Top secret Secret Internal use only Public Product range & Options

1. Abbreviations 2. Product range 3. Combination table 4. Options 5. Operation range

Abbreviations 3 Abbreviation Full BPH Bottom plate heater BSH Booster heater BUH Back-up heater DHW Domestic hot water EWT Entering water temperature LWT Leaving water temperature IU Indoor unit OU Outdoor unit Small unit 04 -08 k. W – Singel fan OU HPC Heat pump convector SPH/SPC Space heating/cooling MMI Man machine interface UFH Underfloor heating Title - Internal use only

Product range ER G A 04 -08 DA V 3 (A) 4 European split outdoor pair heat pump Medium water temperature; ambient zone -10°C-20°C R 32 refrigerant Capacity size (04 -06 -08 k. W) Serie Type of power supply; V 3 = 1 N~-230 V 50 Hz < 16 A (DACE model) Title - Internal use only

Product range E HV H/X 04 -08 S 18 DA 6 V/9 W G 5 European split indoor pair heat pump Floorstanding indoor unit H : Heating X : Heating & Cooling Z : Bizone unit (Heating only) Capacity size (04 -08 k. W) Tank size ; 180 or 230 liter Series 6 V: 2 or 6 k. W 1 x 230 V, 50 Hz 9 W: 3, 6 or 9 k. W 3 x 400 V, 50 Hz V : BUH-less unit (DAB) Grey colour Title - Internal use only

Product range Cap class Mode H/O 04 Revers BUH tank Mat name Prod name BUH less 230 liter 180 liter 230 liter 180 liter 230 liter 180 liter 230 liter EHVH 04 S 23 DV EHVH 04 S 18 D 6 V EHVH 04 S 23 D 6 V EHVX 04 S 18 D 3 V EHVX 04 S 23 D 3 V EHVX 04 S 18 D 6 V EHVX 04 S 23 D 6 V EHVH 08 S 23 DV EHVH 08 S 18 D 6 V EHVH 08 S 23 D 6 V EHVH 08 S 18 D 9 W EHVH 08 S 23 D 9 W EHVX 08 S 18 D 6 V EHVX 08 S 23 D 6 V EHVX 08 S 18 D 9 W EHVX 08 S 23 D 9 W EHVZ 04 S 18 D 6 V EHVZ 08 S 23 D 6 V EHVZ 08 S 18 D 9 W EHVZ 08 S 23 D 9 W EHVH 04 S 23 DAV EHVH 04 S 18 DA 6 V EHVH 04 S 23 DA 6 V EHVX 04 S 18 DA 3 V EHVX 04 S 23 DA 3 V EHVX 04 S 18 DA 6 V EHVX 04 S 23 DA 6 V EHVH 08 S 23 DAV EHVH 08 S 18 DA 6 V EHVH 08 S 23 DA 6 V EHVH 08 S 18 DA 9 W EHVH 08 S 23 DA 9 W EHVX 08 S 18 DA 6 V EHVX 08 S 23 DA 6 V EHVX 08 S 18 DA 9 W EHVX 08 S 23 DA 9 W EHVZ 04 S 18 DA 6 V EHVZ 08 S 23 DA 6 V EHVZ 08 S 18 DA 9 W EHVZ 08 S 23 DA 9 W 6 V 3 V 3 V 6 V BUH less Floor - std H/O 6 V 9 W 08 6 V Revers Floor - bizone 04 H/O 08 H/O 9 W 6 V 6 V 6 V 9 W 9 W 6 Title - Internal use only

Product range E HB H/X 04 -08 DA 6 V/9 W 7 European split indoor pair heat pump Wall mounted indoor unit H : Heating X : Heating & Cooling Capacity size (04 -08 k. W) Series 6 V: 2 or 6 k. W 1 x 230 V, 50 Hz 9 W: 3, 6 or 9 k. W 3 x 400 V, 50 Hz White only Title - Internal use only

Product range Cap class Mode 04 H/O Revers H/O 08 Revers 8 Title - Internal use only BUH Outlook Material name Product name 6 V 6 V 6 V 9 W white white EHBH 04 D 6 V EHBX 04 D 6 V EHBH 08 D 9 W EHBX 08 D 6 V EHBX 08 D 9 W EHBH 04 DA 6 V EHBX 04 DA 6 V EHBH 08 DA 9 W EHBX 08 DA 6 V EHBX 08 DA 9 W

