Comprehensive range of products – u. PVC Systems BOX SASH WINDOWS FLUSH CASEMENT WINDOWS BIFOLD DOORS PATIO DOORS

u. PVC – Classic VS Box Sash Feature Image

u. PVC – Classic VS Box Sash Features § Fully featured ovolo detail § Equal sight lines – run through sash detail § 128 mm deep frame § Deep bottom rail option § Clip on or run through horn option § Georgian bar option

u. PVC – Classic VS Box Sash Colour options § White PVCu § White ash both sides § Cream ash both sides § Golden oak on white & Golden oak both sides § Rosewood on white & Rosewood both sides

u. PVC – Classic VS Box Sash Clip-on horn option Moulding has continuation of interlock Horns are foiled to match woodgrain finishes Extended pivot bar Access hole for removal

u. PVC – Classic VS Box Sash Foiled on white solution

u. PVC – Classic VS Box Sash Ovolo detailing

u. PVC – Classic VS Box Sash options Optional deep bottom rail Standard sash Top sash

u. PVC – Classic VS Box Sash Woolpile groove cover strip VS 15 Woolpile Infill

u. PVC – Classic VS Box Sash Run through horn option

u. PVC – Classic VS Box Sash Georgian bar option Same ovolo shape as main profiles & bead VS 11 (22 mm)

u. PVC – Classic VS Box Sash Cill options Standard Cill (e. g. stone sub cill) VS 02 (150 mm) Extended Cill (new build/casement replacement) VS 14 (210 mm)

u. PVC – Classic VS Box Sash Frame fixing positions Frame Fixing Positions

u. PVC – Classic VS Box Sash Coupler Ovolo Cover Cap SW 58 Aluminium ‘Dog Bone’ Coupler VSR 85 Square Cover Cap SW 55

u. PVC – Classic VS Box Sash Size limits § § Maximum width – 1, 600 mm Maximum height – 3, 000 mm Maximum sash weight – 50 Kg Maximum recommended tilt sash weight – 35 Kg Fire Egress § Minimum width - 872 mm § Minimum height – 1, 300 mm

u. PVC – Classic VS Box Sash Fire egress alternate option § 872 mm min width x 1, 090 – 1, 300 high Inside Outside

u. PVC – Classic VS Box Sash Enhanced security PAS 24 option § Capable of achieving PAS 24 to comply with Document Q of new Building Regulation Document Q for new build applications

u. PVC – Classic VS Box Sash Bay solutions 120° - 160° Variable Post 90° Post Available from windowidgets

u. PVC – Classic VS Box Sash Add-on’s / Packers VS 22 50 mm Frame Packer 20 mm Frame Packer VS 21 10 mm Frame Packer VS 23 2 mm Frame Coupler VS 20

u. PVC – Classic VS Box Sash Summary § Fully featured ovolo detail § Equal sight lines – run through sash detail § 128 mm deep frame § Deep bottom rail option § Clip on or run through horn option § Georgian bar option

u. PVC – Elegance VS Box Sash Feature Image

u. PVC – Elegance VS Box Sash Features § § § § Fully featured ovolo detail Unique KAT Claw Cam Equal sight lines – run through sash detail 146 mm deep frame Deep bottom rail option Clip on or run through horn option Georgian bar option Mayfair – fully mechanical joint option

u. PVC – Elegance VS Box Sash Colour options § White PVCu § White ash both sides § Cream foil both sides (limited availability) § Golden oak both sides (limited availability)

u. PVC – Elegance VS Box Sash Ovolo detailing

u. PVC – Elegance VS Box Sash options Large bottom sash Small top sash Standard Configuration Large/Large Sightlines do not line through Deep bottom rail

u. PVC – Elegance VS Box Sash Clip-on horn option Horns are only available in white finish and are sprayed to suit Extended pivot bar

u. PVC – Elegance VS Box Sash Run through horn option

u. PVC – Elegance VS Box Sash Georgian bar option Bar to sash Bar to Bar

u. PVC – Elegance VS Box Sash Cill options Standard Cill (e. g. stone sub cill) Extended Cill (new build/casement replacement) and also for bay installation where not sat on a stone cill

u. PVC – Elegance VS Box Sash Frame fixing positions Frame Fixing Options Through frame fixing Fixing lugs Other ways Head behind covers and jambs behind travel stops

u. PVC – Elegance VS Box Sash Coupler 2 mm H section PVC Coupler Seal this joint before coupling frames together

u. PVC – Elegance VS Box Sash Size limits

u. PVC – Elegance VS Box Sash Fire egress option Fire Egress § Minimum width - 872 mm § Minimum height – 1080 mm Inside Outside

