UMBC CMSC 104 – Section 01, Fall 2016 Operating Systems 1

Saw This On Reddit… UMBC CMSC 104, Section 01 - Fall 2016 2

Notes & Announcements � Thursday will be a lab day. Project 1 together. We will do part 1 of If you can’t make it, the project will be posted after class � Next Tuesday we will not have class. …but it’s a great time to do part 2 of Project 1 if you haven’t finished it by then. � Next Monday I will be giving a talk at the Microsoft office in Elkridge (15 minutes from here) from 7 -9 PM Topic: Getting started with Universal Windows Platform development Open to the public. Also, Pizza! More info & registration: aka. ms/uwpdevtalk UMBC CMSC 104, Section 01 - Fall 2016 3

Fractions in Alternate Number Systems A 7. BC 16 10 x 161 160 7 x 160 7 11 x 16 -1 . 6875 12 x 16 -2 . 046875 167. 73437510 UMBC CMSC 104, Section 01 - Fall 2016 4

Operating Systems Overview Topics � What is an Operating System? � Types of Operating Systems � Interacting with an Operating System � Linux Overview � Frequently Used Linux Commands � Emacs UMBC CMSC 104, Section 01 - Fall 2016

What is an Operating System (OS)? UMBC CMSC 104, Section 01 - Fall 2016

What is an Operating System (OS)? � The base software that makes your computer work � Performs many operations, such as: Allows you to communicate with the computer (tell it what to do) Controls access (login) to the computer Keeps track of all processes currently running Has code to do common tasks like writing to disk, displaying a graphic, etc. � At this point, your main concern is how to communicate with the computer using the OS UMBC CMSC 104, Section 01 - Fall 2016

Major Operating Systems �Microsoft Windows �UNIX Variants Apple mac. OS / i. OS ▪ Built on Darwin, a UNIX variant Linux ▪ Chromium ▪ Android UMBC CMSC 104, Section 01 - Fall 2016

Lesser-known Operating Systems �DOS variants MS DOS, PC DOS, Free. DOS Still used often in Point of Sale systems �UNIX variants BSD, AIX, IRIX Mostly for servers � OS/2 � React. OS � Haiku � Temple. OS UMBC CMSC 104, Section 01 - Fall 2016

Interacting with an OS � Typically the user is able to interact directly with the OS using I/O devices Keyboard, Mouse, Touchscreen, Microphone, etc. �Two primary types of OS Interfaces Command Line Interface (CLI) Graphical User Interface (GUI) UMBC CMSC 104, Section 01 - Fall 2016 10

The Command Line Interface � Text-only � Main method of interaction for first PCs � Still frequently used by power users � A fast, efficient way to perform certain tasks � Great for scripting and repeatable tasks Create 10, 000 empty files. 2 minutes via CLI, HOURS via GUI �A favorite for programmers, and our focus for this class No need to complicate things… UMBC CMSC 104, Section 01 - Fall 2016 11

The Graphical User Interface �Text + Graphics �Often uses a mouse or touchscreen Point & Click or Tap & Swipe � More User-friendly Easier for novice users � Provided by nearly all modern OSes, although it is often optional Yes, you can still run Windows, mac. OS, and Linux without a GUI! UMBC CMSC 104, Section 01 - Fall 2016 12

The Shell � The Shell is the part of the OS that you interact with GUI CLI Windows Explorer DOS/Power. Shell mac. OS Aqua BASH, others Linux GNOME, others BASH, others UMBC CMSC 104, Section 01 - Fall 2016 13

Remote Connectivity � One advantage to CLI interfaces is they provide a very low bandwidth way to connect remotely Works great even with a slow or high-latency connection � telnet is a very simple protocol that provides connectivity to the CLI of a remote machine Instead of sending characters and control data to the local computer's screen, send it over a network connection Very simple, but also very insecure -- anyone "listening" can see everything! � Secure Shell (SSH) is like telnet, but with encryption Similar simplicity to telnet, much more secure We will be using SSH for this class UMBC CMSC 104, Section 01 - Fall 2016

Linux 15

A Brief History of Linux � Started in 1991 by Linus Torvalds while he was a student at University of Helsinki � Initially envisioned as a free replacement for MINIX was a minimal UNIX-like OS for PCs targeted at students with freely available source code but expensive licensing terms � Originally not licensed for commercial distribution; later changed to GNU GPL license � Quickly embraced and extended by the community UMBC CMSC 104, Section 01 - Fall 2016

