The 1 hour Guide to Stuxnet Carey Nachenberg

The 1 -hour Guide to Stuxnet Carey Nachenberg Vice President, Symantec Fellow Symantec Corporation The 1 -hour Guide to Stuxnet 1

This is Natanz, Iran The 1 -hour Guide to Stuxnet 2

And these are Natanz’s Centrifuges The 1 -hour Guide to Stuxnet 3

Industrial control systems are typically controlled by a standard PC running industrial control software like STEP 7 from Siemens. Windows Programmable And this is how they’re controlled PC Logic Controller Communications Processors (Routers) STEP 7 Frequency Converters are responsible for converting AC The PLC is a specialized Communications frequencies to either higherpiece of hardware that Processors route or lower frequencies to orchestrates control of commands from the PLC operate motors. multiple connected to groups of mechanical devices. Centrifuges enrich Uranium . . . Frequency so it can be used to power Converters nuclear plants or weapons. . . . Centrifuges The 1 -hour Guide to Stuxnet 4

And this is how they’re isolated Windows Programmable PC Logic Controller Communications Processors (Routers) STEP 7 Research Network Frequency Converters . . . Centrifuges The 1 -hour Guide to Stuxnet 5

And this is (probably) Who wants an Israeli Mossad Programmer to introduce onto this computer right here The 1 -hour Guide to Stuxnet 6

So how exactly does this: Get onto an “air-gapped” network to disrupt these: It’s got to spread on its own… Until it discovers the proper computers… Where it can disrupt the centrifuges… All while evading detection. The 1 -hour Guide to Stuxnet 7

It’s got to spread on its own… Stuxnet uses seven distinct mechanisms to spread to new computers. Six of these attacks targeted flaws (back doors) that were unknown to the security industry and software vendors! ? 2. 0 It attacks a hole Peers update other Stuxnet uses thumb It attacks a hole It password-cracks It copies itself to It infects SIEMENS in Windows RPC. peers directly. drives to bridge the gap! in Windows’ print SIEMENS DB software. open file-shares. PLC data files. spooler. But if the centrifuges are air-gapped from the ‘net, Usually we’re surprised how can Stuxnet jump to when we see a threat the enrichment network? targeting one flaw. . . USB drives! The 1 -hour Guide to Stuxnet 8

Spreading – A Sidebar Windows has a built-in task scheduler system. Each user can add new tasks to be run at a certain time and with a certain permission level. (Regular users can’t add “root” level jobs) To prevent tampering, windows computes a CRC 32 hash for each task record and stores this in a protected area of the computer. (the tasks themselves are stored as globally readable/writable XML files) Windows Task #1: Job: Delete temp files Task #2: Run as: Root user Job: Clean registry Task #3: Run at: 10 pm Run as: Jim (non-root) Job: Print receipts Run at: 6 pm Run as: Ted (non-root) Run at: 2 am Task 1 hash: 9 B 7 CC 653 Task 2 hash: 11090343 Task 3 hash: 40910276 The 1 -hour Guide to Stuxnet 9

Spreading – A Sidebar When it arrives on a machine, Stuxnet starts running with non-administrator privileges. But to do its mischief, Stuxnet needs to run with “root” privileges. Windows Task #1: So first, Stuxnet creates a new task, Job: Delete temp files Task #2: using the permissions of the current user. Run as: Root user Job: Clean registry Task #3: Run at: 10 pm And of course, once Windows verifies that the job is Run as: Jim (non-root) legitimate (the user hasn’t tried to create a root. Job: Print receipts Run at: 6 pm level job), it calculates the job’s hash and adds it to Run as: Ted (non-root) the security store. Run at: 2 am Task #4: Job: Run stuxnet. dll Task 1 hash: 9 B 7 CC 653 Run as: Ted (non-root) Task 2 hash: 11090343 Run at: 2 pm Task 3 hash: 40910276 Task 4 hash: DE 9 DBA 76 The 1 -hour Guide to Stuxnet 10

