Tivoli Directory Integrator IBM Software Group ® Tivoli Directory Integrator Exercise 05 – the System Store Eddie Hartman eddie. hartman@no. ibm. com 2005. 06. 20

Tivoli Directory Integrator IBM Software Group TDI: A Stateless System By default, no storage required Data persistence is handled by connected systems 2

Tivoli Directory Integrator IBM Software Group Optional System Store The System Store provides persistence of Iterator state, Delta Engine "snapshots", Sandbox data and user specified information 3

Tivoli Directory Integrator IBM Software Group System Store JDBC data source By default, Cloudscape (Derby) – db 2 java Can be configured for DB 2 instead Other RDBMS can be used - requires you to. System set up SQL calls for Store System Store tables creation of standard System Store paramters in global. properties (or solution. properties if a TDI solution directory is used) 4

Tivoli Directory Integrator IBM Software Group Java Virtual Machine (JVM) Cloudscape (Derby) : 2 Modes System Store Embedded Shares its JVM with TDI 5

Tivoli Directory Integrator IBM Software Group Java Virtual Machine (JVM) System Store Embedded Networked Shares its JVM with TDI Runs in its own JVM Java Virtual Machine (JVM) Cloudscape (Derby) : 2 Modes 6

Tivoli Directory Integrator IBM Software Group System Store Config Editor (CE) Java Virtual Machine (JVM) Embedded Mode In Embedded mode, the database can only be accessed from within the same JVM as Cloudscape is running Runtime Server 7

Tivoli Directory Integrator IBM Software Group System Store Config Editor (CE) Java Virtual Machine (JVM) System Store Java Virtual Machine (JVM) Embedded Mode Runtime Server 8
