Topics The Problem Attack Scenario Demo Mitigations and

Topics The Problem Attack Scenario Demo Mitigations and Recommendations Next Steps

Aaron Margosis Ahmad Mahdi Ambrose Leung Benjamin Godard Bret Arsenault Brian Fielder Charlie Kaufman Crispin Cowan David Hoyle Dean Wells Eric Leonard Fernando Cima Georgeo Pulikkathara Jason Krolak Joe Bialek John Lambert Jonathan Ness Justin Hendricks Laura A. Robinson Lori Woehler Mark Cartwright Mark Novak Mark Oram Mark Russinovich Mark Simos Matt Thomlinson Michael Howard Michiko Short Mike Reavey Mohamed Rouatbi Nate Morin Patrick Arnold Patrick Jungles Paul Rich Peter Zdebski Roger Grimes Scott Robinson Scott V. Cleave Sean Finnegan Steve Patrick Tim Rains Tony Rice

Ideological Movements Nation States Organized Crime

…They were next spotted in March 2010, after signing on with the stolen password of a network administrator… …The hackers logged on through the company’s remote access system, just like any employee… The virus erased data on three-quarters of Aramco’s corporate PCs — documents, spreadsheets, e-mails, files — replacing all of it with an image of a burning American flag.

Attack activities Lateral movement Description In this activity, the attacker uses the credentials obtained from a compromised computer to gain access to another computer of the same value to the organization Privilege escalation In this activity, the attacker uses the credentials obtained from a compromised computer to gain access to another computer of a higher value to the organization.

Power: Domain Controllers 1. Bad guy targets workstations en masse 2. User running as local admin compromised, Bad guy harvests credentials. 3. Bad guy uses credentials for lateral traversal Data: Servers and Applications Access: Users and Workstations 4. Bad guy acquires domain admin credentials and associated privileges – privilege escalation 5. Bad guy has direct or indirect access to read/write/destroy data and systems in the environment.

The same single sign-on (SSO) mechanism that brings significant benefits to the user experience also increases the risk of a Pt. H attack if an operating system is compromised. Credentials must be stored or cached to allow the operating system to perform actions on behalf of the user to make the system usable.

Location Plaintext passwords (Reversibly encrypted) NT Hash LM Hash TGT Windows logon cached password verifiers Security Accounts Manager (SAM) database - Yes Maybe 1 - - Local Security Authority Subsystem Yes (LSASS) process memory Yes Yes - Active Directory Database Yes Maybe 1 - - The Credential Manager (Cred. Man) Maybe 2 store - - LSA Secrets in the registry Service Accounts, Scheduled Tasks, etc. Computer Account - - - HKLMSecurity - - Yes -

Mitigation Effectiveness Effort required Privilege escalation Lateral movement Mitigation 1: Restrict and protect high privileged domain accounts Excellent Medium √ - Mitigation 2: Restrict and protect local accounts with administrative privileges Excellent Low - √ Mitigation 3: Restrict inbound traffic using the Windows Firewall Excellent Medium - √

Objective How Outcome This mitigation restricts the ability of administrators to inadvertently expose privileged credentials to higher risk computers. • Restrict DA/EA accounts from authenticating to lower trust computers • Provide admins with accounts to perform administrative duties • Assign dedicated workstations for administrative tasks. • Mark privileged accounts as “sensitive and cannot be delegated” • Do not configure services or schedule tasks to use privileged domain accounts on lower trust computers An attacker cannot steal credentials for an account if the credentials are never used on the compromised computer.

Objective How Outcome This mitigation restricts the ability of attackers to use local administrator accounts or their equivalents for lateral movement Pt. H attacks. • Enforce the restrictions available in Windows Vista and newer that prevent local accounts from being used for remote administration. • Explicitly deny network and Remote Desktop logon rights for all administrative local accounts. • Create unique passwords for local accounts with administrative privileges. An attacker who successfully obtains local account credentials from a compromised computer will not be able to use those credentials to perform lateral movement on the organization's network.

