The Joints A Study in Motion

The Joints A Study in Motion

Joints are classified by structure and function. These can: q Fibrous Joints

Joints are classified by structure and function. These can: q Fibrous Joints

Joints are classified by structure and function. These can: q Fibrous Joints q Cartilaginous

Joints are classified by structure and function. These can: q Fibrous Joints q Cartilaginous Joints

Joints are classified by structure and function. These can: q Fibrous Joints q Cartilaginous

Joints are classified by structure and function. These can: q Fibrous Joints q Cartilaginous Joints q. Synovial Joints

Sutures (Fibrous Joints) These can be found connecting the plates of the skull. As

Sutures (Fibrous Joints) These can be found connecting the plates of the skull. As the plates fuse in the adult, the sutures are called synostoses and result in immovable joints.

Ligaments (Fibrous Joints) These can be found where bones are connected by ligaments. These

Ligaments (Fibrous Joints) These can be found where bones are connected by ligaments. These are called syndesmoses and result in amphiarthrotic joints (slightly moveable) joints or synarthrosis (not moveable). Examples would be the distal ends of the fibula and tibia.

Gomphotic Joints (Fibrous Joints) These are a peg and socket joint. The only example

Gomphotic Joints (Fibrous Joints) These are a peg and socket joint. The only example is the articulation of the tooth and its socket.

Cartilaginous Joints These are joints where the articulating bones are united by cartilage. There

Cartilaginous Joints These are joints where the articulating bones are united by cartilage. There is no joint cavity and mobility is limited. Most common examples are the first rib and manubrium and epiphyseal plates of the long bones. This is classified as a synchondronsis.

Cartilaginous Joints

Cartilaginous Joints

Cartilaginous Joints Another example is in symphyses (growing together). This is seen with joints

Cartilaginous Joints Another example is in symphyses (growing together). This is seen with joints containing fibrocartilage the vertebral disks and pubic symphsis

Synovial Joints The articulating bones are separated by a fluid containing cavity. These joints

Synovial Joints The articulating bones are separated by a fluid containing cavity. These joints are diarthrotic (most motion) and provide the greatest movement. They have 6 distinguishing features.

6 distinguishing features. 1. Articular cartilage that is approximately 1 mm thick and composed

6 distinguishing features. 1. Articular cartilage that is approximately 1 mm thick and composed of hyaline cartilage.

6 distinguishing features. 1. Articular cartilage that is approximately 1 mm thick and composed

6 distinguishing features. 1. Articular cartilage that is approximately 1 mm thick and composed of hyaline cartilage. 2. Synovial cavity that is a potential space containing a small amount of liquid.

6 distinguishing features. 1. Articular cartilage that is approximately 1 mm thick and composed

6 distinguishing features. 1. Articular cartilage that is approximately 1 mm thick and composed of hyaline cartilage. 2. Synovial cavity that is a potential space containing a small amount of liquid. 3. Articular capsule that is made of 2 layers.

6 distinguishing features. 1. Articular cartilage that is approximately 1 mm thick and composed

6 distinguishing features. 1. Articular cartilage that is approximately 1 mm thick and composed of hyaline cartilage. 2. Synovial cavity that is a potential space containing a small amount of liquid. 3. Articular capsule that is made of 2 layers. 4. Synovial fluid occupies the free space of the joint capsule.

6 distinguishing features. 1. Articular cartilage that is approximately 1 mm thick and composed

6 distinguishing features. 1. Articular cartilage that is approximately 1 mm thick and composed of hyaline cartilage. 2. Synovial cavity that is a potential space containing a small amount of liquid. 3. Articular capsule that is made of 2 layers. 4. Synovial fluid occupies the free space of the joint capsule. 5. Reinforcing ligaments provide additional structure to the joints

6 distinguishing features. 1. Articular cartilage that is approximately 1 mm thick and composed

6 distinguishing features. 1. Articular cartilage that is approximately 1 mm thick and composed of hyaline cartilage. 2. Synovial cavity that is a potential space containing a small amount of liquid. 3. Articular capsule that is made of 2 layers. 4. Synovial fluid occupies the free space of the joint capsule. 5. Reinforcing ligaments provide additional structure to the joints 6. Nerve and blood vessels supply

Figure 8. 3 General structure of a synovial joint. Ligament Joint cavity (contains synovial

Figure 8. 3 General structure of a synovial joint. Ligament Joint cavity (contains synovial fluid) Articular (hyaline) cartilage Fibrous capsule Articular Synovial capsule membrane Periosteum Copyright © 2010 Pearson Education, Inc.

Associated Structures Other structures commonly associated with synovial joints include fat pads and articular

Associated Structures Other structures commonly associated with synovial joints include fat pads and articular discs of fibrocartilage. They work like “ball bearings” and reduce friction where ligaments, tendons and muscles rub against each other.

Associated Structures Tendon Sheaths Bursae of the knee

Associated Structures Tendon Sheaths Bursae of the knee

Movement of Synovial Joints All skeletal muscles attach to bone or connective tissue by

Movement of Synovial Joints All skeletal muscles attach to bone or connective tissue by at least 2 points. – The Origin is the muscle attachment to the less movable bone – The Insertion is the muscle attachment to the movable bone.

3 general types of movement • Gliding • Angular • Rotational

3 general types of movement • Gliding • Angular • Rotational

Gliding motion is the simplest and consists of one bone sliding over another. This

Gliding motion is the simplest and consists of one bone sliding over another. This is seen with the intercarpal and intertarsal joints and between vertebrae

Figure 8. 5 a Movements allowed by synovial joints. Gliding (a) Gliding movements at

Figure 8. 5 a Movements allowed by synovial joints. Gliding (a) Gliding movements at the wrist Copyright © 2010 Pearson Education, Inc.

