The 1 selling walkbehind mower from Exmark offering

The #1 selling walk-behind mower from Exmark, offering the productivity of a hydro mower with a full-floating deck and quick cutting height adjustment

Target Customer • Landscape contractors who require the very best in durability, maneuverability in tight locations, and quality-of-cut that only a hydro full-floating deck mower can provide.

Key Value Propositions • • • Performance Durability Ease of operation

Performance • Engine – Choice of 15 or 17 HP Kawasaki KAI V-Twin recoil engines, or 19 hp Kawasaki KAI V-Twin engines with electric start for 48” and 52” models – The KAI air filtration system keeps grass, dirt, etc from getting into engine which improves reliability and performance while reducing downtime

Performance • Fabricated commercial cutting deck – Patented Flow Control Baffles • Eliminates blowout and delivers our “see it to believe it” quality of cut • Reduce the amount of horsepower required while creating a superior vacuum that lifts the grass tall and straight for a clean, sharp cut • Concentrates the flow of air and forces grass clippings out to two and a half times the width of cut – Designed to give contractors the option to bag, mulch, or side-discharge – Height of cut range of 1. 0” - 4. 25”, and adjustable in. 25” increments

Performance • Full Floating Deck Design – Quick height adjustment system allows quick and easy cut height adjustments in the field without the need for tools – Four-point suspension system allows the deck to float from front to back and side to side, tracing the contours of the property to deliver superior striping and quality-of-cut – 6 anti-scalp rollers allow the deck to trace contours and reduce scalping – Cutting height range of 1. 5” to 4. 5” in 0. 5” increments

Performance • Hydro Drive System – Hydro-Gear 10 cc variable displacement pumps power highefficiency Parker wheel motors – Allows greater maneuverability and productivity • Eliminates belt slippage in wet or hilly conditions – Infinite ground speed up to 6. 20 mph forward and 2. 25 mph in reverse – No need to declutch to go from forward to reverse as required on a gear-drive unit – Recoil start engines standard with cold weather start kit • Isolates the engine from the hydro system which eliminates parasitic load of the hydro system during cold weather

Performance • Hydro Drive System continued. . – Patented hydro idler arm with spherical bearings minimizes maintenance and maintains superior spring tension to competitive designs that use traditional bushings and ball bearings – Patented Insta-Trak fine tunes the mower’s tracking while on the go with the simple turn of a knob

Durability • Fabricated commercial cutting deck – Constructed of 7 gauge steel on the side and 10 gauge steel for the top deck plate – Sides and top deck plate are joined by a continuous-bead weld that follows the entire edge – Design provides exceptional strength, eliminating stress on the unit, and adding additional life to the overall machine • • A rugged metal bumper protects from frontal impacts Flexible discharge chute – Considerably more durable than steel chutes as it keeps its shape after impacts and reduces the likelihood of damaged trees, bushes, fences, etc.

Durability • Tires – Large 16 x 7. 5 drive wheels on 48” and 52” models provide superior traction on inclines, get up easily over curbs, and minimize turf compaction – 9 x 3. 5 dual-yoke semi-pneumatic front castor wheels provide stability and also eliminate the hassle of flat tires

Ease of operation • Enhanced Stability, Reliability and Control – Large frame and wide tracking stance maximizes traction on side -hills compared to competitive machines – The clutching belt is easily adjusted by removing the hair-pin and turning the turnbuckle until the two guide pins are located directly across from one another – Spring loaded idlers provide maximum belt tension – Parking brake eliminates the units from moving around on trailers

Ease of operation • Enhanced Control System (ECS) – The ECS delivers the ultimate in walk-behind comfort and ease of operation – Provides operators with better visibility and control, keeping them centered in the safety zone – Cushioned handles and drive levers optimize comfort and reduce fatigue – Grip distance is reduced to allow operators with large or small hands to operate the drive levers – Topside and inward positioning of the controls keeps operator’s hands farther away from obstacles

Key Feature Fully fabricated 36, 48, and 52 inch commercial cutting decks Benefit Strength, diverse cut sizes and best-inclass quality of cut with the option to bag, mulch, or side-discharge Full-floating deck with four point suspension Easy height adjustment, follows contour of terrain for maximum cut quality Enhanced Control System (ECS) Ultimate design offers comfort and ease of operation 15, 17, and 19 hp Kawasaki KAI engines Commercial built engine provides plenty of horsepower to the deck 16 x 7. 50 Drive tires (48” and 52”) 16 x 6. 50 Drive tires (36” only) Large tires means superior tractions on side hills, simple navigation of curbs, and minimal turf compaction/marks Semi-pneumatic front caster wheels Eliminates flat tires and reduces downtime

Key Feature Benefit 10 cc Hydro-Gear pumps with Parker wheel motors Provides greater maneuverability, efficiency, and positive reverse while eliminating belt slippage Air filtration system Increased engine reliability and performance Heavy duty tractor design Provides greater traction on hills as well as greater durability than competitive models Hydro Idler arm with spherical bearings Greatly reduce friction compared to competitor’s traditional bushings and ball bearings. Reduce maintenance Flexible Discharge Chute More durable than steel chutes as it is designed to keep its shape after impacts

Models Model Overview Model Description THP 15 KA 363 15 HP Kawasaki KAI, ECS, 32” cutting deck THP 17 KA 483 17 HP Kawasaki KAI, ECS, 48” cutting deck THP 17 KA 523 17 HP Kawasaki KAI, ECS, 52” cutting deck THP 19 KAE 483 19 HP Kawasaki KAI, electric start, ECS, 48” cutting deck THP 19 KAE 523 19 HP Kawasaki KAI, electric start, ECS, 52” cutting deck

Accessories Exmark Accessories provide even greater profit opportunities for dealers! Mulch Kits Stand. On Sulky • Increases productivity by finely cutting grass, leaves and other debris and dispersing in lawn. • Great for areas where side discharge is not feasible and bagging is costly. • Increase productivity and rider comfort by adding the Exmark Stand. On Sulky. • Greater ability for operator to see out over deck. • Minimizes operator fatigue. • Greater durability and ease of attachment than competitive sulkies. Turf Striping Kits 3 -bushel grass catcher • Enhances the striping performance of the machine. • Attaches easily to the unit. • Catches clippings for easy disposal. • Attaches easily without the use of tools.