The Origins of Linux From: torv. . . @klaava. Helsinki. FI (Linus Benedict Torvalds) Newsgroups: comp. os. minix Subject: What would you like to see most in minix? Summary: small poll for my new operating system Keywords: 386, preferences Message-ID: <1991 Aug 25. 205708. 9541@klaava. Helsinki. FI> Date: 25 Aug 91 20: 57: 08 GMT Organization: University of Helsinki Lines: 20 Hello everybody out there using minix I'm doing a (free) operating system (just a hobby, won't be big and professional like gnu) for 386(486) AT clones. This has been brewing since april, and is starting to get ready. I'd like any feedback on things people like/dislike in minix, as my OS resembles it somewhat (same physical layout of the file-system (due to practical reasons) among other things). I've currently ported bash(1. 08) and gcc(1. 40), and things seem to work. This implies that I'll get something practical within a few months, and I'd like to know what features most people would want. Any suggestions are welcome, but I won't promise I'll implement them : -) Linus (torv. . . @kruuna. helsinki. fi) PS. Yes - it's free of any minix code, and it has a multi-threaded fs. It is NOT protable (uses 386 task switching etc), and it probably never will support anything other than AT-harddisks, as that's all I have : -(. UMBC CMSC 104, Section 01 - Fall 2016

The UNIX Family Tree UMBC CMSC 104, Section 01 - Fall 2016 18

Linux Today � Powers billions of computers worldwide Every Android & Chromium Device The majority of modern internet servers Many supercomputers and special purpose computers � Still directed by Linus Torvalds Built by contributions from thousands of developers and corporations since 1991 UMBC CMSC 104, Section 01 - Fall 2016 19

Linux on Desktop Computers As of June 2016… 1 UMBC CMSC 104, Section 01 - Fall 2016 2 3 20

Linux on Mobile Devices As of August 2016… 1 UMBC CMSC 104, Section 01 - Fall 2016 2 3 21

Linux on Web Servers As of June 2016… 1 UMBC CMSC 104, Section 01 - Fall 2016 2 22

Why Linux? � Community Linux has a huge academic and business community built around it � Availability Linux (and it’s associated source code) is available for nearly every conceivable platform � Price Because the GNU GPL license specifies that source code must be provided with every distributed copy, Linux is freely available � “Freedom” Anyone can do anything they want with Linux; you’re free to customize it however you want, as long as you make the source code freely available. UMBC CMSC 104, Section 01 - Fall 2016 23

Linux Distributions UMBC CMSC 104, Section 01 - Fall 2016 24

Linux Distributions UMBC CMSC 104, Section 01 - Fall 2016 25

Logging into Linux � On a UMBC Lab PC Launch VMWare Workstation Choose Linux VM & power it on Wait for it to boot Log in at the prompt Launch Terminal � From Home Windows: Pu. TTY, Bash on Ubuntu on Windows ▪ Pu. TTY also available on UMBC Lab PCs mac. OS: Terminal See slides from first class UMBC CMSC 104, Section 01 - Fall 2016 26

Accessing UMBC GL Machines � UMBC provides internet-connected Linux machines for development and general use � Connect via SSH Note to Windows users: Pu. TTY is an SSH client � All projects will be tested and graded here The version of Linux installed in lab machines is NOT guaranteed to be the same as GL � To connect to GL: Open a Terminal window Connect via SSH using the following command ssh userid@linux. gl. umbc. edu UMBC CMSC 104, Section 01 - Fall 2016 27

Accessing GL Machines (con’t) � When you connect the first time via SSH, you may see a prompt asking you to accept a certificate. Type yes. � A warning screen appears before a password prompt. � When you type your password at the prompt, you will not see any characters or cursor movement. This is for your protection. � After a successful login, you will see your last login date and time (if applicable) and the “Message of the Day” (aka motd). UMBC’s motd hasn’t changed in years… UMBC CMSC 104, Section 01 - Fall 2016 28

The Linux Command Prompt � When you log in to the Linux system here, a user prompt will be displayed. It might look like this: linux#[1]% _ � …where # is the number of the Linux server that you have connected to. You may use any of the Linux servers. � The number in the brackets will change as you work. It is the “number” of the command that you are about to type. � If this prompt is not on the screen at any time, you are not in the shell and are not communicating with the OS. UMBC CMSC 104, Section 01 - Fall 2016

Files �A file is a sequence of bytes. �It can be created by a text editor (emacs, nano, etc) a computer program (such as a C program) �It may contain a program, data, a document, or other information. �Files that contain other files are called directories (sometimes called folders). UMBC CMSC 104, Section 01 - Fall 2016

Linux Filenames �Restrictions May not contain certain reserved characters Have a maximum length Are case sensitive ▪ Note: This is NOT the case with Windows! �It is best to stick with filenames that contain letters (uppercase or lowercase), numbers, and the underscore ( _ ) for now. UMBC CMSC 104, Section 01 - Fall 2016

Directories �Directories contain files or other directories called subdirectories. They may also be empty. �Directories are organized in a hierarchical fashion. �They help us to keep our files organized. UMBC CMSC 104, Section 01 - Fall 2016

Directories (con’t) /afs/umbc. edu/users/j/d/jdoe 28 junk recipes pies apple notes cookies peach UMBC CMSC 104, Section 01 - Fall 2016 CMSC 104 choc_chip

