Teroco Windows & Doors Ltd Unit B 1, Riverview Business Park Nangor Road DUBLIN 12 IRELAND Quotation no. : Requisition no. : 16. 10. 2018 Page 1 Delivery week: 20050233 Your contact: Reference: of 20 Customer no. / Your VAT no. : 0001010027/543499 Telephone no. : Terms of delivery: Trailer with lift Delivery address: Teroco Windows & Doors Ltd Unit B 1, Riverview Business Park Nangor Road DUBLIN 12 IRELAND Delivery information: Contact + Phone rel. to delivery: QUOTATION Project: 40033958/QTE 1985 Our quotation allows for the supply only of windows and doors all as detailed in the following quotation. · Our quotation is exclusive of VAT. · Our price provides for delivery to site on a 40 ft curtain sided trailer. · Additional methods of delivery will be subject to additional costs. · Attached is a schedule which details each individual window type included in our quotation. It includes dimensions, reference and precisely what components have been allowed for in our price. Copies have been attached with and without prices. We trust that our quotation meets with your approval, and we are looking forward to hearing from you. Project Coordinator: Shirley Tutty Tel. : +353 1 450 7984 E-Mail: STU@VELFAC. IE Sales Person: Shirley Tutty Tel. : +353 1 450 7984 E-Mail: STU@VELFAC. IE VELFAC A/S | Bygholm Søpark 23 | DK-8700 Horsens | Tel. : +45 7011 0200 | Reg. no: 24347214 | VAT no. : DK 24347214

16. 10. 2018 Quotation no. : Project name: Page 20050233 QTE 1985 2 / 20 Elevations are always seen from the outside. General unless otherwise stated: System VELFAC 200 Energy Frame depth 114 mm Mullion/transom depth 114 mm Sash profile Sash for 48 mm glazing Alu colour, sash externally undecided RAL colour Glazing bead RAL 9010 Pure White Wood colour, frame internally RAL 9010 Pure White Operation Handle Glazing/panel 4 -18 -4 Energy Std/Clear/Energy Std WE Grey W/Argon U= 0, 53 W 01 Pos 10 VELFAC 200 Energy 1 PC Element size (Wx. H) 2400 mm X 500 mm Frame depth 114, 0 mm Element depth 149 mm Cill Standard window cill Sash 1 Opening function Sidehung window Opening direction Left opening Sash size (Wx. H) 594, 0 mm X 500, 0 mm Sash 2 Opening function Fixed casement Sash size (Wx. H) 594, 0 mm X 500, 0 mm Sash 3 Opening function Fixed casement Sash size (Wx. H) 594, 0 mm X 500, 0 mm Sash 4 Opening function Sidehung window Opening direction Right opening Sash size (Wx. H) 594, 0 mm X 500, 0 mm Element weight 56 kg W 02 Pos 20 VELFAC 200 Energy 4 PC Element size (Wx. H) 850 mm X 2300 mm Frame depth 114, 0 mm Element depth 149 mm Cill Standard window cill Sash 1 Opening function Fixed casement Glazing/panel 4 -18 -4 Energy Std Tgh Safe/Clear/Energy Std Tgh Safe WE Grey. W/Argon U= 0, 53 VELFAC A/S | Bygholm Søpark 23 | DK-8700 Horsens | Tel. : +45 7011 0200 | Reg. no: 24347214 | VAT no. : DK 24347214

