The pale blue dot Earth from the Voyager

“The pale blue dot” …. Earth from the Voyager spacecraft, > 4 billion miles away http: //solarsystem. nasa. gov/multimedia/display. cfm? IM_ID=2148

http: //www. solstation. com/stars/earth. htm http: //nssdc. gsfc. nasa. gov/photo_gallery/photogallery-mars. html

http: //www. thew 2 o. net/#

http: //www. misterteacher. com/rainforestwebquest. html

CO 2 N 2 H 2 O Ar O 2 Earth Mars 0. 035% 77% 1% 95% 2. 7% 0. 007% 0. 93% 21% 1. 6% trace http: //www. misterteacher. com/rainforestwebquest. html

http: //science. kennesaw. edu/~jdirnber/Bio. Oceanography/Lectures/Lec. Physical. Ocean. html

0. 5 bya: Cambrian 0. 24 bya: Mesozoic 0. 065 bya: Cenozoic 0. 9 bya: first animals 1. 8 bya: first eukaryote 2. 3 -2. 0 bya: Oxygen 4. 0 bya: Oldest Rocks 3. 4 bya: Oldest Fossils 4. 5 bya: Earth Forms Earth History 4. 5 million to present (1/1000 th of earth history)

All genera The “big five” Mass Extinction Events Millions of Years Ago http: //en. wikipedia. org/wiki/File: Phanerozoic_biodiversity_blank_01. png Thousands of Genera “well described” genera

(% of Genera) Permian mass extinction: 96% of all marine species and 70% of terrestrial vertebrate species

WHY?

WHY?

WHY?

WHY?

WHY?

http: //science. nationalgeographic. com/science/prehistoric-world/mass-extinction/

ecological collapse Almost all animals over 25 kg (~55 lbs) went extinct. (The things that require the most energy to survive) http: //we. vub. ac. be/~dglg/Web/Claeys/Chicxulub/Chixproject. html

BIODIVERSITY NOW http: //www. coral. org/node/3230

Millenium Ecosystem Assessment (2006) http: //englishontour. blogspot. com/2011/03/beetles. html

http: //www. illuminatedorigin. com/The_Illuminated_Origin_of_Species/Blog/Entries/2011/9/22_Beetles!. html Detritivores Pollinators Insect predators Herbivores http: //www. sbs. utexas. edu/jcabbott/abbottlab/

http: //www. dendroboard. com/forum/photography/42636 -incredible-costa-rican-euglossine-bees. html Pollinators Insect Parasitoids (lay eggs on other insects) Insect Predators

http: //magicbelles. com/flutterbudclub/special-wonders/beetles Jewel Bug Herbivores Pollinators Parasites Detritivores Malagasy Sunset Butterfly http: //www. brisbaneinsects. com/brisbane_flies/images/PWC_8410. jpg http: //buggirl. tumblr. com/post/12568644622/bugs-that-break-the-rules-themadagascar-sunset

http: //www. trekearth. com/gallery/Africa/South_Africa/West/Eastern_Cape/Kob_Inn/photo 915391. htm Herbivores Detritivores

http: //www. flowersociety. org/Redwood-profile. htm PRODUCERS http: //www. paulsanghera. com/infonential-Contact. html

Most vertebrate species are fishes http: //www. elp. manchester. ac. uk/pub_projects/2003/MNZO 0 MLK/lecture 1. htm

http: //ambergriscaye. com/critters/redeyedtreefrog. ht ml http: //freakz. info/2011/09/21/10 -interesting-seahorse-facts/ http: //australian-animals. net/plat. htm http: //www. pbase. com/image/37557333 http: //www. bbc. co. uk/nature/life/Blue_Whale Herbivores, Predators, Detritivores, Pollinators http: //www. hodag. info/what%E 2%80%99 s-going-on-herethen-100

But do we NEED all these species? ?

There’s a lot of redundancy in nature… http: //katherinegerdes. com/portfolio/11/rainy-day-jewels

Are all species equally important? If not, which ones are critical?

without

We don’t know which species are critical So we need to save them all to maintain ecosystem function

But what does biodiversity do? ?

1) Biodiversity increases “productivity”. . . FOOD

Monoculture They all need the same things at the same concentrations; they compete.

