UNITIV Memory Management Logical Physical Address Space Swapping

UNIT–IV: Memory Management • Logical & Physical Address Space • Swapping • Memory Management Techniques • • Contiguous Memory Allocation Non–Contiguous Memory Allocation Paging Segmentation with Paging Virtual Memory Management Demand Paging • Page Replacement Algorithms • Demand Segmentation • Thrashing • Case Studies • Linux • Windows • Exam Questions 1

Logical & Physical Address Space The Concept of a logical address space that is bound to a separate physical address space is central to proper memory management Logical address – generated by the CPU; also referred to as virtual address Physical address – address seen by the memory unit Logical and physical addresses are the same in compile-time and load-time address-binding schemes; logical (virtual) and physical addresses differ in execution-time address-binding scheme 2

Swapping Schematic View 3

Swapping • A process can be swapped temporarily out of memory to a backing store, and then brought back into memory for continued execution • Backing Store – provide direct access to these memory images • Roll out, Roll in – Swapping variant used for priority-based scheduling algorithms; lower-priority process is swapped out so higher-priority process can be loaded and executed • Major part of swap time is transfer time; Total transfer time is directly proportional to the amount of memory swapped • Modified versions of swapping are found on many systems (i. e. , UNIX, Linux, and Windows) • System maintains a ready queue of ready-to-run processes which have memory images on disk 4

Memory Management Techniques • Single Contiguous Memory Management • Partitioned Memory Management • Relocation Partitioned Memory Management • Paged Memory Management • Segmented Memory Management • Demand–Paged Memory Management • Page Replacement Algorithms • Overlay Memory Management 5

Single Contiguous Memory Management • Simplicity • Available memory fully not utilised • Limited Job Size (< Available Memory) 6

Partitioned Memory Management 7

8

Dynamic Storage-Allocation Problem How to satisfy a request of size n from a list of free holes • First-fit: – Allocate the first hole that is big enough • Best-fit: – Allocate the smallest hole that is big enough; must search entire list, unless ordered by size – Produces the smallest leftover hole • Worst-fit: – Allocate the largest hole; must also search entire list – Produces the largest leftover hole First-fit and best-fit better than worst-fit in terms of speed and storage utilization 9

r 1. in memory order: 10 KB, 4 KB, 20 KB, 18 KB, 7 KB, 9 KB, 12 KB, and 15 KB. Which hole is taken for successive segment requests of 12 KB, 10 KB, 9 KB for first fit? Now repeat the question for best fit, and worst fit. Memory First Fit Best Fit Worst Fit 10 KB (Job 2) 10 KB 4 KB 20 KB 4 KB 12 KB (Job 1) 8 KB 18 KB 9 KB (Job 3) 8 KB 18 KB 9 KB 10 KB (Job 2) 8 KB 7 KB 9 KB 12 KB 9 KB (Job 3) 12 KB (Job 1) 15 KB 12 KB 9 KB Job 3) 6 KB 10 10

2. Given memory partitions of 12 KB, 7 KB, 15 KB, 20 KB, 9 KB, 4 KB, 10 KB, and 18 KB (in order), how would each of the first-fit and best-fit algorithms place processes of 10 KB, 12 KB, 6 KB, and 9 KB (in order)? 11

Relocation Partitioned Memory Management Compaction / Burping / Recompaction / Reburping • Periodically combining all free areas in between partitions into one contiguous area. • Move the contents of allocated partitions to become one contiguous. 12

Fragmentation • External Fragmentation – Total memory space exists to satisfy a request, but it is not contiguous • Internal Fragmentation rtly beallocated memory may– difference is memory internal to a partition, but not being used • Reduce external fragmentation by compaction – Shuffle memory contents to place all free memory together in one large block – Compaction is possible only if relocation is dynamic, and is done at execution time – I/O problem • Latch job in memory while it is involved in I/O • Do I/O only into OS buffers 13