Objective How Outcome This mitigation restricts the ability of attackers from initiating lateral movement from a compromised workstation by blocking inbound connections. • Restrict all inbound connections to all workstations except for those with expected traffic originating from trusted sources, such as helpdesk workstations, security compliance scanners and servers. An attacker who successfully obtains any type of account credentials will not be able to connect to other workstations. Note: Whitepaper update recently released with guidance for authorized peer to peer applications

Recommendations Remove standard users from the local administrators group Effectiveness Effort required Privilege escalation Lateral movement Excellent High √ - Limit the number and use of privileged domain accounts Good Medium √ - Configure outbound proxies to deny Internet access to privileged accounts Good Low √ - Ensure administrative accounts do not have email accounts Good Low √ -

More recommendations Effectiveness Effort required Privilege escalation Lateral movement Use remote management tools that do not place reusable credentials on a remote computer’s memory Good Medium √ - Avoid logons to potentially compromised computers Good Low √ √ Update applications and operating systems Partial Medium - - Secure and manage domain controllers Partial Medium - - Remove LM Hashes Partial Low - -

Other mitigation Effectiveness Effort required Privilege escalation Lateral movement Disable NTLM Minimal High - - Smart cards and multifactor authentication Minimal High - - Jump servers Minimal High √ - Rebooting workstations and servers Minimal Low - -

Mitigations and recommendations in the paper are what can be done today (easily).

Whitepaper and Next Steps Ø Read the Whitepaper Mitigating Pass-the-Hash Attacks and other Credential Theft Techniques Next Steps http: //download. microsoft. com/download/7/7/A/77 ABC 5 BD-8320 -41 AF-863 C-6 ECFB 10 CB 4 B 9/Mitigating Pass-the-Hash (Pt. H) Attacks and Other Credential Theft Techniques_English. pdf Ø Spread the Word Ø Questions? Interested in advanced architectures? Ø Mark. Simos [at] Microsoft. com The Pt. H workgroup will continue to investigate mitigations for credential theft and reuse.

Admin Environment Production Domain(s) Power: ü Credential Partitioning ü Hardened Admin Environment ü Hardened Workstations ü Network security ü Accounts and smartcards ü Auto-Patching ü Security Alerting ü Tamper-resistant audit ü Assist with mitigating risks ü Services & Applications ü Lateral Traversal Threats: Internet Domain Controllers IPsec Domain Admins Management and Monitoring Data: Servers and Applications Access: Users and Workstations Red Card Admins Break Glass Account(s)

http: //channel 9. msdn. com/Events/Tech. Ed www. microsoft. com/learning http: //microsoft. com/technet http: //microsoft. com/msdn

Logon type # Authenticators accepted Reusable credentials in LSA session Interactive (a. k. a. , Logon locally) 2 Password, Smartcard, other Yes Network 3 Password, NT Hash, Kerberos ticket Batch 4 Service 5 Password (usually stored as LSA secret) Examples Console logon; RUNAS; Hardware remote control solutions (such as Network KVM or Remote Access / Lights-Out Card in server) IIS Basic Authn (before IIS 6. 0) No (except if delegation NET USE; is enabled, then RPC calls; Kerberos tickets Remote registry; present) IIS integrated Windows authn; SQL Windows authn; Yes Scheduled tasks Yes Windows services

Logon type # Authenticators accepted Reusable credentials Examples in LSA session Network. Cleartext 8 Password Yes IIS Basic Authn (IIS 6. 0 and newer); Windows Power. Shell with Cred. SSP New. Credentials 9 Password Yes RUNAS /NETWORK Password, Smartcard, other Yes Remote Desktop (formerly known as “Terminal Services”) Remote. Interactive 10

Connection method Logon type Log on at console Interactive RUNAS Reusable credentials on destination Comments Includes hardware remote access / lights-out cards and network KVMs. √ Interactive √ RUNAS /NETWORK Remote Desktop (success) Remote Desktop (failure - logon type was denied) New. Credentials Remote. Interactive √ Remote. Interactive - √ Clones current LSA session for local access, but uses new credentials when connecting to network resources. If the remote desktop client is configured to share local devices and resources, those may be compromised as well. By default, if RDP logon fails credentials are only stored very briefly. This may not be the case if the computer is compromised.

Connection method Net use * \SERVER /u: user MMC snap-ins to remote computer Logon type Reusable credentials on destination Comments Network - Network Power. Shell Win. RM with Cred. SSP Network. Clear. Text √ Example: Computer Management, Event Viewer, Device Manager, Services Example: Enter-PSSession server New-PSSession server -Authentication Credssp -Credential cred

Connection method Ps. Exec without explicit creds Logon type Network Ps. Exec with explicit creds Network + Interactive Remote Registry Network Remote Desktop Gateway Scheduled task Reusable credentials on destination Comments Example: Ps. Exec \server cmd - Network Batch Ps. Exec \server -u user -p pwd cmd √ Creates multiple logon sessions. √ Authenticating to Remote Desktop Gateway. Password will also be saved as LSA secret on disk.

Connection method Run tools as a service Vulnerability scanners Logon type Reusable credentials on destination Comments Password will also be saved as LSA secret on disk. Service √ Network - Most scanners default to using network logons, though some vendors may implement non-network logons and introduce more credential theft risk.