Product range E HF H 04 -08 S 18 DA 3 V European split oudoor pair heat pump Floorstanding indoor unit – LOW COST MODEL H : Heating Capacity size (04 -06 -08 k. W) Tank size ; 180 liter only Series 3 k. W 1 x 230 V, 50 Hz Postponed 09/2018 Cap class Mode 04 H/O 08 H/O 9 Title - Internal use only BUH 3 V 3 V Tank 180 L Outlook white White Material name EHFH 04 E 18 D 3 V EHFH 08 E 18 D 3 V Product name EHFH 04 E 18 DA 3 V EHFH 08 E 18 DA 3 V

Combination table HEATING - R 32 - Altherma LT (4 – 6 - 8 k. W) Model name R 32 NEW MODELS Hydro BOX 'DA-series' Floor standing - integrated tank Wall mounted STANDARD (EHV(H/X)) STANDARD and BI-ZONE (EHVZ) EHBH 04 DA 6 V EHBH 08 DA 6 V EHVH 04 S 23 DAV EHVH 08 S 23 DAV EHBX 04 DA 6 V EHBH 08 DA 9 W EHVH 04 S 18 DA 6 V EHVH 08 S 18 DA 6 V EHBX 08 DA 6 V EHVH 04 S 23 DA 6 V EHVH 08 S 23 DA 6 V EHBX 08 DA 9 W EHVX 04 S 18 DA 3 V EHVH 08 S 18 DA 9 W EHVX 04 S 18 DA 6 V EHVH 08 S 23 DA 9 W EHVX 04 S 23 DA 3 V EHVX 08 S 18 DA 6 V EHVX 04 S 23 DA 6 V EHVX 08 S 23 DA 6 V EHVZ 04 S 18 DA 6 V EHVX 08 S 18 DA 9 W EHVX 08 S 23 DA 9 W EHVZ 08 S 18 DA 6 V EHVZ 08 S 23 DA 6 V EHVZ 08 S 18 DA 9 W EHVZ 08 S 23 DA 9 W P P P Check databook ERGA 04 DAV 3(A) R 32 - 65 °C ERGA 06 DAV 3(A) (standard) ERGA 08 DAV 3(A) 10 Title - Internal use only

Options Name Description Aplicable unit FS 11 WM EKHBCONV Kit to convert Heating only to heating/cooling models EKVBCONV Kit to convert Heating only to heating/cooling models X EKFILL-CA Filling kit X BRP 069 A 61 Lan adapter (LAN + SG + PV) X X BRP 069 A 62 Lan adapter (LAN only) X X KRCS 01 -1 Remote indoor sensor X X KRCSA 1 Remote outdoor sensor X X EKPCCAB 3 PC-cable (Updater AND D-checker) X X EKRP 1 HBAA Option PCB X X EKRP 1 AHTA Demand PCB X X EKRUDAS Simplified controller X X Title - Internal use only X OU

Options Name Description Aplicable unit FS 12 WM OU EKLBUHCB 6 W 1 BUH for BUH-less models EKDP 008 D Drain pan X EKDPH 008 D Drain pan heater X EKFT 008 D Mounting feet X FWXV 15/20 VEB HPC X X BZKA 7 V 3 Bizone kit X X - Tanks – See details on seperate slide - BUH – See details on seperate slide Title - Internal use only X

Options EKHBCONV EKVBCONV Conversion kit from HO to HC - Insulation - New pressure sensor - Drainpan 13 Title - Internal use only

Options EKFILL-CA Filling kit Canceled 14 Title - Internal use only

Options BRP 069 A 61 Lan adapter for App + PV + SG connection BRP 069 A 62 Lan adapter for App Separate training available – See documentation added to this training or business portal https: //my. daikin. eu/content/denv/en_US/home/applications/productfinder/BRP 069 A 62. html 15 Title - Internal use only

Options KRCS 01 -1 Ambient sensor for inside - Temperature measurement remotely from UI - Connect to indoor unit - Only for RT control KRSCA 1 Ambient sensor for outside - Temperature measurement remotely from outdoor unit (ambient temp) - Connected to indoor unit Only one of these 2 sensors can be installed 16 Title - Internal use only

Options EKPCCAB 3 PC Cable - Possibility to - Update the software of the unit Monitor data via D-checker - Lasest software is available on internet: www. daikineurope. com – software downloads - Connection to - 17 X 10 A = Hydro PCB Title - Internal use only

Options EKRP 1 HBAA Option PCB or Digital I/O PCB Hydro A 1 P/X 33 A – Option PCB A 4 P/X 2 A - Alarm output YC – Y 1 - Space Heating/Cooling OR On/Off signal YC – Y 2 - External heat source KCR X 1 -X 2 Check wiring diagram of indoor unit for details! 18 Title - Internal use only