16. 10. 2018 Quotation no. : Project name: Page 20050233 QTE 1985 3 / 20 Sash size (Wx. H) 850, 0 mm X 2300, 0 mm Element weight 73 kg Comment: Opening changed because the item was too large. W 02 - ALTERNATIVE Pos 30 VELFAC 200 Energy 4 PC Element size (Wx. H) 850 mm X 2300 mm Frame depth 114, 0 mm Element depth 149 mm Cill Standard window cill Sash 1 Opening function Top-guided window Sash size (Wx. H) 850, 0 mm X 1596, 0 mm Accessories Locking device, secondary Circular Sash 2 Opening function Fixed casement Glazing/panel 4 -18 -4 Energy Std Tgh Safe/Clear/Energy Std Tgh Safe WE Grey. W/Argon U= 0, 53 Sash size (Wx. H) 850, 0 mm X 696, 0 mm Element weight 77 kg W 03 Pos 40 VELFAC 200 Energy 1 PC Element size (Wx. H) 2400 mm X 2300 mm Frame depth 114, 0 mm Element depth 149 mm Cill Standard window cill Sash 1 Opening function Fixed casement Sash size (Wx. H) 1196, 0 mm X 761, 3 mm Sash 2 Opening function Top-guided window Sash size (Wx. H) 1196, 0 mm X 761, 3 mm Sash 3 Opening function Fixed casement Glazing/panel 4 -18 -4 Energy Std Tgh Safe/Clear/Energy Std Tgh Safe WE Grey. W/Argon U= 0, 53 Sash size (Wx. H) 1196, 0 mm X 761, 3 mm Sash 4 Opening function Fixed casement Sash size (Wx. H) 1196, 0 mm X 761, 3 mm Sash 5 Opening function Top-guided window VELFAC A/S | Bygholm Søpark 23 | DK-8700 Horsens | Tel. : +45 7011 0200 | Reg. no: 24347214 | VAT no. : DK 24347214

16. 10. 2018 Quotation no. : Project name: Page 20050233 QTE 1985 4 Sash size (Wx. H) / 20 1196, 0 mm X 761, 3 mm Sash 6 Opening function Fixed casement Glazing/panel 4 -18 -4 Energy Std Tgh Safe/Clear/Energy Std Tgh Safe WE Grey. W/Argon U= 0, 53 Sash size (Wx. H) 1196, 0 mm X 761, 3 mm Element weight 221 kg W 04 Pos 50 VELFAC 200 Energy 2 PC Element size (Wx. H) 2000 mm X 270 0 mm Frame depth 114, 0 mm Element depth 149 mm Cill Standard windo w cill Sash 1 Opening function Fixed casement Sash size (Wx. H) 2000, 0 mm X 11 61, 4 mm Sash 2 Opening function Top-guided win dow Sash size (Wx. H) 996, 0 mm X 761 , 3 mm Sash 3 Opening function Fixed casement Glazing/panel 4 -18 -4 Energy Std Tgh Safe/Clear/Ener gy Std Tgh Safe WE Grey. W/ Argon U= 0, 53 Sash size (Wx. H) 2000, 0 mm X 76 1, 3 mm Sash 4 Opening function Top-guided win dow Sash size (Wx. H) 996, 0 mm X 761 , 3 mm Element weight 206 kg Comment: Configuration changed because the item was too large. W 05 Pos 60 VELFAC 200 Energy 1 PC Element size (Wx. H) 600 mm X 2300 mm Frame depth 114, 0 mm Element depth 149 mm Cill Standard window cill Sash 1 Opening function Fixed casement Glazing/panel 4 -18 -4 Energy Std Tgh Safe/Clear/Energy Std Tgh Safe WE Grey. W/Argon U= 0, 53 VELFAC A/S | Bygholm Søpark 23 | DK-8700 Horsens | Tel. : +45 7011 0200 | Reg. no: 24347214 | VAT no. : DK 24347214

