The Boundary layer concept Ludwig Prandtl 1875 -1953
Application of boundary layer control § Delay separation of the boundary layer § Increase the heat transfer rate
Techniques to reduce drag § Passive § Active § Compound
Some passive techniques Vortex generator Leading edge slat
Some active techniques suction boundary layer control Mobile surface
Electro-hydrodynamic method
Corona wind
airfoil under the influence of electric field Electrical potential charge density
stream line analyze V=0 kv H=1 cm V=15 kv H=0. 1 cm
The Cylinder under the influence of electric field
Re=100 Re=40 V=0 kv V=15 kv
- Slides: 13
