The Myths and Truths of Java Games Programming

The Myths (and Truths) of Java Games Programming Andrew Davison Dept. of Computer Engineering Prince of Songkla University Hat Yai, Songkhla 90112 Thailand ad@fivedots. coe. psu. ac. th Myths 1

In a Nutshell v Java for games programming: are you joking ? v No, Java is a great games programming language. Myths 2

The Familiar Advantages v The object-oriented paradigm. v Cross-platform support. v Code reuse. v Ease of development. v Tool availability. v Reliability and stability. Myths continued 3

v Good documentation. v Support from Sun Microsystems. v Low development costs. v The ability to use legacy code (e. g. C, C++) v Increased programmer productivity. v It's fun, especially for games programming. Myths 4

Java Bashing 1. 2. 3. 4. 5. 6. 7. Myths v Java is too slow for games programming. Java has memory leaks. Java is too high-level. Java application installation is a nightmare. Java isn't supported on games consoles. No one uses Java to write 'real' games. Sun Microsystems isn't interested in supporting Java gaming. Almost all of these are substantially wrong. 5

Wake up, it's 2006 v These objections had more validity in the late 1990 s – the language and its libraries were less sophisticated and slower – lots of hype led to lots of disappointment Myths 6

1. Java Is Too Slow For Games Programming v Or "Java is slow compared to C and C++, the dominant languages for games programming at the moment ". v JDK 1. 0 (1996): 20 to 40 times slower than C++ v J 2 SE 5: only 1. 1 times slower v Java SE 6 is about 20% faster than J 2 SE 5 Myths continued 7

v Speed depends on the application and coding style – Java programmers must be good programmers v Jack Shirazi's Java Performance Tuning site – http: //www. javaperformancetuning. com/ Myths 8

The Hotspot Compiler v Introduced in J 2 SE 1. 3. v The run-time system identifies areas of code that are utilized many times, and aggressively compiles them. v Program execution is often slow at the beginning until the code has been analyzed and compiled – splash screens API in Java SE 6 Myths 9

Slow-Moan 1: Swing is Slow v Swing GUI components don't use the OS much – portability, controllablilty – extra layer of processing above OS v Some games applications use the older, lower-level AWT GUI libraries. Myths continued 10

v J 2 SE 5/6 Swing uses Open. GL/Direct. X more directly v Most games don't require complex GUIs – full-screen game play with mouse and keyboard controls is the norm – mouse and keyboard processing is dealt with by the AWT – full-screen mode Myths 11

Slow-Moan 2: my Program is Slow (because of Java) v Where to lay the blame? – graphics rendering: Open. GL or Direct. X – network games: the network Myths 12

. 2 Java Has Memory Leaks v Uhh? – Java doesn't offer pointer arithmetic – out-of-bounds array accesses are caught Myths 13

Possible Meaning 1 v Defunct objects are not being garbage collected. v Due to bad programming style – the garbage collector can only do its job when an object is completely dereferenced Myths 14

Possible Meaning 2 v Garbage collector is executing at poorly timed intervals. v The JVM comes with several different garbage collectors – can be selected/fine-tuned from the command line Myths 15

Profiling Tools v Java SE 6: jps, jstat, jhat, and jstack v Many third-party tools – e. g. JProfiler Myths 16

. 3 Java Is Too High-level v Abstraction versus speed and control – C++ is too high-level – C is too high-level – assembler is too high-level – ICs are too high-level – an abacus is sufficient for all our computing needs Myths 17

Historical Observation v The gaming community used to think that C and C++ were too high-level. Until: – Doom and Dungeon Master, mid 1980 s – cross-platform development tools u e. g. Render. Ware, Gamebryo Myths 18

High-level Moan 1 v Java’s use of classes, objects, and inheritance add too much overhead without enough coding benefit. v Class libraries are essential: – high-speed I/O, advanced 2 D and 3 D graphics, networking, etc. v Object-oriented design (UML) Myths 19

High-level Moan 2 v Low-level, fast operations -- such as direct Video RAM I/O -- are impossible. v Full-screen mode – page flipping – control over the screen's resolution and image depth v Graphics rendering using Open. GL and Direct. X. Myths 20

High-level Moan 3 v Java can't use game peripherals – e. g. joysticks and game pads v Yes it can: – JNI, the Java Native Interface – JInput, the game devices API u https: //jinput. dev. java. net/ Myths 21

. 4 Installation Is A Nightmare 1. 2. Java has to be on the machine before the application will run. Code bloat – even small programs require a 16 MB JRE 3. 4. Myths Frequently changing JVMs. Non-standard components are often required (e. g. Java 3 D). continued 22

5. 6. 7. v Myths It's not possible to compile the application for a specific platform. The. jar extension is hijacked by other software The JRE is slower to start up compared to a native compiled application. Solved with good installation software – except for 2 and 7 23