16. 10. 2018 Quotation no. : Project name: Page 20050233 QTE 1985 5 / 20 Sash size (Wx. H) 600, 0 mm X 2300, 0 mm Element weight 54 kg Comment: Opening changed because the item was too large. W 05 - ALTERNATIVE Pos 70 VELFAC 200 Energy 1 PC Element size (Wx. H) 600 mm X 2300 mm Frame depth 114, 0 mm Element depth 149 mm Cill Standard window cill Sash 1 Opening function Top-guided window Sash size (Wx. H) 600, 0 mm X 1596, 0 mm Accessories Locking device, secondary Circular Sash 2 Opening function Fixed casement Glazing/panel 4 -18 -4 Energy Std Tgh Safe/Clear/Energy Std Tgh Safe WE Grey. W/Argon U= 0, 53 Sash size (Wx. H) 600, 0 mm X 696, 0 mm Element weight 57 kg W 06 Pos 80 VELFAC 200 Energy 1 PC Element size (Wx. H) 2000 mm X 1850 mm Frame depth 114, 0 mm Element depth 149 mm Cill Standard window cill Sash 1 Opening function Fixed casement Glazing/panel 4 -18 -4 Energy Std Tgh Safe/Clear/Energy Std Tgh Safe WE Grey. W/Argon U= 0, 53 Sash size (Wx. H) 996, 0 mm X 1850, 0 mm Sash 2 Opening function Sidehung window Opening direction Right opening Glazing/panel 4 -18 -4 Energy Std Tgh Safe/Clear/Energy Std Tgh Safe WE Grey. W/Argon U= 0, 53 Sash size (Wx. H) 996, 0 mm X 1850, 0 mm Element weight 137 kg VELFAC A/S | Bygholm Søpark 23 | DK-8700 Horsens | Tel. : +45 7011 0200 | Reg. no: 24347214 | VAT no. : DK 24347214

16. 10. 2018 Quotation no. : Project name: Page 20050233 QTE 1985 6 / 20 W 07 Pos 90 VELFAC 200 Energy 1 PC Element size (Wx. H) 600 mm X 750 mm Frame depth 114, 0 mm Element depth 149 mm Cill Standard window cill Sash 1 Opening function Sidehung window Opening direction Right opening Glazing/panel 4 -18 -4 Energy Std/Satin Acid Etched/Energy Std WE Grey W/Argon U= 0, 53 Sash size (Wx. H) 600, 0 mm X 750, 0 mm Element weight 19 kg W 08/1 Pos 100 VELFAC 200 Energy 2 PC Element size (Wx. H) 600 mm X 1504 mm Frame depth 114, 0 mm Element depth 149 mm Cill Standard window cill Sash 1 Opening function Fixed casement Sash size (Wx. H) 600, 0 mm X 748, 0 mm Sash 2 Opening function Top-guided window Sash size (Wx. H) 600, 0 mm X 748, 0 mm Element weight 39 kg W 08/2 Pos 110 VELFAC 200 Energy 2 PC Element size (Wx. H) 600 mm X 2276 mm Frame depth 114, 0 mm Element depth 149 mm Cill Standard window cill Sash 1 Opening function Fixed casement Glazing/panel 4 -18 -4 Energy Std/Clear/Energy Std Tgh Safe WE Grey W/Argon U= 0, 53

16. 10. 2018 Quotation no. : Project name: Page 20050233 QTE 1985 7 / 20 W 08/3 Pos 120 VELFAC 200 Energy 2 PC Element size (Wx. H) 600 mm X 1504 mm Frame depth 114, 0 mm Element depth 149 mm Cill Standard window cill Sash 1 Opening function Top-guided window Sash size (Wx. H) 600, 0 mm X 748, 0 mm Sash 2 Opening function Fixed casement Glazing/panel 4 -18 -4 Energy Std Tgh Safe/Clear/Energy Std Tgh Safe WE Grey. W/Argon U= 0, 53 Sash size (Wx. H) 600, 0 mm X 748, 0 mm Element weight 39 kg W 09 Pos 130 VELFAC 200 Energy 2 PC Element size (Wx. H) 2000 mm X 240 0 mm Frame depth 114, 0 mm Element depth 149 mm Cill Standard windo w cill Sash 1 Opening function Fixed casement Sash size (Wx. H) 2000, 0 mm X 86 1, 4 mm Sash 2 Opening function Top-guided win dow Sash size (Wx. H) 996, 0 mm X 761 , 3 mm Sash 3 Opening function Fixed casement Glazing/panel 4 -18 -4 Energy Std Tgh Safe/Clear/Ener gy Std Tgh Safe WE Grey. W/ Argon U= 0, 53 Sash size (Wx. H) 2000, 0 mm X 76 1, 3 mm Sash 4 Opening function Top-guided win dow Sash size (Wx. H) 996, 0 mm X 761 , 3 mm Element weight 187 kg Comment: Configuration changed because the item was too large. VELFAC A/S | Bygholm Søpark 23 | DK-8700 Horsens | Tel. : +45 7011 0200 | Reg. no: 24347214 | VAT no. : DK 24347214