“Niche Complementarity” Monoculture Polyculture They all need the same things at Combinations of different plants can be the same concentrations; they planted at higher density, and they use compete. different "niches" and coexist. Even if abundance of "most productive" species drops, this loss can be offset.

“Positive Effects” Monoculture They all need the same things at the same concentrations; they compete. Polyculture without beans with beans Nitrogen fixing legumes (beans) nutrify the soil, increasing the growth of other plants. And you have beans!

2) Biodiversity improves ecosystem services Estimates of various Ecosystem Services - $U. S. trillions Ecosystem services Value (trillion $US) Soil formation Recreation Nutrient cycling Water regulation and supply Climate regulation (temperature and precipitation) Habitat Flood and storm protection Food and raw materials production Genetic resources Atmospheric gas balance Pollination All other services Total value of ecosystem services 17. 1 3. 0 2. 3 1. 8 1. 4 1. 1 0. 8 0. 7 0. 4 1. 6 33. 3 Source: Adapted from R. Costanza et al. , “The Value of the World’s Ecosystem Services and Natural Capital, ” Nature, Vol. 387 (1997), p. 256, Table 2. TOTAL GLOBAL GNP (1997) = 18 trillion.

3) Aesthetics and Inspiration: Biodiversity enriches our cultures

How is our biodiversity doing? Genetic diversity within species Species diversity in communities Ecosystem diversity

How is our biodiversity doing? Humans used hundreds of crop species worldwide; now 3 species (rice, wheat, corn) provide 60% of our calories from crop plants. According to the FAO of the UN, 70% of the genetic diversity of crop plants has been lost in the last 75 years as we’ve shifted to industrial farming and the use of GM strains.

How is our biodiversity doing? 2000 Pacific Island bird species (15% of global total) have gone extinct after human colonization 20 of the 297 mussel species in N. A. have gone extinct in the last 100 years; 60% are endangered 40 of 950 fish species in N. A. have gone extinct in the last century; 35% are threatened or endangered http: //www. americanscientist. org/issues/pub/the-real-biodiversity-crisis/1 Yellow-finned cutthroat trout http: //www. fishdecoys. net/pages/LDC_Collection/Benzie. Jo. Decoys. htm http: //www. nps. gov/sacn/planyourvisit/st-croixcurrents. htm? customel_data. Page. ID_206517=289024

How is our biodiversity doing? 1 in 4 mammal species is endangered 1 in 8 bird species is endangered 1 in 3 amphibian species is endangered 48% of primate species are threatened Data from: http: //iucn. org/what/tpas/biodiversity/

How is our biodiversity doing? 35% of mangrove habitat has been lost in the last 20 years In the Caribbean, hard coral cover has declined from 50% to 10% in the last 20 years Since 2000, 232, 000 sq miles of old growth forest have been lost (size of Texas).

WHY?

7 billion in 2011 (12 years later)

http: //news. mongabay. com/2011/1009 -amazon_deforestation_revised. html 13, 000 sq kilometers is about the size of Connecticut

Extent of Virgin Forest, Contiguous U. S. http: //mvh. sr. unh. edu/mvhinvestigations/old_growth_forests. htm

Millenium Assessment 2006

Humans use/control 40% of the ‘food’ produced on the planet. 1 10 million?

Fragmentation

Fragmentation Area Effects CARNIVORES HERBIVORES PLANTS LARGE AREA OF HABITAT

Fragmentation HABITAT FRAGMENTATION

Fragmentation 1) Carnivores lost - (reduce diversity) 2) Herbivores compete – (reduce diversity) 3) Plants overgrazed – (reduce diversity) HABITAT FRAGMENTATION

We are a geological force, operating on an ecological timescale Mountaintop removal in West Virginia

We are a geological force, operating on an ecological timescale Gold mining in Peruvian Amazon

We are a geological force, operating on an ecological timescale

We are a geological force, operating on an ecological timescale Hmmmm….

Sixth major mass extinction event - NOW All genera The “big five” Mass Extinction Events Millions of Years Ago http: //en. wikipedia. org/wiki/File: Phanerozoic_biodiversity_blank_01. png Thousands of Genera “well described” genera

22 May 2010 –Secretary-General Ban Ki-moon: “Biodiversity loss is moving ecological systems ever closer to a tipping point beyond which they will no longer be able to fulfill their vital functions. ”

What Can We Do? We need to protect and preserve large intact, biodiverse ecosystems.