u. PVC – Elegance VS Box Sash Enhanced security PAS 24 option § Capable of achieving PAS 24 to comply with Document Q of new Building Regulation Document Q for new build applications So what’s different? Cam catches Keeps Tilt latches Security block – top sash Jamb packers - frame Sash spacers Reinforcing specification changes

u. PVC – Elegance VS Box Sash Bay solutions Fixed 90° Post Fixed 135° Post Fixed 120° Post

u. PVC – Elegance VS Box Sash Add-on’s / Packers Because of the depth of the frame 2 add-ons are used one in the front section and one at the back

u. PVC – Elegance VS Box Sash Summary § Fully featured ovolo detail § Equal sight lines – run through sash detail § 146 mm deep frame § Deep bottom rail option § Clip on or run through horn option § Georgian bar option

Mayfair Box Sash Windows

Mayfair Box Sash Windows Features § § § § Mechanically jointed outer frame and sashes Mechanically jointed deep bottom rail White ash grained both sides White glazing spacer bar Grey wool pile Black Glazing Gasket 146 mm front to back frame depth Flush frame and cill features Integral cill Spiral sprung balance mechanism KAT suited sash lifts, ‘hook and claw’ cam locks and ring pulls Fitted with draft excluding woolpile and seals Low emissivity 24 mm double glazed argon filled sealed units Window energy rating of C as standard All frames made to measure Max size w: 1. 6 m h: 3. 0 m

Mayfair Box Sash Windows Colour § White ash grained both sides

Mayfair Box Sash Windows Hardware KAT suited sash lifts, ‘hook and claw’ cam locks and ring pulls in: § White § Antique Gold § Chrome § Satin § Pewter

Mayfair Box Sash Windows Hand crafted § Mechanically jointed outer frame and sashes § Mechanically jointed deep bottom rail

Mayfair Box Sash Windows Vertical section drawing

Mayfair Box Sash Windows Summary § § § § Mechanically jointed outer frame and sashes Mechanically jointed deep bottom rail White ash grained both sides White glazing spacer bar Grey wool pile Black Glazing Gasket 146 mm front to back frame depth Flush frame and cill features Integral cill Spiral sprung balance mechanism KAT suited sash lifts, ‘hook and claw’ cam locks and ring pulls Fitted with draft excluding woolpile and seals Low emissivity 24 mm double glazed argon filled sealed units Window energy rating of C as standard All frames made to measure Max size w: 1. 6 m h: 3. 0 m

Flush Casement Windows Features § § § § Authentic flush finish both internally and externally 72 mm deep frame 1. 0 U-Value 5 colours from stock Dummy sashes always located in fixed lights Achieves PAS 24 10 year guarantee Options: § § Internal or external authentic Georgian bars, available in a traditional Georgian layout or with Single vertical and horizontal bars Bay windows Trickle vents

Flush Casement Windows Colour options § White, Light Cream, French Grey, Balmoral and Agate Grey all in a woodgrain finish § Internally all windows have a White woodgrain finish with a sculptured ovolo mould

Flush Casement Windows Hardware § Period Black Monkey Tail with dummy stay § White, Black, Gold, Chrome or Satin espag locking handles

Flush Casement Windows Sash Parameters § Top hung casement - Maximum 1200 mm wide x 1350 mm high * § Side hung casement – Maximum 750 mm wide x 1500 mm high * * Based on a 28 mm double glazing unit with 2 leaves of 4 mm glass.

Flush Casement Windows Glass Specification and Weathering § Outstanding Energy Efficiency 1. 0 U-Value double glazed, dependant on the glass centre pane value.

Flush Casement Windows Summary § § § § Authentic flush finish both internally and externally 72 mm deep frame 1. 0 U-Value 5 colours from stock Dummy sashes always located in fixed lights Achieves PAS 24 10 year guarantee Options: § § Internal or external authentic Georgian bars, available in a traditional Georgian layout or with Single vertical and horizontal bars Bay windows Trickle vents

u. PVC Patio Features § § § In line sliding door system 2, 3 or 4 pane options 3 star diamond rated cylinder lock with Kitemark Stainless steel vanguard handles with 10 year guarantee Low threshold & room divider options 6 hook bi directional locking system Shootbolt option on the lock system 8 hook lock on tall doors Chamfered or Ovolo system 28 mm glazing Outer frame can be welded or mechanically jointed Sits on 95/150/180 cills (except low threshold) Options • Hercules Rollers

u. PVC Patio Colour options § White PVCu § White foil § Cream on white & Cream both sides § Golden oak on white & Golden oak both sides § Rosewood on white & Rosewood both sides § Anthracite grey on white § Black on white