16. 10. 2018 Quotation no. : Project name: Page 20050233 QTE 1985 8 / 20 W 10 Pos 140 VELFAC 200 Energy 1 PC Element size (Wx. H) 1000 mm X 1050 mm Frame depth 114, 0 mm Element depth 149 mm Cill Standard window cill Sash 1 Opening function Sidehung window Opening direction Right opening Glazing/panel 4 -18 -4 Energy Std/Satin Acid Etched/Energy Std WE Grey W/Argon U= 0, 53 Sash size (Wx. H) 1000, 0 mm X 1050, 0 mm Element weight 41 kg W 11 Pos 150 VELFAC 200 Energy 2 PC Element size (Wx. H) 800 mm X 800 mm Frame depth 114, 0 mm Element depth 149 mm Cill Standard window cill Sash 1 Opening function Top-guided window Sash size (Wx. H) 800, 0 mm X 800, 0 mm Element weight 26 kg W 12 Pos 160 VELFAC 200 Energy 1 PC Element size (Wx. H) 1000 mm X 1500 mm Frame depth 114, 0 mm Element depth 149 mm Cill Standard window cill Sash 1 Opening function Sidehung window Opening direction Right opening Glazing/panel 4 -18 -4 Energy Std/Satin Acid Etched/Energy Std WE Grey W/Argon U= 0, 53 Sash size (Wx. H) 1000, 0 mm X 1500, 0 mm Element weight 56 kg VELFAC A/S | Bygholm Søpark 23 | DK-8700 Horsens | Tel. : +45 7011 0200 | Reg. no: 24347214 | VAT no. : DK 24347214

16. 10. 2018 Quotation no. : Project name: Page 20050233 QTE 1985 9 / 20 W 13 Pos 170 VELFAC 200 Energy 2 PC Element size (Wx. H) 2000 mm X 135 0 mm Frame depth 114, 0 mm Element depth 149 mm Cill Standard windo w cill Sash 1 Opening function Sidehung windo w Opening direction Left opening Sash size (Wx. H) 996, 0 mm X 135 0, 0 mm Sash 2 Opening function Fixed casement Sash size (Wx. H) 996, 0 mm X 135 0, 0 mm Element weight 102 kg Comment: Configuration changed because the item was too small. W 14 Pos 180 VELFAC 200 Energy 1 PC Element size (Wx. H) 800 mm X 1350 mm Frame depth 114, 0 mm Element depth 149 mm Cill Standard window cill Sash 1 Opening function Sidehung window Opening direction Right opening Sash size (Wx. H) 800, 0 mm X 1350, 0 mm Element weight 42 kg D 01/1 Pos 190 VELFAC 200 Energy 1 PC Element size (Wx. H) 1392 mm X 1453 mm Frame depth 114, 0 mm Element depth 149 mm Cill Standard window cill Sash 1 Opening function Fixed casement Sash size (Wx. H) 1392, 0 mm X 1453, 0 mm Glazing bar colour, internally GRANITE 01 White 9010 Energy glazing bar 54 mm Glazing bar height 1 1050, 00 mm Element weight 52 kg VELFAC A/S | Bygholm Søpark 23 | DK-8700 Horsens | Tel. : +45 7011 0200 | Reg. no: 24347214 | VAT no. : DK 24347214