Relocation Partitioned Memory Management 14

Paging • Physical address space of a process can be noncontiguous. • Process is allocated physical memory whenever the latter is available • Divide physical memory into fixed-sized blocks called frames (Size is power of 2, between 512 bytes and 8, 192 bytes) • Divide logical memory into blocks of same size called pages • Keep track of all free frames • To run a program of size n pages, need to find n free frames and load program • Set up a page table to translate logical to physical addresses • Internal fragmentation 15

Address Translation Scheme n Address generated by CPU is divided into: l Page number (p) – used as an index into a page table which contains base address of each page in physical memory l Page offset (d) – combined with base address to define the physical memory address that is sent to the memory unit l For given logical address space 2 m and page size 2 n 16

Paging Hardware 17

Paging Model of Logical and Physical Memory 18

Paging Example n=2 and m=4 32 -byte memory and 4 -byte pages 19

Paging (Cont. ) • Calculating internal fragmentation – Page size = 2, 048 bytes – Process size = 72, 766 bytes – 35 pages + 1, 086 bytes – Internal fragmentation of 2, 048 - 1, 086 = 962 bytes – Worst case fragmentation = 1 frame – 1 byte – On average fragmentation = 1 / 2 frame size – So small frame sizes desirable? – But each page table entry takes memory to track – Page sizes growing over time • Solaris supports two page sizes – 8 KB and 4 MB • Process view and physical memory now very different • By implementation process can only access its own memory 20

Segmentation • Program Collection of Segments • Segment Logical Unit • • • Main Program Procedure Function Method Object Local / Global Variables Common Block Stack Symbol Table Arrays 21

User’s View of a Program 22

Logical View of Segmentation 1 4 1 2 3 4 2 3 user space physical memory space 23

Segmentation Architecture • Logical address consists of a two tuple: <segment-number, offset>, • Segment table – maps two-dimensional physical addresses; each table entry has: – base – contains the starting physical address where the segments reside in memory – limit – specifies the length of the segment • Segment-table base register (STBR) points to the segment table’s location in memory • Segment-table length register (STLR) indicates number of segments used by a program; segment number s is legal if s < STLR 24

Segmentation Architecture (Cont. ) • Protection – With each entry in segment table associate: • validation bit = 0 illegal segment • read/write/execute privileges • Protection bits associated with segments; code sharing occurs at segment level • Since segments vary in length, memory allocation is a dynamic storage-allocation problem • A segmentation example is shown in the following diagram 25

Segmentation Hardware 26

Example of Segmentation 27

Virtual Memory – Background • Virtual memory Separation of user logical memory from physical memory. – – Only part of the program needs to be in memory for execution Logical address space can therefore be much larger than physical address space Allows address spaces to be shared by several processes Allows for more efficient process creation • Virtual memory can be implemented via: – Demand paging – Demand segmentation 28

Virtual Memory That is Larger Than Physical Memory 29

Demand Paging • Bring a page into memory only when it is needed – – Less I/O needed Less memory needed Faster response More users • Lazy swapper Never swaps a page into memory unless page will be needed – Swapper that deals with pages is a pager 30

Demand Paging 31

Page Replacement 32

Page Replacement Algorithms • Want lowest page-fault rate • Evaluate algorithm by running it on a particular string of memory references (reference string) and computing the number of page faults on that string 33

Page Replacement Algorithms • First–In First–Out (FIFO) • Optimal • Least Recently Used (LRU) • Second Chance (Clock) 34

FIFO Page Replacement Algorithm Reference String: 7, 0, 1, 2, 0, 3, 0, 4, 2, 3, 0, 3, 2, 1, 2, 0, 1, 7, 0, 1. 35

First-In-First-Out (FIFO) Algorithm • Reference string: 1, 2, 3, 4, 1, 2, 5, 1, 2, 3, 4, 5 • 3 frames (3 pages can be in memory at a time per process) 1 1 4 5 2 2 1 3 3 3 2 4 1 1 5 4 2 2 1 5 3 3 2 4 4 3 9 page faults • 4 frames 10 page faults Belady’s Anomaly: more frames more page faults 36

