UNCLASSIFIED (FOUO) FST-J 20 -72 Joint & Coalition Comms Meeting 15 June 2020 Mr. Brynt “Woody” Query Joint/Partner Nation Training Team (+01) (619)735 -1859 UNCLASSIFIED (FOUO)

UNCLASSIFIED (FOUO) Tele-Con Connection Info • UNCLASSIFIED (FOUO) Conversation • Dial +01(866)707 -3968 & when queried, enter the Participant Code: 196376 • Roll Call: - Sea Training Group (CAN) - 404 Squadron (CAN) - RCN DMOC (CAN) - NSWC-Corona (US Navy) - TTGP: -- N 77 COMMO -- N 7 Tech -- N 3 -- N 7 Jt/Partner Nation Trng Team UNCLASSIFIED (FOUO) 2

UNCLASSIFIED (FOUO) Agenda • Voice Communications • Chat (Same. Time Connect, IRC, Hex Chat, etc. ) • Information Sharing & Knowledge Management (KM) • Other • Follow Up UNCLASSIFIED (FOUO) 3

UNCLASSIFIED (FOUO) Key Question To Consider • What level of information flow is required for participation to be valuable? – Voice Comms – Chat – Information Sharing & Knowledge Management UNCLASSIFIED (FOUO) 4

UNCLASSIFIED (FOUO) Voice Comms • Voice communications between the FVEY partners operating from sim facilities for FST-J 20 -72 (see Notes Section) – Last Known State of Comms: never been done before from TTGP DIS Voice to CP-140 Aurora • Canada: which ships/naval facilities are in play? – What has been tested to date that will be a part of FST-J 20 -72? • NSWC Corona has tested voice • But… there’s more to do (follow on slides – Are the US, Canada, & Australia able to communicate with all using Allied Crypto enabled real/sim radios today? – Does a separate testing venue need to be set up? • If yes, when should that be? UNCLASSIFIED (FOUO) 5

UNCLASSIFIED (FOUO) Chat • Communications (Chat): (see Notes Section) – Have we had a good three-way test between U. S. , Canadian sites, and Australian sites using Same. Time Connect? • TTGP believes it has not been tested – If not, what hurdles have been identified/require further testing? – When can that testing be scheduled? – Is a work-around required to mitigate the chat hurdle that doesn’t involve Same. Time Connect chat? • Hex Chat – replacing MAKO chat (IRC-based) – see next slide UNCLASSIFIED (FOUO) 6

UNCLASSIFIED (FOUO) Hex Chat UNCLASSIFIED (FOUO)

UNCLASSIFIED (FOUO) Information Sharing & KM • Has Collaboration At Sea (CAS)access been gained by Canadian sites? • Can the Canadian teams pull data from CAS exercise sites here at TTGP? At other locations to include AUS Mo. D/RAN/RAAF? • Are Canadian sites capable of posting their own data on CAS and can other countries pull data from Canadian sites? • If no to any of the above, what work-arounds have been identified/proposed? UNCLASSIFIED (FOUO) 7

UNCLASSIFIED (FOUO) Other • DIS Simulation Testing (Mr. Lepard): – All DIS (simulation and voice) traffic flowed well. – There will be the usual enumeration, damage and terrain correlation issues. – Some fidelity limitations; certain interactions either weren't handled by both sides or didn't make it through CAN CDS • Mostly countermeasures and underwater warfare (active sonar or detailed propulsion information) – Relatively recent move to version of NTB (5. 3. 36 I think) so some of the issues will hopefully be easier to solve. • Tactical Datalink (Mr. Lepard): – Most TDL traffic flowed well; however Current (old) CDS doesn’t pass ASW-related trk info (J 5. 4). UNCLASSIFIED (FOUO)

UNCLASSIFIED (FOUO) Other • Tactical Datalink (Mr. Lepard/continued) – In the process of updating to a newer CDS, but • Has not been approved for use yet and timeline unsure. • A number of other issues are supposed to be fixed, may not fix ASW tracks. • VOIP (Mr. Lepard): – Worked well, however limited by only being able to directly dial USN numbers, and not others on the NETTN • JTEN firewall @ JFJ 7(Mr. Lepard): – Takes at least 1 - 3 days to make sure we can exchange all types of traffic. – Positive: VOIP traffic is always allowed through, even outside of exercises, personnel can be reached as necessary. UNCLASSIFIED (FOUO)

UNCLASSIFIED (FOUO) Follow-Up • Create a Program of Actions & Milestones (POA&M) or add to TTGP’s existing exercise POA&M with delivery dates and office of responsibility for each item – Let’s do this NOW if we know what needs to be added and… • Track/Provide update by the process owners at the IPC REDUX and MPC REDUX on those items. UNCLASSIFIED (FOUO) 8

UNCLASSIFIED (FOUO) Q&A Roundtable Discussion • • • Sea Training Group (CAN) 404 Squadron (CAN) RCN DMOC (CAN) NSWC-Corona (US Navy) TTGP: ―N 77 COMMO ― N 7 Tech ―N 3 ― N 7 Joint/Partner Nation Trng Team UNCLASSIFIED (FOUO) 9