16. 10. 2018 Quotation no. : Project name: Page 20050233 QTE 1985 10 / 20 D 01/2 Pos 200 VELFAC 200 Energy 1 PC Element size (Wx. H) 1200 mm X 1876 mm Frame depth 114, 0 mm Element depth 149 mm Cill Standard window cill Sash 1 Opening function Fixed casement Sash size (Wx. H) 1200, 0 mm X 1876, 0 mm Glazing bar colour, internally GRANITE 01 White 9010 Energy glazing bar 54 mm Glazing bar height 1 480, 00 mm Glazing bar height 2 1473, 00 mm Element weight 72 kg D 01/3 Pos 210 VELFAC 200 Energy 1 PC Element size (Wx. H) 1392 mm X 1453 mm Frame depth 114, 0 mm Element depth 149 mm Cill Standard window cill Sash 1 Opening function Fixed casement Sash size (Wx. H) 1392, 0 mm X 1453, 0 mm Glazing bar colour, internally GRANITE 01 White 9010 Energy glazing bar 54 mm Glazing bar height 1 1050, 00 mm Element weight 52 kg D 01/4 Pos 220 VELFAC 200 Energy 2 PC Element size (Wx. H) 1392 mm X 2296 mm Frame depth 114, 0 mm Element depth 149 mm Cill Standard window cill Sash 1 Opening function Fixed casement Glazing/panel 4 -18 -4 Energy Std Tgh Safe/Clear/Energy Std Tgh Safe WE Grey. W/Argon U= 0, 53 Sash size (Wx. H) 1392, 0 mm X 2296, 0 mm Glazing bar colour, internally GRANITE 01 White 9010 Energy glazing bar 54 mm Glazing bar height 1 774, 33 mm Glazing bar height 2 1521, 67 mm Element weight 113 kg VELFAC A/S | Bygholm Søpark 23 | DK-8700 Horsens | Tel. : +45 7011 0200 | Reg. no: 24347214 | VAT no. : DK 24347214

16. 10. 2018 Quotation no. : Project name: Page 20050233 QTE 1985 11 / 20 D 01/5 Pos 230 VELFAC Ribo alu 2 1 PC Element size (Wx. H) 1200 mm X 2296 mm Frame depth 148, 0 mm Sash profile Sash for 52 mm glazing Alu colour, frame externally undecided RAL colour Colour, alu glazing bead ext. undecided RAL colour Wood colour, sash internally RAL 9010 Pure White Cill Low threshold Profile at head Coupling profile Profile at left jamb Cover profile Profile at right jamb Cover profile Sash 1 Opening function Glazed entrance door outward Opening direction Right opening Glazing/panel 4 -20 -4 Energy Std Tgh Safe/Clear/Energy Std Tgh Safe WE Grey. W/Argon U= 0, 53 Sash size (Wx. H) 1137, 2 mm X 2252, 8 mm Glazing bar 68 mm Glazing bar height 1 777, 13 mm Glazing bar height 2 1527, 27 mm Accessories Lockbox 3 -point lock, standard Element weight 96 kg Free width, element 1028 mm D 02/1 Pos 240 VELFAC 200 Energy 2 PC Element size (Wx. H) 1807 mm X 2300 mm Frame depth 114, 0 mm Element depth 149 mm Placement guiding rail At head (frame) Cill 70 mm threshold, no tread-plate Sash 1 Opening function Sliding casement door Opening direction Fixed left sash, sliding door Glazing/panel 6 -16 -6 -14 -6 Energy Std Tgh Safe/Clear/Energy Std Tgh Safe WE Grey. W/Argon U= 0, 61 Sash size (Wx. H) 1807, 0 mm X 2282, 0 mm Glazing bar colour, internally GRANITE 01 White 9010 Energy glazing bar 54 mm Glazing bar height 1 769, 67 mm Glazing bar height 2 1512, 33 mm Element weight 205 kg VELFAC A/S | Bygholm Søpark 23 | DK-8700 Horsens | Tel. : +45 7011 0200 | Reg. no: 24347214 | VAT no. : DK 24347214

