Ultra-Filtration drinking water community filter suitable for village/school/hospital/hotel/hostel Technorbital Advanced Materials Private Limited Kanpur -Uttar Pradesh India www. technorbital. com Technology developed with Council of Scientific and Industrial Research lab (NCL-National Chemical Laboratory) Pune, India

Ultra-Filtration drinking water Technology q Tech-Jal (Tech-Water) is a drinking water technology developed by Technorbital using a polymeric hollow fiber membrane q Removes dust, dirt, turbidity, Chlorine and odor from the contaminated water q Removes 99. 999% viruses (like Hepatitis A & E, Polio virus) from the raw water q Removes 99. 9999 bacteria (like E-coli) from the raw water q Can operate without electricity q Can operate without gravity also (using manual paddle pump) q The manual paddle pump can suck water from river, pond or any ground water source (suction head-20 ft. , Discharge head-40 ft. ) q Produces up to 2000 liters of drinking water in one hour q. Very easy for operation and maintenance for a layman q Membrane life – up to 3 years (depending on the quality of water) q Zero expense on maintenance q Very easy to clean q UF membrane is with inherent anti-fouling properties q No wastage of water q Retain minerals in drinking water

What is Hollow Fiber Membrane? Hollow fiber held with fingers Hollow Fiber Clean Water Impurities (Virus/Bacteria/Turbidity) Recycle Water Dirty Water Clean Water Hollow Fiber Porous wall

Hollow Fiber Membrane Module Hollow fiber under microscope UF Module Hollow fibers bundle in module Drinking Water Hollow fibers bundle sealing Dirty Water

Ultra-Filtration drinking water unit Pure and safe Drinking Water UF Module Contaminated water coming from over head tank UF Filtration Unit PP/Carbon Pre-filter Filtration by gravity only. No need of electricity Inlet for air backwash by manual air piston pump

Ultra-Filtration drinking water unit UF Module Pure and safe Drinking Water PP/Carbon Pre-filter UF Filtration Unit Manual Paddle Pump for pumping contaminated Water into UF filtration system (in case of no gravity , no electricity) Filtration by manual paddle pump only. No need of electricity Inlet for air backwash by manual air piston pump In case of electricity – the system will work on centrifugal pump

Space Requirement (Closed unit) Height – 1. 4 m Width – 0. 7 m Depth – 0. 6 m All pipe connections: 1 inch diameter

Tech-Jal Portable unit can work with/without gravity – No need of Electricity

Technical Specifications – UF Membrane Parameters Specs Product Name Techno. UF 90 -L*D MWCO 70, 000 Dalton Membrane diameter (ID/OD) 0. 7 ㎜ / 1. 2 ㎜ Water (distilled) flux at 1 ㎏/㎠ 500 Liters/㎡/Hr Max. inlet pressure 7 ㎏/㎠ Operating pressure 0. 2~2. 0 ㎏/㎠ Max. back flushing pressure 2. 0 ㎏/㎠ Max. Operating temperature 50℃ Operating temperature 10~40℃ p. H range 3~12 Membrane Specialty Polyacrylonitile Housing UPVC/PP Potting material Epoxy resin Gasket NBR/Silicon Inlet-Outlet Connections 1 inch L-Length = 40 inches, D- Diameter = 4 inches

Capacities and replacement costs Tech Jal 2000 Sr. No. Filter Type Purpose Average life in Liters of pure water Replacement Cost (Rs) 1 PP Pre-filter To remove suspended impurities ~1, 50, 000 ~ 1000 2 Activated Carbon filter To remove odor, taste and chlorine ~1, 50, 000 ~ 1000 3 Ultra-Filtration Membrane To remove virus, bacteria, cyst and turbidity ~10, 00000 ~75000 Basic Price of the complete unit – Rs. 1, 30, 000 (Ex. Factory Kanpur)

Capacities and replacement costs Tech Jal 2000 Sr. No. Filter Type Purpose Average life in Liters of pure water Replacement Cost ($) 1 PP Pre-filter To remove suspended impurities ~1, 50, 000 ~ 30 2 Activated Carbon filter To remove odor, taste and chlorine ~1, 50, 000 ~ 30 3 Ultra-Filtration Membrane To remove virus, bacteria, cyst and turbidity ~10, 00000 ~1250 Basic Price of the complete unit – $ 2200 (Ex. Factory Kanpur)

