THAWING INSTALLATION Product Management 2015 www vemaganlagenbau com
THAWING INSTALLATION © Product Management 2015 www. vemag-anlagenbau. com vertrieb@vemag-anlagenbau. de
Definition of a thawing process • • Unfreeze of meat or other products like fruit, vegetables or fish Temperature controlled process From e. g. -20°C (-4°F) to -1°C (+30°F) Or to a temperature for the following production steps like slicing or cutting © Product Management 2015 www. vemag-anlagenbau. com vertrieb@vemag-anlagenbau. de
Reason for thawing • Nearly 200 mio tons of meat are produced in the world every year • Apart from this about 20% will be frozen • Transport routes / export of meat from Brazil, Denmark, Germany, Canada Shelf life Hygienic requirements Just-in time production Taking advantage of good market prices • • © Product Management 2015 www. vemag-anlagenbau. com vertrieb@vemag-anlagenbau. de
Process © Product Management 2015 www. vemag-anlagenbau. com vertrieb@vemag-anlagenbau. de
Thawing process Zone I Heating of frozen product up to -5°C (23°F) 30 25 20 chamber temperature Zone II surface temperature Thawing and heating up to -1°C (30. 2°F) 15 temperature in °C 10 5 0 core temperature -5 Zone III Heating of thawed product of >+1°C (33. 8°F) -10 -15 -20 0 50 © Product Management 2015 100 150 time in minutes 200 250 www. vemag-anlagenbau. com 300 vertrieb@vemag-anlagenbau. de
Process scheme © Product Management 2015 www. vemag-anlagenbau. com vertrieb@vemag-anlagenbau. de
Flow conditions Suction duct Injection ducts © Product Management 2015 www. vemag-anlagenbau. com vertrieb@vemag-anlagenbau. de
Options Chamber by customer (ceramic plates on brick or PU-walls) © Product Management 2015 Metalchamber by VEMAG www. vemag-anlagenbau. com vertrieb@vemag-anlagenbau. de
Options Machine at rear wall © Product Management 2015 Machine on top www. vemag-anlagenbau. com vertrieb@vemag-anlagenbau. de
Boxes are not possible © Product Management 2015 www. vemag-anlagenbau. com vertrieb@vemag-anlagenbau. de
Open or packed products © Product Management 2015 www. vemag-anlagenbau. com vertrieb@vemag-anlagenbau. de
Control Systems and LDS © Product Management 2015 www. vemag-anlagenbau. com vertrieb@vemag-anlagenbau. de
Thawing with Microwaves Pros Cons Fast Only for small batches No bacteriological contamination High energy demand High investment costs Loss of quality, decomposition of proteins Different temperatures, partial overheating Cons are obvious © Product Management 2015 www. vemag-anlagenbau. com vertrieb@vemag-anlagenbau. de
Steak in a water bath © Product Management 2015 www. vemag-anlagenbau. com vertrieb@vemag-anlagenbau. de
Thawing in water bath Pros Cons Low investment costs Only for small batches Loss of quality „Washing out“ proteins and colour High water consumption High bacteriological contamination High weight loss Cons are obvious © Product Management 2015 www. vemag-anlagenbau. com vertrieb@vemag-anlagenbau. de
© Product Management 2015 www. vemag-anlagenbau. com vertrieb@vemag-anlagenbau. de
VEMAG – Thawing by means of air Pros Cons No bacterial contamination Min. weight loss No „washing out“ and min. loss of proteines Low investment costs Installations are designed individually No loss of quality The advantages are obvious © Product Management 2015 www. vemag-anlagenbau. com vertrieb@vemag-anlagenbau. de
The VEMAG way • • Wrapped products we have a weight loss of around 1% (depending on product, water injections, freezing process) Uncontrolled thawing at the air will be at least 2 -3 % for meat and fish 9 trolleys à 600 kg Meat price 3€/kg Batch time 10 – 12 hours A difference of 1, 5% weight loss sums up to 243€/day, i. e. 60. 750€/year © Product Management 2015 www. vemag-anlagenbau. com vertrieb@vemag-anlagenbau. de
Basic data Basic information is needed such as • Block dimension • Product information • Fat content • Max. surface temperature • Start temperature • Final temperature (core) © Product Management 2015 www. vemag-anlagenbau. com vertrieb@vemag-anlagenbau. de
Basic data • © Product Management 2015 www. vemag-anlagenbau. com Maximum load for different block dimensions vertrieb@vemag-anlagenbau. de
Temporary solution needed? © Product Management 2015 www. vemag-anlagenbau. com vertrieb@vemag-anlagenbau. de
Mobile Thawing Installation © Product Management 2015 www. vemag-anlagenbau. com vertrieb@vemag-anlagenbau. de
Mobile Thawing Installation • • © Product Management 2015 www. vemag-anlagenbau. com Worldwide movable Movement by ship, rail, truck… Plug and play with only few connections Same performance and quality as the tried and tested Thawing Installation vertrieb@vemag-anlagenbau. de
Basic data • • © Product Management 2015 40‘‘ high cube container 9 trolleys à 750 kg 6. 750 kg/batch Packed products in blocks e. g. 600 x 400 x 150 (lxwxh) Time: 10 – 12 hours Use as a storage room www. vemag-anlagenbau. com vertrieb@vemag-anlagenbau. de
Basic data Inner dimensions l = 11. 185 mm w = 2. 286 mm h = 2. 520 mm © Product Management 2015 www. vemag-anlagenbau. com Outer dimensions (12. 192 mm) (2. 438 mm) (2. 896 mm) vertrieb@vemag-anlagenbau. de