16. 10. 2018 Quotation no. : Project name: Page 20050233 QTE 1985 12 / 20 D 02/2 Pos 250 VELFAC 200 Energy 2 PC Element size (Wx. H) 1485 mm X 2300 mm Frame depth 114, 0 mm Element depth 149 mm Placement guiding rail At head (frame) Cill 70 mm threshold w/tread-plate Sash 1 Opening function Sliding casement door Opening direction Towards left Glazing/panel 4 -18 -4 Energy Std Tgh Safe/Clear/Energy Std Tgh Safe WE Grey. W/Argon U= 0, 53 Sash size (Wx. H) 1485, 0 mm X 2282, 0 mm Glazing bar colour, internally GRANITE 01 White 9010 Energy glazing bar 54 mm Glazing bar height 1 769, 67 mm Glazing bar height 2 1512, 33 mm Accessories Locking device, secondary Handle Element weight 132 kg External cup handle is included as a separate unit D 03/1 Pos 260 VELFAC 200 Energy 5 PC Element size (Wx. H) 996 mm X 2300 mm Frame depth 114, 0 mm Element depth 149 mm Placement guiding rail At head (frame) Cill 70 mm threshold w/tread-plate Sash 1 Opening function Sliding casement door Opening direction Towards right Glazing/panel 4 -18 -4 Energy Std Tgh Safe/Clear/Energy Std Tgh Safe WE Grey. W/Argon U= 0, 53

16. 10. 2018 Quotation no. : Project name: Page 20050233 QTE 1985 13 / 20 D 03/2 Pos 270 VELFAC 200 Energy 5 PC Element size (Wx. H) 996 mm X 2300 mm Frame depth 114, 0 mm Element depth 149 mm Placement guiding rail At head (frame) Cill 70 mm threshold, no tread-plate Sash 1 Opening function Sliding casement door Opening direction Fixed right sash, sliding door Glazing/panel 4 -18 -4 Energy Std Tgh Safe/Clear/Energy Std Tgh Safe WE Grey. W/Argon U= 0, 53

16. 10. 2018 Quotation no. : Project name: Page 20050233 QTE 1985 14 Element weight 41 kg Free width, element 722 mm / 20 D 05/1 Pos 290 VELFAC 200 Energy 1 PC Element size (Wx. H) 2943 mm X 496 mm Frame depth 114, 0 mm Element depth 149 mm Cill Standard window cill Sash 1 Opening function Fixed casement Glazing/panel 6 -16 -6 -14 -6 Energy Std/Clear/Energy Std WE Grey W/Argon U= 0, 61 Sash size (Wx. H) 2943, 0 mm X 496, 0 mm Element weight 81 kg D 05/2 Pos 300 VELFAC 200 Energy 1 PC Element size (Wx. H) 400 mm X 2496 mm Frame depth 114, 0 mm Element depth 149 mm Cill Standard window cill Sash 1 Opening function Fixed casement Glazing/panel 4 -18 -4 Energy Std Tgh Safe/Clear/Energy Std Tgh Safe WE Grey. W/Argon U= 0, 53 Sash size (Wx. H) 400, 0 mm X 2496, 0 mm Element weight 43 kg Comment: Dimension changed because the item was too small. D 05/3 Pos 310 VELFAC Ribo alu 2 1 PC Element size (Wx. H) 1000 mm X 2496 mm Frame depth 148, 0 mm Sash profile Sash for 52 mm glazing Alu colour, frame externally undecided RAL colour Colour, alu glazing bead ext. undecided RAL colour Wood colour, sash internally RAL 9010 Pure White Cill Low threshold Profile at head Coupling profile Profile at left jamb Cover profile Profile at right jamb Cover profile Sash 1 Opening function Glazed entrance door inward Opening direction Right opening VELFAC A/S | Bygholm Søpark 23 | DK-8700 Horsens | Tel. : +45 7011 0200 | Reg. no: 24347214 | VAT no. : DK 24347214