Options EKRP 1 AHTA Demand PCB Hydro A 1 P/X 85 A – Option PCB X 80 A - Power consumption control : Digital Inputs X 801 M Details about PCC -> IRG (or chapter Installation) 19 Title - Internal use only

Options EKRUDAS - In combination with the MMI - Simplified version of normal user interface to improve custumor friendlyness - Limited functions and dedicated button layout 20 Title - Internal use only

Options BUH Wall mounted - No wiring changes needed anymore (Settings only!) BUH 6 V 9 W 21 BUH Cap 2 k. W 2 – 4 k. W 2 – 6 k. W 3 – 6 k. W (9 k. W emergency) 3 – 9 k. W Title - Internal use only Steps 1 2 2 1 2 Power supply 1 x 230 V 3 x 400 V 2 3 x 400 V BUH : - 6 k. W 1 x 230 V BUH, adjustable to 2 or 4 k. W available on all capacity classes - 9 k. W 3 x 400 V BUH, adjustable to 3 or 6 k. W available on 6/8 k. W capacity class

Blanco BUH floorstanding - No rewiring needed anymore (Settings only) BUH V 3 V 6 V 9 W 22 BUH Cap 3 KW 2 k. W 2 – 4 k. W 2 – 6 k. W 3 – 6 k. W (9 k. W emergency) 3 – 9 k. W Title - Internal use only Steps 1 1 2 2 1 2 Power supply 1 x 230 V 3 x 400 V 3 x 400 V 2 3 x 400 V BUH - 3 k. W 1 x 230 V on 4 k. W reversible units (DACE demand <16 A) - BUH less models : 4 k. W now also in big size tank (DAB demand) - 6 k. W 1 x 230 V BUH, adjustable to 2 or 4 k. W (available on all capacity classes and all tank sizes) - 9 k. W 3 x 400 V BUH, adjustable to 3 or 6 k. W (available on 6/8 k. W capacity class and all tank sizes

Blanco EKLBUHCB 6 W 1 23 Title - Internal use only a Water in – 1” – Male b Water uit – 1” – Male c Air purge d BUH e BUH contactor f BUH thermal fuse g BUH overcurrent fuse h Terminal block

Options EKDP 008 D Drain pan - Dimensions 775 x 300 x 34, 7/60, 8 mm - Drainhole 38 mm - Collect water from defrost cycle and drain via central hole - Consists of a drainpan and U-beams EKDPH 008 D - min. 5 mm between wires - 90 W +/- 10% - ON if Tamb < 0°C and during defrost 24 Title - Internal use only

Options EKFT 008 D - U-beams for mounting outdoor unit without drainpan - Dimensions 300 x 106 x 55 mm 25 Title - Internal use only

Options FWXV 15 -20 VEB Seperate training availabe on the business portal FWXV HPC 15 Capacity (0, 1 k. W) A Series V Single phase E Frequency (50 & 60 Hz) B CE mark 26 Title - Internal use only

Options Tanks – Polyproylene tank required for solar connection EK U HW P B or BB European kit UK tank DHW tank Polypropylene tank Series with drain back solar Series with pressurised solar 28 Title - Internal use only

Option – Connection kit for ROTEX tank – EKDVCPLT 3/5 H/X EKVCDPLT 3 H or EKVCDPLT 3 X - For 300 l tank - H = Heating only / X = Heating and cooling EKVCDPLT 5 H or EKVCDPLT 5 X - For 500 l tank - H = Heating only / X = Heating and cooling 29 Title - Internal use only

Options Tank – Stainles steel (OSO) tank EK HW S (U) 150 D 3 V 3 European kit DHW tank Stainless steel UK tank -> preplumed + expansion vessel Volume (150, 180, 200, 250, 300 liter) Series BSH capacity (k. W) Power supply 1~, 230 V, 50 Hz MANUAL 30 Title - Internal use only

Option – Connection kit for ‘field supplied’ tank Not compatible – We do NOT allow the connection of 3 rd party tanks 31 Title - Internal use only

Option – Room thermostat EKRTWA/EKRTR 1/EKRTETS - Wired space heating/cooling controller : EKRTWA - Remote space heating/cooling controller : EKRTR 1 (receiver incl. ) - External sensor: EKRTETS Additional sensor for dew point prevention (UFH) 32 Title - Internal use only

Operation range Check databook ERGA-DV 3 33 Title - Internal use only