This is great, but it ain’t gonna do it…

We need to rethink our model of community… nature Development

We need to find out what’s out there!

We need to appreciate the societal and economic value of biodiversity Corporate Social Responsibility (CSR) http: //www. justmeans. com/Stop-Loss-CSR-Biodiversity/28856. html “Protection of biodiversity should be the underlying reason for every CSR effort. Biodiversity loss is the most severe threat to human-wellbeing on the planet. It rates even higher than climate change and related problems…. The head of Deutsche Bank's Global Markets predicts that our current rate of biodiversity loss could see 6% of global GDP wiped out as early as 2050. The Economics of Ecosystems and Biodiversity executive summary (2010) reports that “over 50% of CEOs surveyed in Latin America and 45% in Africa see declines in biodiversity as a challenge to business growth. In contrast, less than 20% of their counterparts in Western Europe share such concerns”

If we recognize the grandeur of life, we might appreciate it…

If we appreciate it, we might value it…

If we value it, we might sustain it…

If we sustain it, we might be able to sustain our societies and economies, as well. ECONOMY SOCIETY ENVIRONMENT

If we don’t, we won’t… Thylacine - 1936 Tecopa Pupfish - 1981 Quogga - 1883 Vietnamese Rhinoceros - 2010 Yangtze River Dolphin - 2006 Golden Toad - 1989 A few extinct animal species.

Study questions: In what two major ways does the earth differ from Mars? How have each of these differences influenced the dramatic loss of CO 2 from the earth atmosphere, relative to Mars? Dinosaurs went extinct because a meteor struck the earth and caused an ‘ecological catastrophe’ in which the animals with the greatest energy demand went extinct. Why is humanity similarly vulnerable with respect to the amount of resources we use, and the range of food we consume? What are the two main ways that we are causing the extinction of other organisms? Why is maintaining diversity important? (Brief answers on the next slides – try them yourselves first!!!!)

Study questions: In what two major ways does the earth differ from Mars? Lots of liquid water at the surface, and the presence of life. How have each of these differences influenced the dramatic loss of CO 2 from the earth atmosphere, relative to Mars? First, CO 2 dissolves in water. Then, it is available to organisms that make shells and reefs out of calcium carbonate. This material accumulates as sedimentary deposits (Cliffs of Dover) in the lithosphere. Likewise, the evolution of photosynthesis (specifically the ‘light independent reaction’) allow CO 2 in the atmosphere to be stored as glucose, cellulose, and other organic molecules. Although respiration and decomposition would return CO 2 to the atmosphere, much of the organic remains have been preserved as fossil fuel deposits in sedimentary rocks – again representing a transfer of CO 2 from the atmosphere to the lithosphere, mediated by living organisms.

Study questions: Dinosaurs went extinct because a meteor struck the earth and caused an ‘ecological catastrophe’ in which the animals with the greatest energy demand went extinct. Why is humanity similarly vulnerable with respect to the amount of resources we use, and the range of food we consume? We use 40% of the food produced on land. If there was an ecological catastrophe that reduced food production, we would feel it worse than other species. In addition, we get 60% of our calories from just three species!!! So, if a calamity befalls any of these three species, we will feel it. What are three main ways that we are causing the extinction of other organisms? 1. Competition – we are consuming most the food. 2. This is largely by changing their habitats (prairie, forest, etc. ) into our agricultural land. 3. Changing the climate faster than it has changed before, and faster than many species can adapt. Why is maintaining diversity important?

Study questions: Why is maintaining diversity important? Natural ecosystems provide ‘services’ upon which humanity depends, such as making food, cleaning the air, cleaning the water, stabilizing the climate, and fertilizing the soil. Ecology has shown that more diverse systems are more effective and efficient at performing these functions. Although there is redundancy in nature, we don’t yet know which species are the key ‘drivers’ of ecosystem function. As such, in order to maintain ecosystem function, we must ‘keep all the pieces’. As the percentage of endangered species in different groups shows, we aren’t doing such a great job at this. BUT! The first step in solving a problem is identifying it. Now we know. Now we must act.