u. PVC Patio Furniture colour options § § § Black White Grey Satin Chrome Gold § Vanguard stainless steel handles with 10 year guarantee

u. PVC Patio Door configurations § Two pane § Three pane (standard) § Three pane (dummy mullion) § Four pane

u. PVC Patio Size limits § 2 pane width – min 1600 mm : max 3000 mm § 3 pane width – min 2400 mm : max 4000 mm § 4 pane width – min 3000 mm : max 5000 mm § Height – min 1600 mm : 2400 mm (standard threshold) § Height – min 1600 mm : 2365 mm (low threshold)

u. PVC Patio Mechanical joint option § Mitre cut outer frame – mechanically joint on-site § Allows transportation of large frames in some cases § Aids manoeuvrability on-site

u. PVC Patio Mid-rail option § Mechanically jointed – allows letter plate option § No internal flap

u. PVC Patio detail § Sliding leaf on the inside as standard § Can be mounted on the outside as option

u. PVC Patio Frame edge detail § 70 mm edge detail § Universal coupler & range on ancillaries

u. PVC Patio Threshold Options Part M compliant Cannot be used with a cill Ramp is an optional extra Room divider for internal use only

u. PVC Patio Hardware § 6 hook lock with 1 piece keep § Eurogroove mounted tandem rollers (adjustable) § Stainless steel track § Stainless steel handles 10 year guarantee § 3 star diamond rated cylinder § Hercules roller 160 Kgs per sash (optional)

u. PVC Patio Weather rating § Intended for domestic & sheltered applications – not high rise or exposed locations § BBA weather test results § Air 300 Pascals § Gust 1200 Pascals § Water 100 Pascals

u. PVC Patio Summary § § § § § In line sliding door system 2, 3 or 4 pane options Low threshold & room divider options 6 hook bi directional locking system Shootbolt option on the lock system 8 hook lock on tall doors Chamfered or Ovolo system 28 mm glazing Outer frame can be welded or mechanically jointed Sits on 95/150/180 cills (except low threshold)

u. PVC – Bifold Door Features § § § u. PVC bifold door system From 2 to 7 panels in various configurations Inward or outward opening Low threshold (30 mm) & room divider (15 mm) options Multipoint locking system to master door 3 star diamond security cylinder lock with Kitemark Exclusive to KAT door handles with 10 year guarantee D Handle to intermediate doors Chamfered or Ovolo beads 28 mm glazing Sits on 85/150/180 cills (except low threshold)

u. PVC – Bifold Door Colour options § § § Rosewood on white & Rosewood White PVCu both sides Cream through colour White foil § Irish oak and Irish oak on white Golden oak on white & Golden § Black Ash on white oak both sides § Anthracite grey on white

u. PVC – Bifold Door Furniture colour options Master handles with design exclusive to KAT. Available in white, grey, black, chrome, gold and satin sliver with a stainless steel handle base. All handles carry a 10 year guarantee. D handle - white, black, satin silver and champagne

u. PVC – Bifold Door configurations

u. PVC – Bifold Door Size limits Maximum Minimum Height 2400 mm 1000 mm Overall width 6000 mm 1200 mm Panel width 900 mm 600 mm Weight per panel 80 Kgs

u. PVC – Bifold Door Mechanical joint option § No mechanical joint option § Doors are fabricated and fully assembled § Heavy product so please bear that in mind § Full installation instructions available

u. PVC – Bifold Door Bifold detail

u. PVC – Bifold Door Frame edge detail § 70 mm edge detail § Universal coupler & range on ancillaries

u. PVC – Bifold Door Threshold Options Low threshold is Part M compliant Cannot be used with a cill Single or double ramp is an optional extra – not fully weather rated Room divider for internal use only

u. PVC – Bifold Door Hardware § Millenco Mantis hook lock § Stainless steel track § Rollers designed to take 80 Kgs per sash § Adjustable hinges § 3 star diamond security cylinder lock § Magnetic door catches § Slave leaf has finger bolt lever which drives shoot bolts

u. PVC – Bifold Door Weather rating § Intended for domestic & sheltered applications – not high rise or exposed locations § U Value with standard warm edge unit 1. 2 centre pane would give a indicative U Value of 1. 4 W/m²K° § Test results § Air 600 Pascals § Wind 1200 Pascals § Water 200 Pascals

u. PVC – Bifold Door Summary § § § u. PVC bifold door system Up to 7 panels in various configurations Inward or outward opening Low threshold options Multipoint locking system to master door 3 start diamond security cylinder lock with Kitemark Exclusive to KAT door handles with 10 year guarantee D Handle to intermediate doors Chamfered or Ovolo beads 28 mm glazing 10 year guarantee