Optimal Algorithm • Replace page that will not be used for longest period of time • Example: Reference String: 1, 2, 3, 4, 1, 2, 5, 1, 2, 3, 4, 5 4 frames 1 4 2 6 page faults 3 4 5 37

Optimal Page Replacement Reference String: 7, 0, 1, 2, 0, 3, 0, 4, 2, 3, 0, 3, 2, 1, 2, 0, 1, 7, 0, 1. 38

Least Recently Used (LRU) Algorithm • Reference string: 1, 2, 3, 4, 1, 2, 5, 1, 2, 3, 4, 5 • Counter implementation – Every page entry has a counter; every time page is referenced through this entry, copy the clock into the counter – When a page needs to be changed, look at the counters to determine which are to change 1 1 5 2 2 2 3 5 5 4 4 3 39

LRU Page Replacement Reference String: 7, 0, 1, 2, 0, 3, 0, 4, 2, 3, 0, 3, 2, 1, 2, 0, 1, 7, 0, 1. • Stack implementation Keep a stack of page numbers in a double link form: – Page referenced: • Move it to the top • requires 6 pointers to be changed – No search for replacement 40

Second Chance (Clock) Algorithms • Reference bit – With each page associate a bit, initially = 0 – When page is referenced bit set to 1 – Replace the one which is 0 (if one exists) • We do not know the order, however • Second chance – Need reference bit – Clock replacement – If page to be replaced (in clock order) has reference bit = 1 then: • set reference bit 0 • leave page in memory • replace next page (in clock order), subject to same rules 41

Second-Chance (clock) Page-Replacement Algorithm 42

Overlay Memory Management 43

Thrashing • If a process does not have “enough” pages, the page-fault rate is very high. This leads to: – low CPU utilization – operating system thinks that it needs to increase the degree of multiprogramming – another process added to the system • Thrashing A process is busy swapping pages in and out 44

Windows • Uses demand paging with clustering. Clustering brings in pages surrounding the faulting page • Processes are assigned working set minimum and working set maximum • Working set minimum is the minimum number of pages the process is guaranteed to have in memory • A process may be assigned as many pages up to its working set maximum • When the amount of free memory in the system falls below a threshold, automatic working set trimming is performed to restore the amount of free memory • Working set trimming removes pages from processes that have pages in excess of their working set minimum 45

Linux • Linux address translation • Linux uses paging to translate virtual addresses to physical addresses • Linux does not use segmentation� Advantages • More portable since some RISC architectures don’t support segmentation • Hierarchical paging is flexible enough • Intel x 86 processes have segments • Linux tries to avoid using segmentation • Memory management is simpler when all processes use the same segment register values • Using segment registers is not portable to other processors • Linux uses paging 4 k page size • A three-level page table to handle 64 -bit addresses • On x 86 processors • Only a two-level page table is actually used • Paging is supported in hardware • TLB is provided as well 46

Exam Questions 1. Explain briefly about free space management. 2. Explain the paging concept. 3. What is paging? Why paging is used? 4. Explain Paging technique with example. 5. What is fragmentation? Different types of fragmentation. 6. Explain internal fragmentation. 7. Explain briefly about a. fragmentation b. Swapping c. Thrashing 9. Write short notes on Segmentation. 10. What is virtual memory? 47

Exam Questions 11. Briefly explain the implementation of virtual memory. 12. Discuss the issues when a page fault occurs. 13. What are the needs for Page replacement algorithms? Explain any two page replacement algorithms. 14. Write short notes on Page replacement algorithms and its types. 15. Explain the following Page Replacement algorithms. a. LRU Replacement b. FIFO Replacement c. Optimal Replacement d. Second Chance Replacement 48