Many Installation Options v Applets v Java SE 6 plug-in – for Internet Explorer v Java Web Start (JWS) – improved significantly since J 2 SE 1. 4. v Third-party installers – e. g. install 4 j Myths 24

Code Bloat v Increasingly irrelevant – many games weighing in at over 100 MB – many graphics and sound card drivers are larger than 15 MB v Network speeds are a problem, especially overseas – broadband usage is growing rapidly Myths 25

Others v Sun Microsystems estimates that around 70% of all new PC's come with a JRE pre-installed. v Slow start-up time, but – better in Java SE 6 – fairly negligible compared to the total running time – Java SE 6's splash screen API Myths 26

5. Java Isn't Supported On Games Consoles v This criticism has some justification. v Two important games platforms: – the PS 2 and Windows – Java isn't available on the PS 2 Myths continued 27

v Actually it is possible to run Java on the PS 2 using Sony's version of Linux, but: – the OS requires the PS 2 to have a hard disk – only limited access to hardware v Two trends that may help Java: – consoles are mutating into home media devices – the rise of online gaming Myths 28

Java on the PS 3? Probably Not v Basic/premium PS 3 versions will have – 512 MB of RAM, a large hard drive, Linux support, Open. GL v Casual games programming on the PS 3 – development kits in Spring 2007 – support for an object-oriented language u probably C++/C – virtual machine utilizes JIT technology Myths 29

Blu-ray Drives v Support a version of Java called BD-J for: – interactive menus, GUIs – networking applications Myths 30

Other Markets v The PC market is far from miniscule – US$ 953 million by the end of 2008 – over a billion in 2009 v Games on PCs – superior, modern hardware u video Myths cards, RAM, internet connections – more exciting game play – many more PC games, particularly in the area of multiplayer online games continued 31

v Mobile gaming – sales rising to US$ 2. 5 billion in 2007 – thought to be around 250 million Java-enabled phones – Java ME Myths 32

6. No One Uses Java To Write Real Games v The number of commercial Java games is small, but growing – won awards and bestsellers – e. g. Tribal Trouble, Puzzle Pirates, Call of Juarez, Chrome, Titan Attacks, Star Wars Galaxies, Runescape, Alien Flux, Kingdom of Wars, Law and Order II, Ultratron, Roboforge, IL-2 Sturmovik, Galactic Village, Wurm Online, . . . Myths continued 33

Myths 34

Myths 35

Myths 36

Myths 37

Casual Gaming Market v Java is used widely in the casual gaming market – game play is more innovative – implementation timelines are shorter – budgets smaller – less man-power needed v By 2008, the casual games market will surpass US$2 billion in the US. Myths 38

Many Java Gaming Sites v Sun Microsystems showcase – http: //www. java. com/en/games/ v Community pages – http: //community. java. net/games/ v Open-source gaming tools – https: //games. dev. java. net/ Myths continued 39

v The Java Games factory – http: //javagamesfactory. org/ v Works-in-progress – https: //games-forge. dev. java. net/ v Java. Gaming forums – http: //www. javagaming. org/ Myths 40

Java. Gaming. org v Best source of technical advice – over 9000 highly opinionated registered users v Discussion topics – Java 3 D, Java 2 D, Java Sound, J 2 ME, networking, online games development, performance tuning, JOGL, JOAL, JInput, and more Myths 41

Open-source Gaming Tools https: //games. dev. java. net/ v JOGL, a Java binding for Open. GL v JOAL, a binding for Open. AL (a 3 D audio library( v JInput, a game devices API v games-middleware and games-forge sections Myths 42

Books Myths continued 43

due out in May 2007 http: //fivedots. coe. psu. ac. th/~ad/jg Myths 44

. 7 Sun Isn't Interested v J 2 SE 1. 3 – improved graphics and audio capabilities v Version 1. 4 – full-screen mode and page flipping in hardware – faster I/O, memory mapping – support for non-block sockets u useful Myths in client/server multiplayer games continued 45

v Version 5. 0 – nanosecond timer v Java extension libraries, e. g. – Java 3 D – JMF (the Java Media Framework) – the Java Communications API – JAXP (Java’s peer-to-peer API) Myths continued 46

v Java SE 6 – improved graphics rendering speeds – splash screen API, scripting, desktop API v Sun-sponsored websites – http: //www. javagaming. org – http: //www. java. net – http: //community. java. net/games/ Myths 47

Sun's Project Dark. Star http: //games-darkstar. dev. java. net v Tools for supporting massive multi-player online games. – server side: Sun Game Server (SGS) – client APIs for C++, Java SE, and Java ME Myths 48

. 8 In a Nutshell v Java for games programming: are you joking? v No, Java is a great games programming language. Myths 49