16. 10. 2018 Quotation no. : Project name: Page 20050233 QTE 1985 15 Glazing/panel / 20 4 -20 -4 Energy Std Tgh Safe/Clear/Energy Std Tgh Safe WE Grey. W/Argon U= 0, 53 Sash size (Wx. H) 938, 2 mm X 2454, 6 mm Accessories Lockbox 3 -point lock, standard Element weight 88 kg Free width, element 821 mm D 05/4 Pos 320 VELFAC 200 Energy 1 PC Element size (Wx. H) 1523 mm X 2496 mm Frame depth 114, 0 mm Element depth 149 mm Cill Standard window cill Sash 1 Opening function Fixed casement Glazing/panel 4 -18 -4 Energy Std Tgh Safe/Clear/Energy Std Tgh Safe WE Grey. W/Argon U= 0, 53 Sash size (Wx. H) 1523, 0 mm X 2496, 0 mm Glazing bar colour, internally GRANITE 01 White 9010 Energy glazing bar 54 mm Glazing bar height 1 964, 00 mm Glazing bar height 2 1780, 00 mm Element weight 132 kg D 05/5 Pos 330 VELFAC 200 Energy 1 PC Element size (Wx. H) 2693 mm X 1496 mm Frame depth 114, 0 mm Element depth 149 mm Cill Standard window cill Sash 1 Opening function Fixed casement Glazing/panel 6 -16 -6 -14 -6 Energy Std/Clear/Energy Std WE Grey W/Argon U= 0, 61 Sash size (Wx. H) 2693, 0 mm X 496, 0 mm Sash 2 Opening function Fixed casement Glazing/panel 6 -16 -6 -14 -6 Energy Std/Clear/Energy Std WE Grey W/Argon U= 0, 61 Sash size (Wx. H) 2693, 0 mm X 992, 0 mm Element weight 213 kg VELFAC A/S | Bygholm Søpark 23 | DK-8700 Horsens | Tel. : +45 7011 0200 | Reg. no: 24347214 | VAT no. : DK 24347214

16. 10. 2018 Quotation no. : Project name: Page 20050233 QTE 1985 16 / 20 D 05/6 Pos 340 VELFAC 200 Energy 1 PC Element size (Wx. H) 2693 mm X 1496 mm Frame depth 114, 0 mm Element depth 149 mm Cill Standard window cill Sash 1 Opening function Top-guided window Sash size (Wx. H) 1342, 5 mm X 744, 0 mm Sash 2 Opening function Fixed casement Glazing/panel 6 -16 -6 -14 -6 Energy Std Tgh Safe/Clear/Energy Std Tgh Safe WE Grey. W/Argon U= 0, 61 Sash size (Wx. H) 2693, 0 mm X 744, 0 mm Sash 3 Opening function Top-guided window Sash size (Wx. H) 1342, 5 mm X 744, 0 mm Element weight 186 kg Pos 350 622933 Door Handle 3 PC Pos 360 661900 SC/KE Cylinder 660 different key 3 PC Pos 370 832894 Packed 2 c+2 d for single 2 PC Pos 380 832895 Packed 7 c+2 d for single 1 PC Pos 400 VELFAC 200 Energy 1 PC Pos 420 Timber component 90° corner post, type A 2016 Wood colour RAL 9010 Pure White Profile length 3000 mm A-dimension 121, 0 mm B-dimension 121, 0 mm C-dimension 103, 0 mm D-dimension 103, 0 mm VELFAC 200 Energy 1 PC Aluminium profile 90° corner pressing type A 1004 Alumunium colour undecided RAL colour Profile length 3000 mm Aluminium plate thickness 1, 5 mm Screw holes Not included VELFAC A/S | Bygholm Søpark 23 | DK-8700 Horsens | Tel. : +45 7011 0200 | Reg. no: 24347214 | VAT no. : DK 24347214

16. 10. 2018 Quotation no. : Project name: Page 20050233 QTE 1985 17 Pos 430 Aluminium fold back Not folded A-dimension 145, 0 mm B-dimension 145, 0 mm C-dimension 34, 5 mm D-dimension 11, 5 mm A 2550 -R 9010 White coupling 8 mm for 90 fram / 20 16 PC The project contains 462 linear meters of frames. Calculated from this there are 68 linear meters of window cills. VELFAC A/S | Bygholm Søpark 23 | DK-8700 Horsens | Tel. : +45 7011 0200 | Reg. no: 24347214 | VAT no. : DK 24347214

