TK 2123 Lecture 13: Assembly Language Level (Level 4) Ass. Prof. Dr Masri Ayob

Why Use Assembly Language? n Assembly language programming is difficult. n n n Why use assembly language? n n 6/8/2021 Writing a program in assembly language takes much longer than writing the same program in a high-level language. Much longer to debug and much harder to maintain. Performance Access to the machine Prepared by: Dr Masri Ayob 2

Why Use Assembly Language? n Performance n n Access to the machine. n 6/8/2021 An expert assembly language programmer can often produce code that is much smaller and faster than a highlevel language programmer can. n Some application – speed and size are critical. E. g. embedded application (code on a smart card, handphone, etc. ) Some procedure need complete access to the hardware. n E. g. low-level interrupt, trap handlers in OS, device controller, etc. n This is usually impossible in high-level language. Prepared by: Dr Masri Ayob 3

Why Use Assembly Language? Comparison of assembly language and high-level language programming, with and without tuning. 6/8/2021 Prepared by: Dr Masri Ayob 4

Assembly Language n n 6/8/2021 Assembly language: n Assembly language is used for most programming because it is extremely difficult to program a microprocessor in its native, that is hexadecimal machine language. Assembler: n An assembler is a program that converts software written in symbolic machine language (the source program) into hexadecimal machine language (object program). n The primary reason to use assembler is because development and modification are always difficult in machine language. Prepared by: Dr Masri Ayob 5

Assembly Language n n Instruction is a command to the microprocessor to perform a given task on specified data. Each instruction has two parts: n n 6/8/2021 one is the task to be performed, called the operation code (op-code), the second is the data to be operated on, called the operand. n The operand (or data) can be specified in various ways. n It may include an internal register or a memory location. n In some instructions, the operand is implicit. Prepared by: Dr Masri Ayob 6

Assembly Language n 6/8/2021 The Two-pass Assembler : n Read programme two times. 1. Generate a table of the labels/symbols within the source program. 2. Develop hexadecimal version of the source program. n Allow forward addressing (the software can jump ahead to an instruction in a program). Prepared by: Dr Masri Ayob 7

Assembly Language 6/8/2021 Prepared by: Dr Masri Ayob 8

Assembly Language n 6/8/2021 The assembler always assumes that the first instruction of the program is stored at memory address 0000 H unless otherwise directed by the ORG command. Prepared by: Dr Masri Ayob 9

Assembly Language n Pass One: n n n 6/8/2021 The assembler scans the source program during the first pass and generates a table of the labels found within the source program. Each entry in the label table contains the label and the address where the label appears in the program. During the first pass the assembler determines the length of each instruction by updating an internal program counter. This internal program counter allows the assembler to complete the label table by equating each label with the counter. Once the label table is complete the second pass begin. Prepared by: Dr Masri Ayob 10

Assembly Language n Pass Two: n During the second pass of the source program, the assembler forms the object program. n This occurs by referring to the label table for any labels that appear in the program and to an instruction table. n The instruction table contains all the opcodes in both symbolic and machine language forms. n The tables help convert the source program into the object program. 6/8/2021 Prepared by: Dr Masri Ayob 11

Assembly Language n n 6/8/2021 Assembly Language Statement: n Format : Label Field. n Contains a symbolic memory address that refers to the statement in a program. Labels are optional. n Labels are constructed from alphanumeric characters and must begin with any letter of the alphabet. Prepared by: Dr Masri Ayob 12

Format of an Assembly Language Statement (1) Computation of N = I + J. (a) Pentium 4. 6/8/2021 Prepared by: Dr Masri Ayob 13

Format of an Assembly Language Statement (2) Computation of N = I + J. 6/8/2021 (b) Motorola 680 x 0. Prepared by: Dr Masri Ayob 14

Format of an Assembly Language Statement (3) Computation of N = I + J. (c) SPARC. 6/8/2021 Prepared by: Dr Masri Ayob 15

Assembly Language n Opcode field: n n Operand field: n n 6/8/2021 This field must contain opcodes. May contain register name, data or labels. If more than one of these is present, they must be separated with comma. Data must be encoded as decimal, binary, octal, hexadecimal, or ASCII must appear as one of more letters surrounded by apostrophe. Prepared by: Dr Masri Ayob 16

Assembly Language n 6/8/2021 Operand arithmetic operations. Prepared by: Dr Masri Ayob 17

Assembly Language n 6/8/2021 Comment field. n Must begin with semicolon in most 8085 assemblers and may continue to the end of the line only. n Use asterisk * or semicolon ; if the comment should continue into the next line. n Example : Prepared by: Dr Masri Ayob 18

Pseudoinstructions n 6/8/2021 Assembler pseudo operations. n Directives to the assembler program that may or may not generate machine code. n Examples : n END, DB, DW, DS, ORG, EQU, IF, ENDIF, SET, GLB, EXT, TITLE, SPC. n All pseudo operations must appear in the opcode field of a statement. Prepared by: Dr Masri Ayob 19

Pseudoinstructions n 6/8/2021 Define Byte (DB). n Defines 8 -bit memory data for a program. n Multiple one byte data, comma ( , ) as a separator. Prepared by: Dr Masri Ayob 20

Assembly Language : Example 6/8/2021 Prepared by: Dr Masri Ayob 21

Pseudoinstructions n 6/8/2021 Origin (ORG). n Changes the starting location of the program to another address besides 0000 H. n Can be used at any place in a program to change the location of the assembled machine language instructions or data. Prepared by: Dr Masri Ayob 22

Assembly Language : Example 6/8/2021 Prepared by: Dr Masri Ayob 23

Pseudoinstructions n 6/8/2021 Define Word (DW). n Pseudo operation stores a 16 -bit number in the memory for use by a program. n Defines no only numeric data but also memory addresses and label. Prepared by: Dr Masri Ayob 24

Assembly Language : Example 6/8/2021 Prepared by: Dr Masri Ayob 25

Pseudoinstructions n 6/8/2021 Define Storage (DS). n Reserves space in a program for variable data. n Does not place any specific data into the reserved area of memory. Prepared by: Dr Masri Ayob 26

Assembly Language : Example 6/8/2021 Prepared by: Dr Masri Ayob 27

Pseudoinstructions n 6/8/2021 Equate (Equ). n Equates a label to another label or value. n Note that the EQU statement label does not contain a colon ( : ). Prepared by: Dr Masri Ayob 28

Assembly Language 6/8/2021 Prepared by: Dr Masri Ayob 29

Macro n n Assembly language programmer frequently need to repeat sequence of instructions several times within a program. Solution: n n 6/8/2021 Use subroutine (CALL instruction). n Disadvantage: Procedure CALL overhead. Use Macro n Easy and efficient solution n Is a way to give name to a piece of text. Prepared by: Dr Masri Ayob 30

Macro Definition, Call, Expansion (1) Macro Assembly language code for interchanging P and Q twice. (a) Without a macro. (b) With a macro. 6/8/2021 Prepared by: Dr Masri Ayob 31

Macro Definition, Call, Expansion (2) Comparison of macro calls with procedure calls. 6/8/2021 Prepared by: Dr Masri Ayob 32

Macros with Parameters Nearly identical sequences of statements. (a) Without a macro. (b) With a macro. 6/8/2021 Prepared by: Dr Masri Ayob 33

Thank you Q&A 6/8/2021 Prepared by: Dr Masri Ayob 34