Spreading – A Sidebar Next Stuxnet modifies the XML job file it just added, changing its permission to “root”! (Remember, the XML files are writable) But wait! The updated job Windows Tasks file hash no longer matches Ah, but Stuxnet is more clever than that. Task #1: the protected hash stored by Job: Delete temp files Stuxnet knows how to forge a CRC - it computes a set Task #2: Windows! Run as: Root user of values which, if appended to the file, will result in Job: Clean registry its CRC matching the original! And then it appends Task #3: Run at: 10 pm these bytes to the file! If Windows were to process Run as: Jim (non-root) Job: Print receipts Task #4: Run at: 6 pm the updated job file, it would Run as: Ted (non-root) And Windows will happily run the updated job, Job: Run stuxnet. dll detect this and reject it! Run at: 2 am giving Stuxnet root-level privileges! Ted (non-root) Run as: Ted (non-root) Root user Run at: 2 pm ! Y A D - O R ZE Task 1 hash: 9 B 7 CC 653 Task 2 hash: 11090343 Task 3 hash: 40910276 Task 4 hash: DE 9 DBA 76 The 1 -hour Guide to Stuxnet XQ New hash: DE 9 DBA 76 New hash: 66 C 35150 11

Until it discovers the proper computers… It’s got to spread on its own… Stuxnet is extremely picky and only activates its payload when it’s found an exact match. STEP 7 The targeted computer must be running STEP 7 software from Siemens. The targeted computer must be directly connected to an S 7 -315 Programmable Logic Controller from Siemens. The PLC must further be connected to at least six CP-342 -5 Network Modules from Siemens. Each Network Module must be connected to ~31 Fararo Paya or Vacon NX frequency converters. The 1 -hour Guide to Stuxnet … 12

Until it discovers the proper computers… Stuxnet is extremely picky and only activates its payload when it’s found an exact match. STEP 7 What a coincidence! Now if you do the math…. The creators of Stuxnet must have guessed all of these Stuxnet verifies that the discovered details. Programmable Logic Controller… Is controlling at least 155 total frequency converters… And recently we learned that Iran’s Uranium enrichment “cascade” just happens to use exactly 160 centrifuges. The 1 -hour Guide to Stuxnet … 13

Until it discovers the proper computers… Now Stuxnet gets down to business… Stuxnet starts by downloading malicious logic onto the PLC hardware. The 1 -hour Guide to Stuxnet What you (probably) didn’t realize is that the PLC uses a totally different microchip & computer language than Windows PCs. Stuxnet is the first known threat to target an industrial control microchip! 14

Now Stuxnet gets down to business… And makes sure the motors are running between 807 Hz and 1210 Hz. (This is coincidentally the frequency range required to run centrifuges. ) (After all, whoever wrote Stuxnet wouldn’t want it to take out a roller coaster or something. ) Next, Stuxnet measures the operating speed of the frequency converters during their normal operation for 13 days! The 1 -hour Guide to Stuxnet 15

Now Stuxnet gets down to business… Once it’s sure, the malicious PLC logic begins its mischief! Stuxnet raises the spin rate to 1410 Hz for 15 mins. Then sleeps for 27 days. Then slows the spin rate to 2 Hz for 50 mins. Then sleeps for 27 days. Stuxnet repeats this process over and over. 0 Hz The 1 -hour Guide to Stuxnet 1500 Hz 16

Now Stuxnet gets down to business… Why push the motors up to 1410 Hz? Well, ~1380 Hz is a resonance frequency. It is believed that operation at this frequency for even a few seconds will result in disintegration of the enrichment tubes! Why reduce the motors to 2 Hz? At such a low rotation rate, the vertical enrichment tubes will begin wobbling like a top (also causing damage). 0 Hz The 1 -hour Guide to Stuxnet 1500 Hz 17

Now Stuxnet gets down to business… What about Iranian failsafe systems? (Surely by now you’re thinking that alarm bells should have been blaring at the enrichment plant, right? ) Maybe Stuxnet pulled a mission impossible? !? The 1 -hour Guide to Stuxnet 18

Now Stuxnet gets down to business… And in fact, that’s exactly what Stuxnet did! 0 Hz The 1 -hour Guide to Stuxnet 1500 Hz Stuxnet records telemetry Well, in fact, these readings while the facilities typically do centrifuges are operating have fail-safe controls. normally. They trigger a shutdown And when it launches its if the frequency goes out attack, it sends this of the acceptable range. recorded data to fool the fail-safe systems! But worry not… Stuxnet takes care of And Stuxnet disables this too. the emergency kill switch on the PLC as well… Just in case someone tries to be a hero. 20