Directories (con’t) Directory Structure of jdoe 28 junk recipes pies apple peach cookies choc_chip notes CMSC 104 UMBC CMSC 104, Section 01 - Fall 2016

Directories (con’t) � Your home directory is where you are located when you log in (e. g. , /afs/umbc. edu/users/j/d/jdoe 28). Tip: type cd at the shell prompt (with no arguments) to return to your home directory � The current directory is where you are located at any time while you are using the system. � Files within the same directory must be given unique names. Remember that Linux filenames are case sensitive. Hello. txt and hello. txt are two different files! � Paths allow us to give the same name to different files located in different directories. � Each running program has a current directory and all filenames are implicitly assumed to start with the name of that directory unless they begin with a slash. UMBC CMSC 104, Section 01 - Fall 2016

Subdirectories �Are used for organizing your files �For example, make a subdirectory for CMSC 104 make subdirectories for each project CMSC 104 project 1 project 2 UMBC CMSC 104, Section 01 - Fall 2016 . . . project 8

Moving in the Directory Tree �. (dot) is the current directory. �. . (dot-dot) is the parent directory. �Use the Linux command cd to change directories. �Use dot-dot to move up the tree. �Use the directory name to move down. �Use the complete directory name (path name) to move anywhere. UMBC CMSC 104, Section 01 - Fall 2016

Frequently Used Linux Commands �pwd, ls, cd – Directory Viewing �mkdir, rmdir – Directory Manipulation �cat, more – File Viewing �cp, mv, rm, touch – File Manipulation �clear, man, history , who �ctrl-c, ctrl-z References: �Linux man page �Links from the 104 homepage �Books and the Internet UMBC CMSC 104, Section 01 - Fall 2016

Directory Viewing Commands �cd Change Directory Can change to absolute path (beginning with /) or relative path (beginning without /) �pwd Print Working Directory Displays full path of your current directory �ls List files in directory Use ls –al to get more detailed view UMBC CMSC 104, Section 01 - Fall 2016

Directory Manipulation Commands �mkdir Make Directory Absolute or Relative paths �rmdir Remove Directory Absolute or Relative paths UMBC CMSC 104, Section 01 - Fall 2016

File Viewing Commands �cat Short for concatenate Dumps file contents to terminal �more Displays file on terminal, one page at a time Use Page Up and Page Down, arrow keys, etc. to scroll Press q to quit UMBC CMSC 104, Section 01 - Fall 2016

File Manipulation Commands � cp Copy (cp <source> <destination>) Works with absolute and relative paths � mv Move (mv <source> <destination>) Works with absolute and relative paths Also useful for renaming � rm Remove (aka delete) Works with absolute and relative paths � touch Creates a blank file if one does not exist Updates timestamp on existing file UMBC CMSC 104, Section 01 - Fall 2016

Miscellaneous Commands � clear Clears the terminal screen � man Manual Page Shows you instructions on how to use a command ▪ e. g. man ls � history Shows you commands you have previously run Cycle through your previous commands using the up arrow � who Displays users logged into system and what they are running UMBC CMSC 104, Section 01 - Fall 2016

Wildcard Characters �You will find wildcard characters useful when manipulating files (e. g. , listing or moving them). �The wildcard characters are * and ? �? is used to represent any single character. �* is used to represent 0 or more characters. UMBC CMSC 104, Section 01 - Fall 2016

Text Editors in Linux �Because the command line is text based, there a number of text editors available �Generic nano �Special-purpose emacs / xemacs vi / vim UMBC CMSC 104, Section 01 - Fall 2016 45

Using nano �The nano text editor works like you would expect any standard text editor to. Arrow keys to move around, tabs with tabstops, etc. �Shortcut options (like save and exit) are available at the bottom of the screen. In this context, the ^ character represents the Ctrl button. UMBC CMSC 104, Section 01 - Fall 2016 46

Using emacs �The emacs editor provides a lot more functionality, especially for programming It’s also a lot more complicated… �Emacs also has a GUI frontend. If you’re in the lab and running Linux via VMWare, this should appear. Otherwise the text-only version will appear �Launching emacs with no parameters will display the help screen UMBC CMSC 104, Section 01 - Fall 2016 47

Emacs UMBC CMSC 104, Section 01 - Fall 2016 48

Emacs Shortcuts �Emacs shortcuts typically begin with C- or M C- means Ctrl, then the specified key M- means Meta (aka Escape), then the specified key �You can quit emacs at any time using C-x C-c That’s Ctrl-x then Ctrl-c If you’re working on an unsaved file, you will be prompted to save. �I’ve posted a list of common emacs shortcuts on the class webpage UMBC CMSC 104, Section 01 - Fall 2016 49

What Editor Should I Use? �You can use whatever editor you want for this class. �If you plan on taking more CMSC courses, it may behoove you to learn emacs �A purpose-built editor like emacs makes adhering to the coding standards easier UMBC CMSC 104, Section 01 - Fall 2016 50

Questions? 51