Angular movements increase or decrease the angle between 2 bones. Movements include: – Flexion

Angular movements increase or decrease the angle between 2 bones. Movements include: – Flexion – Extension – Hyperextension – Abduction – Adduction – Circumduction

a)Flexion is the bending along a sagittal plane; this decreases the angle of the

a)Flexion is the bending along a sagittal plane; this decreases the angle of the joint and brings the bones closer together. b) Extension is the straightening of bones resulting in the increase angle between bones. c) Hyperextension is the bending of a joint beyond anatomical position.

Figure 8. 5 b Movements allowed by synovial joints. Hyperextension Extension Flexion (b) Angular

Figure 8. 5 b Movements allowed by synovial joints. Hyperextension Extension Flexion (b) Angular movements: flexion, extension, and hyperextension of the neck Copyright © 2010 Pearson Education, Inc.

Figure 8. 5 c Movements allowed by synovial joints. Extension Hyperextension Flexion (c) Angular

Figure 8. 5 c Movements allowed by synovial joints. Extension Hyperextension Flexion (c) Angular movements: flexion, extension, and hyperextension of the vertebral column Copyright © 2010 Pearson Education, Inc.

Figure 8. 5 d Movements allowed by synovial joints. Flexion Extension (d) Angular movements:

Figure 8. 5 d Movements allowed by synovial joints. Flexion Extension (d) Angular movements: flexion and extension at the shoulder and knee Copyright © 2010 Pearson Education, Inc.

d) Abduction is moving away from the midline along the frontal plane. e) Adduction

d) Abduction is moving away from the midline along the frontal plane. e) Adduction is moving toward the midline. f) Circumduction is moving the limb to describe a cone, for example the motion made by a pitcher. This motion involves the motions described above.

Figure 8. 5 e Movements allowed by synovial joints. Abduction Adduction Circumduction (e) Angular

Figure 8. 5 e Movements allowed by synovial joints. Abduction Adduction Circumduction (e) Angular movements: abduction, adduction, and circumduction of the upper limb at the shoulder Copyright © 2010 Pearson Education, Inc.

Rotation Is the turning of the bone along its axis. This is seen with

Rotation Is the turning of the bone along its axis. This is seen with the first and second vertebrae and the hip and shoulder joint

Figure 8. 5 f Movements allowed by synovial joints. Rotation Lateral rotation Medial rotation

Figure 8. 5 f Movements allowed by synovial joints. Rotation Lateral rotation Medial rotation (f) Rotation of the head, neck, and lower limb Copyright © 2010 Pearson Education, Inc.

Special Movements Supination is the radius and ulna are parallel and the palms are

Special Movements Supination is the radius and ulna are parallel and the palms are facing forward. Pronation the radius and ulna form an X and the palms face posterior. (Think 3 P’spronation palms posterior).

Figure 8. 6 a Special body movements. Pronation (radius rotates over ulna) Supination (radius

Figure 8. 6 a Special body movements. Pronation (radius rotates over ulna) Supination (radius and ulna are parallel) (a) Pronation (P) and supination (S) Copyright © 2010 Pearson Education, Inc.

Dorsi flexion and plantar flexion are seen with the bending of the foot up

Dorsi flexion and plantar flexion are seen with the bending of the foot up and down. Bending the foot towards the tibia is dorsi flexion. Pointing the toes away is plantar flexion. This latter motion is seen with ballet dancers.

Figure 8. 6 b Special body movements. Dorsiflexion Plantar flexion (b) Dorsiflexion and plantar

Figure 8. 6 b Special body movements. Dorsiflexion Plantar flexion (b) Dorsiflexion and plantar flexion Copyright © 2010 Pearson Education, Inc.

Inversion/Eversion is medial and lateral movement of the ankle. Overextension or inversion is commonly

Inversion/Eversion is medial and lateral movement of the ankle. Overextension or inversion is commonly seen with the sprained ankle.

Figure 8. 6 c Special body movements. Inversion (c) Inversion and eversion Copyright ©

Figure 8. 6 c Special body movements. Inversion (c) Inversion and eversion Copyright © 2010 Pearson Education, Inc. Eversion

Protraction and Retraction are the anterior and posterior movement of the jaw. Protraction is

Protraction and Retraction are the anterior and posterior movement of the jaw. Protraction is the jutting out of the jaw.

Figure 8. 6 d Special body movements. Protraction of mandible Retraction of mandible (d)

Figure 8. 6 d Special body movements. Protraction of mandible Retraction of mandible (d) Protraction and retraction Copyright © 2010 Pearson Education, Inc.

Protraction and Retraction are the anterior and posterior movement of the jaw. Protraction is

Protraction and Retraction are the anterior and posterior movement of the jaw. Protraction is the jutting out of the jaw. Elevation and depression are the movement of the jaw in an inferior superior direction. (Opening and closing)

Figure 8. 6 e Special body movements. Elevation of mandible Depression of mandible (e)

Figure 8. 6 e Special body movements. Elevation of mandible Depression of mandible (e) Elevation and depression Copyright © 2010 Pearson Education, Inc.

Opposition is seen with touching of the thumb to the tips of the other

Opposition is seen with touching of the thumb to the tips of the other phalanges.

Figure 8. 6 f Special body movements. Opposition (f) Opposition Copyright © 2010 Pearson

Figure 8. 6 f Special body movements. Opposition (f) Opposition Copyright © 2010 Pearson Education, Inc.