All while evading detection… Now Stuxnet gets down to business… Stuxnet uses five distinct mechanisms to conceal itself. #5 Stuxnet hides its own files on infected thumb drives using 2 “rootkits. ” The 1 -hour Guide to Stuxnet 21

All while evading detection. Stuxnet uses five distinct mechanisms to conceal itself. #4 Stuxnet inhibits different behaviors in the presence of different security products to avoid detection. Launch Attack A Launch Attack B Launch Attack C Launch Attack D The 1 -hour Guide to Stuxnet Launch Attack A Launch Attack B Launch Attack C Launch Attack D 22

All while evading detection. Stuxnet uses five distinct mechanisms to conceal itself. #3 Stuxnet completely deletes itself from USB keys after it has spread to exactly three new machines. The 1 -hour Guide to Stuxnet 23

All while evading detection. Stuxnet uses five distinct mechanisms to conceal itself. #2 Stuxnet’s authors “digitally signed” it with stolen digital certificates to make it look like it was created by well-known companies. Realtek The 1 -hour Guide to Stuxnet The two certificates were stolen from Real. Tek and Jmicron… …as it turns out, both companies are located less than 1 km apart in the same Taiwanese business park. 24

All while evading detection. Stuxnet uses five distinct mechanisms to conceal itself. #1 Stuxnet conceals its malicious “code” changes to the PLC from operational personnel (It hides its injected logic)! SIEMENS ration: e p o l a m or During n at 1064 hz Spin ergency: m e f o e s In ca n to 0 hz w o d in p S Instructions to the Centrifuges PLC During normal operation: Spin at 1410 hz In case of emergency: IGNORE OPERATOR COMMANDS (To centrifuges) The 1 -hour Guide to Stuxnet 25

Stuxnet Epidemiology The 1 -hour Guide to Stuxnet 26

Did It Succeed? Well, based on some clever Symantec engineering, we’ve got some interesting data. Fact: Stuxnet contacts two command-control servers every time it runs to report its status and check for commands. Working with registrars, Symantec took control of these Fact: As Stuxnet spreads between domains, forwarding all traffic computers, it keeps an internal log of every computer it’s visited. to our Symantec data centers. www. todaysfutbol. com www. mypremierfutbol. com The 1 -hour Guide to Stuxnet 27

Stuxnet Bookkeeping 27. 42. 97. 152 151. 21. 32. 19 151. 21. 32. 21 27. 42. 97. 152 151. 21. 32. 19 151. 21. 32. 21 93. 154. 11. 42 93. 154. 12. 78 Stuxnet embeds its “visited list” inside its own body as it spreads, enabling detailed forensics! The 1 -hour Guide to Stuxnet 28

Here’s What We Found The 1 -hour Guide to Stuxnet 29

Here’s What We Found (These graphs show the discovered samples spread) The 1 -hour Guide to Stuxnet 30

Here’s What We Found Data at time of discovery (July, 2010) The 1 -hour Guide to Stuxnet 31

Here’s What We Found Data at time of discovery (July, 2010) The 1 -hour Guide to Stuxnet 32

Did It Succeed? Indications are that it did! Symantec telemetry indicates that rather than directly trying to infiltrate Natanz… The attackers infected five industrial companies with potential subcontracting relationships with the plant. These companies (likely) then unknowingly ferried the infection into Natanz’s research and enrichment networks. The Institute for Science and International Security writes: “It is increasingly accepted that, in late 2009 or early 2010, Stuxnet destroyed about 1, 000 IR-1 centrifuges out of about 9, 000 deployed at the site. ” The 1 -hour Guide to Stuxnet 33

Whodunit? 19790509 According to Wikipedia, On May 9 th, 1979 “Habib Elghanian was executed by a firing squad in Tehran sending shock waves through the closely knit Iranian Jewish community. He was the first Jew and one of the first civilians to be executed by the new Islamic government. This prompted the mass exodus of the once 100, 000 member strong Jewish community of Iran which continues to this day. ” June 22, 2009 4: 31: 47 pm GMT June 22, 2009 6: 31: 47 pm Local GMT + 2 The 1 -hour Guide to Stuxnet 34

To Conclude Stuxnet has signaled a fundamental shift in the malware space. Stuxnet proves cyber-warfare against physical infrastructure is feasible. Unfortunately, the same techniques can be used to attack other physical and virtual systems. The 1 -hour Guide to Stuxnet 35
