TYPES OF SYRINGES NEEDLES AND I V CANNULA

TYPES OF SYRINGES NEEDLES AND I. V CANNULA Prepared by: IMRAN IQBAL CLINICAL INSTRUCTOR

INTRODUCTION • Injections are among the most common health care procedures • At least 16 billion administered in developing and transitional countries each year. • 95% of injections are administered in curative care • 3% are for immunization, and the rest for other purposes like blood transfusions

COURSE OBJECTIVES • After successfully completing this class you will be able to: • Describe the different types of syringes. • Use different types of needles as per patient’s unique need • Recognize different types of IV cannula and butterfly needles and their usage. •

SYRINGE A tube with a nozzle and piston or bulb for sucking in and ejecting liquid in a thin stream. v Used for cleaning wounds or body cavities. v Fitted with a hollow needle for injecting or withdrawing fluids . v Syringes are frequently used in clinical medicine to administer injections, infuse intravenous therapy into the bloodstream, apply compounds such as glue or lubricant, and draw/measure liquids

SYRINGE • The word 'gauge' rhymes with 'cage' and tells how thick a needle is. • Depending on the needle length you choose, you might also have a choice of gauge. • The higher the gauge, the thinner the needle. • For example, a 31 gauge needle is thinner than a 29 gauge needle.

SYRINGE • .

SYRINGE • Used for: • Medication Administration like insulin • Test dose for antibiotics • Diagnostic test like Mantoux (TB) • For subcutaneous and intradermal injections • Blood sampling ( ABG’s)

SYRINGE • Used for: • Medication Administration like I. M Injections • Blood sampling

SYRINGE • Used for: • Medication Administration like I. M and I. V Injections • Blood sampling

SYRINGE • Used for: • Medication Administration like I. M and I. V Injections • Blood sampling and minor wounds irrigation • Local Anaesthesia

SYRINGE • • Used for: Medication Administration Blood sampling and minor wounds irrigation Large volumes of fluid

SYRINGE • Used for: • Medication Administration (infusions) • Wound irrigation

SYRINGE • Used for: • Gastric Lavage • NG Tube feeding • Wound irrigation • Foley’s catheter irrigation

NEEDLES • • • 26 G × 1⁄2″ (0. 45 × 12 mm) (brown) 25 G × 5⁄8″ (0. 5 × 16 mm) (orange) 22 G × 1 1⁄4″ (0. 7 × 30 mm) (black) 21 G × 1 1⁄2″ (0. 8 × 40 mm) (green) 20 G × 1 1⁄2″ (0. 9 × 40 mm) (yellow) 19 G × 1 1⁄2″ (1. 1 × 40 mm) (cream)

NEEDLES

NEEDLES 23 G Butterfly Needle

NEEDLES 21 G Butterfly Needle

NEEDLES 23 G Butterfly Needle

I. V CANNULA v A device used to draw blood and give treatments, including intravenous fluids, drugs, or blood transfusions. v A thin, flexible tube is inserted into a vein, usually in the back of the hand, the lower part of the arm, or the foot. v A needle is inserted into a vein to draw blood or give fluids.

I. V CANNULA v Select your catheter size based on the patient and the reason for IV therapy. v Catheters are colour coded to allow for easy identification and selection. v Catheters range in size from 14 gauge (the largest) to 24 gauge (for Pediatric patients)

I. V CANNULA YELLOW

I. V CANNULA Used for: § Most infusions in Neonate and Pediatric. § Geriatrics patients § Neonate or Pediatric blood transfusions § Patients with very thin veins § Flow rate is 20 ml/min

I. V CANNULA

I. V CANNULA Used for: § Most infusions in Neonate and Pediatric. § Geriatrics patients § Routine blood transfusions § Adult patients § Flow rate is 36 ml/min

I. V CANNULA PINK

I. V CANNULA Used for: § Most infusions and for diagnostic procedures § Rapid fluid replacement § Routine blood transfusions and routine medications § Patients with trauma § Flow rate is 60 ml/min § Commonly used for adults

I. V CANNULA GREEN

I. V CANNULA Used for: § Most infusions and for diagnostic procedures § Rapid fluid replacement § Routine blood transfusions and routine medications § Patients with trauma and surgery § Flow rate is 90 ml/min § Commonly used for adults

I. V CANNULA GRAY

I. V CANNULA Used for: § Rapid fluid replacement § Rapid blood transfusions § Patients with polytrauma § Flow rate is 180 ml/min § Surgery

I. V CANNULA ORANGE

I. V CANNULA Used for: § Rapid fluid replacement § Rapid blood transfusions § Patients with polytrauma § Flow rate is 240 ml/min § Surgery

SPINAL NEEDLES
