Tractor Safety Operation and Maintenance Tractor Systems Onyango
- Slides: 20
Tractor Safety, Operation, and Maintenance Tractor Systems Onyango. Ngoye@Hotmail. com
Tractor Systems The tractor has many systems that must be properly serviced and maintained to ensure long life and service.
Engine Classifications Internal combustion engines are identified by the number of strokes in the cycle and by the fuel that is used to run them. Common Tractor Classifications: 4 stroke cycle - Petrol - Diesel - LP
Diesel Engine & Petrol Engine
Four Stroke Cycle
Major Systems 1. 2. 3. 4. 5. Lubrication System Electrical System Cooling System Fuel System Ignition System
Air Intake Parts: 1. Pre-Cleaner 2. Air Cleaner 3. Intake Manifold 4. Intake Valve
Exhaust System Parts: 1. Exhaust Valve 2. Exhaust Manifold 3. Muffler 4. Cap
Parts: Lubricating System Full Flow & By-Pass 1. Crankcase Oil Reservoir (Oil Pan) 2. Oil Pump 3. Oil Filter 4. Oil Passages 5. Pressure Regulating Valve Oil goes to: 1. Camshaft Bearings 2. Crankshaft Main Bearings 3. Piston Pin Bearing 4. Valve Tappet Shaft
Parts: Electrical System 1. Battery 2. Ground Cable 3. Key Switch 4. Ammeter 5. Voltage Regulator 6. Starter Solenoid 7. Starter 8. Distributor * Petrol Only 9. Coil 10. Alternator 11. Spark Plug 12. Power Cable
Cooling System Liquid & Air Parts: 1. Radiator 2. Pressure Cap 3. Fan 4. Fan Belt 5. Water Pump 6. Engine Water Jacket 7. Thermostat 8. Connecting Hoses 9. Liquid or Coolant
Fuel Systems n n Gasoline Diesel Liquid Propane (LP) Alternate Fuels
Petrol Fuel System Parts: 1. Fuel Tank 2. Fuel Pump 3. Carburetor 4. Fuel Filter 5. Fuel Lines
Diesel Fuel System Parts: 1. Fuel Tank 2. Fuel Pump 3. Fuel Filters 4. Injection Pump 5. Injection Nozzles
Liquid Propane (L P) Fuel System Parts: 1. Fuel Tank 2. Fuel Strainer 3. Converter 4. Carburetor
Hydraulic System Open & Closed Parts: 1. Reservoir 5. Lines 2. Accumulator or Variable Displacement Pump 6. Fluid 3. Cooler 7. filter 4. Valves
Power Transmission Mechanical & Hydraulic Parts: 1. Clutch Pedal 2. Clutch 3. Shift Controls 4. Transmission 5. Differential 6. Differential Lock Pedal 7. Final Drives 8. Power Take Off (PTO)
