceph Open. Stack Cloud Nova Compute x 20 (SNB) Ceph MON Nova Compute x 20 (BDW) Ceph OSD x 7 Spark/Hadoop Master Workers Private Network(10 Gb) - 20. 0. 0. 1/24 Manage Network(1 Gb) - 40. 0. 0. 1/24 System Technologies & Optimization (STO) 8
Use Kolla-ansible for Open. Stack installation 1. Prerequisite on deployment server Docker, Ansible, Open. Stack client libraries, NTP installation, “/etc/hosts” to contain managed nodes, be able to passwordless ssh to manged nodes 2. Prerequisite on managed nodes: Docker 3. Download Docker Open. Stack Images 4. Create Docker Local Registry and Load it with downloaded images 5. Edit “multinode” file in “$/kolla/ansible/inventory” to speficy what nodes are taking what roles 6. Edit “globals. yml” file in “/etc/kolla” to specify or config to-be-installed openstack features 7. Verify your config files: kolla-ansible prechecks -i $multinode_file 8. Start to deploy: kolla-ansible deploy -i $multinode_file System Technologies & Optimization (STO) 9
Miscellaneous • Enable HA via Kolla’s globals. xml config file haproxy, keepalived, cron, …etc will be installed via Kolla • Set up Ceph by using Virtual Storage Manager(VSM) and config Cinder file manually Reference: https: //github. com/01 org/virtual-storage-manager • Set up gateway bridge for public network Edit “l 3_agent. ini” for “external_gateway_bridge = br-ex” • Set up public network via horizon • Use the container - “heka” to check Open. Stack logs System Technologies & Optimization (STO) 10
ISSUES HIGHLIGHT 1. Maria. DB issue during installing Kolla. During deploy, mariadb could be fail to connect and must re-try the deploy command. 2. Upgrade Issues via “kolla-ansible upgrade” command. (Mitaka -> Newton) Ansible must be upgraded to a new version since new version Kolla requires a new version Ansible support. Keep to use the related version of config file for multinode/globals; Use a wrong version config file could get fails during upgrade. 3. Downgrade issue with failed “kolla-ansible upgrade” command. What is the measures when "kolla-ansible upgrade" failed? 4. Recover database if it crashes via “kolla-ansible mariadb_recovery” 5. Check the version of docker and keep all the nodes use the same version. 6. Customize config items of type Multi. Str. Opt & List. Opt System Technologies & Optimization (STO) 11
Kolla’s Future Plan New features in Ocata • More stable • Support more Open. Stack projects Future Plan • Kolla Kubernetes Support • Multi Arch Support • Multi region / Cell deployment • Better CI jobs System Technologies & Optimization (STO) 12
enjoy the life under clear sky System Technologies & Optimization (STO) 13
enjoy the life, with beer, noodle and without computer System Technologies & Optimization (STO) 14
