The Page. Rank Citation Ranking: Bringing Order to the Web Presented By: Noy Hadar

Introduction and Motivation 1998 - there are over 150 million web pages. 2016 - at least 4. 62 billion web pages. Huge number of web pages. The average web page quality >= quality of the average web page.

Let’s Count Simple links count doesn’t work. Useless websites http: //www. theuselessweb. com/ Show Me Your Friends, I’ll Tell You Who You Are

Related Work HITS algorithm (Jon Kleinberg). Two scores for each page: authority hub

Link Structure of the Web Forward links = outedges Backlinks = inedges

Importance of Links Most pages have just a few backlinks. Highly linked pages are more "important”. 1 important link vs. many average ranked links Vs.

Definition of Page. Rank A method for computing a ranking for every web page. Based on the graph of the web. High rank requires: • many backlinks • highly ranked backlinks A page is important if important pages refer to it.

Simple Ranking Function u: web page Bu: backlinks Nu = |Fu| number of links from u c: factor used for normalization

Simplified Page. Rank Calculation Page Rank A 1/8 B 1/8 C 1/8 D 1/8 E 1/8 F 1/8 G 1/8 H 1/8

Iteration 1 Page Rank A 1/2 B 1/8 C 1/8 D 1/8 E 1/8 F 1/8 G 1/8 H 1/8

Iteration 1 Page Rank A 1/2 B 1/16 C 1/8 D 1/8 E 1/8 F 1/8 G 1/8 H 1/8

Iteration 1 Page Rank A 1/2 B 1/16 C 1/16 D 1/8 E 1/8 F 1/8 G 1/8 H 1/8

Iteration 1 Page Rank A 1/2 B 1/16 C 1/16 D 1/16 E 1/8 F 1/8 G 1/8 H 1/8

Iteration 1 Page Rank A 1/2 B 1/16 C 1/16 D 1/16 E 1/16 F 1/8 G 1/8 H 1/8

Iteration 1 Page Rank A 1/2 B 1/16 C 1/16 D 1/16 E 1/16 F 1/16 G 1/8 H 1/8

Iteration 1 Page Rank A 1/2 B 1/16 C 1/16 D 1/16 E 1/16 F 1/16 G 1/16 H 1/8

Iteration 1 Page Rank A 1/2 B 1/16 C 1/16 D 1/16 E 1/16 F 1/16 G 1/16 H 1/8

Update Iteration 1 Page Rank A 1/2 B 1/16 C 1/16 D 1/16 E 1/16 F 1/16 G 1/16 H 1/8

Iteration 2 Page Rank A 5/16 B 1/16 C 1/16 D 1/16 E 1/16 F 1/16 G 1/16 H 1/8

Iteration 2 Page Rank A 5/16 B 1/4 C 1/16 D 1/16 E 1/16 F 1/16 G 1/16 H 1/8

Iteration 2 Page Rank A 5/16 B 1/4 C 1/4 D 1/16 E 1/16 F 1/16 G 1/16 H 1/8

Iteration 2 Page Rank A 5/16 B 1/4 C 1/4 D 1/32 E 1/16 F 1/16 G 1/16 H 1/8

Iteration 2 Page Rank A 5/16 B 1/4 C 1/4 D 1/32 E 1/32 F 1/16 G 1/16 H 1/8

Iteration 2 Page Rank A 5/16 B 1/4 C 1/4 D 1/32 E 1/32 F 1/32 G 1/16 H 1/8

Iteration 2 Page Rank A 5/16 B 1/4 C 1/4 D 1/32 E 1/32 F 1/32 G 1/32 H 1/8

Iteration 2 Page Rank A 5/16 B 1/4 C 1/4 D 1/32 E 1/32 F 1/32 G 1/32 H 1/16

Update Iteration 2 Page Rank A 5/16 B 1/4 C 1/4 D 1/32 E 1/32 F 1/32 G 1/32 H 1/16

Rank Sink F and G form a loop that accumulates rank to infinity.

Random Surfer Model The “random surfer” simply keeps clicking on successive links at random. If stuck in a loop of web pages jump to some other page. We model this behavior with the additional factor E.

Page. Rank Expression Let E(u) be some vector over the Web pages that corresponds to a source of rank. The water intuition. Dumping factor Usually d=0. 85 Number of forward links from v

Page. Rank Calculation Page Rank A 1/8 B 1/8 C 1/8 D 1/8 E 1/8 F 1/8 G 1/8 H 1/8

Page. Rank Calculation Page Rank A 0. 231 B 1/8 C 1/8 D 1/8 E 1/8 F 1/8 G 1/8 H 1/8

Page. Rank Calculation Page Rank A 0. 231 B 0. 071 C 1/8 D 1/8 E 1/8 F 1/8 G 1/8 H 1/8

Page. Rank Calculation Page Rank A 0. 231 B 0. 071 C 0. 071 D 1/8 E 1/8 F 1/8 G 1/8 H 1/8

Page. Rank Calculation Page Rank A 0. 231 B 0. 071 C 0. 071 D 0. 071 E 1/8 F 1/8 G 1/8 H 1/8

Page. Rank Calculation Page Rank A 0. 231 B 0. 071 C 0. 071 D 0. 071 E 0. 071 F 1/8 G 1/8 H 1/8 0. 85*1/16+0. 15*1/8

Page. Rank Calculation Page Rank A 0. 231 B 0. 071 C 0. 071 D 0. 071 E 0. 071 F 0. 071 G 1/8 H 1/8 0. 85*1/16+0. 15*1/8

Page. Rank Calculation Page Rank A 0. 231 B 0. 071 C 0. 071 D 0. 071 E 0. 071 F 0. 071 G 0. 071 H 1/8 0. 85*1/16+0. 15*1/8

Page. Rank Calculation Page Rank A 0. 231 B 0. 071 C 0. 071 D 0. 071 E 0. 071 F 0. 071 G 0. 071 H 0. 071 0. 85*1/16+0. 15*1/8

Dangling Links that point to any page with no outgoing links. Where should their weight be distributed?

Page. Rank Implementation 1. 2. 3. 4. 5. 6. 7. • Convert each URL into a unique integer ID Sort the link structure by ID Remove the dangling links Make an initial assignment of ranks Iteratively compute Page. Rank until Convergence Add the dangling links back Recompute the rankings After adding the dangling links back, we need to iterate as many times as was required to remove the dangling links

Convergence of Page. Rank Computations Page. Rank(322 Million link db) converges in 52 iterations Page. Rank(322/2 Million link db) converges in 45 iterations Scaling factor is roughly linear in logn

Personalized Page. Rank Important component of Page. Rank calculation is E E vector corresponds to the distribution of web pages that a random surfer periodically jumps to. In Personalized Page. Rank E consists of a single web page.

Conclusions Page. Rank is based solely on page location in the Web’s graph structure. More important and central Web pages are given preference. The structure of the Web graph is very useful for information retrieval tasks.

References https: //www. cs. bgu. ac. il/~snean 171/wiki. files/06 Page. Rank. pdf https: //en. wikipedia. org/wiki/Page. Rank https: //www. quora. com/How-many-web-pages-arethere-on-the-internet-in-2016 https: //en. wikipedia. org/wiki/HITS_algorithm#Algorith m https: //www. cs. cornell. edu/home/kleinber/networksbook/networks-book-ch 14. pdf