Cleaning and Maintenance

UF Membrane Module Flow Schematics Activated Carbon Pre-Filter Raw Water P 1 PP Pre-Filter 1 2 Turbidity Dirt, dust and Suspended solids PP Candle To remove odor/chlorine Virus/ Bacteria 3 0 0 0 0 Drinking Water P 2 4 Reject/Backwash Water Hollow Fiber Under microscope 5 Air Piston Pump

Normal Filtration Protocol 1. Open valve 1, 2 and 4 while keeping valve 3 and 5 closed 2. Let the water flow from valve 4 (reject line) making sure all air is passed out of the system (this process is for the startup only, valve 3 and 5 remain close) 3. Once the water starts flowing with full flow rate from valve 4, close the valve 4 and open valve 3 ( valve 5 remains close) 4. The safe drinking water will start coming out from drinking water line (valve 3). 5. Connect this line to the drinking water taps.

UF Membrane Module Raw Water P 1 PP Pre-Filter 3 Open Activated Carbon Pre-Filter 1 P 2 Closed 4 Reject/Backwash Water Open Schematic of Normal Filtration Protocol Drinking Water 2 Closed 5 Air Piston Pump

UF Membrane Cleaning Protocol 1. Close valve 1, 2 and 3 while keeping valve 4 and 5 open 2. Paddle the air piston pump slowly three times and let the water come out of reject line (valve 4) 3. Repeat step 2 till water stops coming out of reject line (valve 4) 4. Make sure the pressure of the air piston pump does not exceed 2 bar. 5. In case of excessive pressure generation by air piston pump, open valve 3 to release the air pressure 6. After completing the backwashing process, slowly push down the air piston pump paddle (make sure valve 5 and 4 are open while doing this) and lock it in resting position. 7. Close valve 4 and 5 8. UF backwashing is recommended once in a day for the long life of membrane

UF Membrane Module PP Pre-Filter 3 Closed Activated Carbon Pre-Filter P 2 Open P 1 1 Closed 4 Closed 2 Backwash Water Pressurized air Open 5 Air Piston Pump UF Membrane Cleaning Protocol

PP Pre-Filter Washing Protocol 1. Close valve 1 and 2 2. Un-screw the PP pre-filter lower casing using the spanner provided with the system 3. Remove the PP candle from the casing 4. Wash the PP candle manually with clean water to remove the dirt and suspended solids 5. Put back the clean PP candle in the casing and screw the casing tight 6. This activity can be done once in a week (If quality of raw water is good then PP filter can be cleaned once in 15 days)

Disinfection with Hypo Solution 1. Prepare a Hypo solution (20 ml in one liter water) 2. Mix Hypo solution (20 ml+1 lit water) in to the 20 lit water in a drum/bucket 3. Connect the manual paddle pump outlet to the inlet (Valve 1) of the filtration system 4. Make sure all the air is removed from the manual paddle pump inlet and outlet pipe line 5. Deep the suction foot valve of the manual paddle pump into the drum/bucket containing hypo solution water 6. Make sure that the suction pipe of the paddle pump is filled with water 7. Open valves 1, 2 and 4. Keep valve 3 and 5 close 8. Start paddling the paddle pump still water starts coming out of reject line (valve 4) 9. Once water starts coming out of reject line (valve 4), stop paddling the pump and close all the valves (including valve 4) 10. Let the hypo solution in the system for one hour 11. After one hour, flush the hypo solution out by plain water using normal filtration protocol (i. e. , valve 1, 2 and 3 open and valve 4, 5 closed) for 20 minutes 6. This activity is recommended for the startup only. 7. The hypo solution wash is not recommended more than once in a month 8. The repeatability of the Hypo solution wash depends on the physical observation of any fungal/bacterial/algee growth seen in the pre-filter or pipe lines

Precautions for UF Membrane • Always make sure that the UF module is filled with some water. Never let it dry. The dryness may crack the hollow fibers. • For the longer life of UF membrane, it is recommended to have 5 -10% water rejection from the reject line.