16. 10. 2018 Quotation no. : Project name: Page 20050233 QTE 1985 18 / 20 GENERAL CONDITIONS For general terms please follow the following link: www. velfac. ie/GENERALCONDITIONSOFSALE Applies to Ireland only. Other markets please separate general terms of sales and delivery VELFAC A/S | Bygholm Søpark 23 | DK-8700 Horsens | Tel. : +45 7011 0200 | Reg. no: 24347214 | VAT no. : DK 24347214

16. 10. 2018 Quotation no. : Project name: Page 20050233 QTE 1985 19 / 20 DATASHEET, ENERGY CONDITIONS Pos. Alt. Reference Qty A Uw Ff Gg LTg System Ew FSC® 10 W 01 1 1. 20 1. 17 0. 63 0. 53 0. 74 VELFAC 200 Energy ● 20 W 02 4 7. 84 0. 85 0. 83 0. 53 0. 73 VELFAC 200 Energy ● 30 20 W 02 4 7. 84 0. 91 0. 78 0. 53 0. 74 VELFAC 200 Energy ● 40 W 03 1 5. 52 0. 92 0. 77 0. 53 0. 74 VELFAC 200 Energy ● 50 W 04 2 10. 80 0. 86 0. 81 0. 53 0. 74 VELFAC 200 Energy ● 60 W 05 1 1. 38 0. 94 0. 78 0. 53 0. 73 VELFAC 200 Energy ● 70 60 W 05 1 1. 38 1. 00 0. 74 0. 53 0. 74 VELFAC 200 Energy ● 80 W 06 1 3. 70 0. 83 0. 53 0. 73 VELFAC 200 Energy ● 90 W 07 1 0. 45 1. 08 0. 70 0. 52 0. 72 VELFAC 200 Energy ● 100 W 08/1 2 1. 80 1. 07 0. 69 0. 53 0. 74 VELFAC 200 Energy ● 110 W 08/2 2 2. 74 0. 99 0. 74 0. 53 0. 74 VELFAC 200 Energy ● 120 W 08/3 2 1. 80 1. 07 0. 69 0. 53 0. 74 VELFAC 200 Energy ● 130 W 09 2 9. 60 0. 89 0. 79 0. 53 0. 74 VELFAC 200 Energy ● 140 W 10 1 1. 05 0. 90 0. 80 0. 52 0. 72 VELFAC 200 Energy ● 150 W 11 2 1. 28 1. 00 0. 74 0. 53 0. 74 VELFAC 200 Energy ● 160 W 12 1 1. 50 0. 85 0. 82 0. 52 0. 72 VELFAC 200 Energy ● 170 W 13 2 5. 40 0. 86 0. 81 0. 53 0. 74 VELFAC 200 Energy ● 180 W 14 1 1. 08 0. 91 0. 79 0. 53 0. 74 VELFAC 200 Energy ● 190 D 01/1 1 1. 35 0. 96 0. 75 0. 53 0. 74 VELFAC 200 Energy ● 200 D 01/2 1 1. 79 0. 93 0. 77 0. 53 0. 74 VELFAC 200 Energy ● 210 D 01/3 1 1. 35 0. 96 0. 75 0. 53 0. 74 VELFAC 200 Energy ● 220 D 01/4 2 6. 40 0. 82 0. 83 0. 53 0. 73 VELFAC 200 Energy ● 230 D 01/5 1 2. 76 0. 90 0. 63 0. 53 0. 73 VELFAC Ribo alu 2 ● 240 D 02/1 2 8. 32 0. 87 0. 84 0. 53 0. 73 VELFAC 200 Energy ● 250 D 02/2 2 6. 84 0. 82 0. 83 0. 53 0. 73 VELFAC 200 Energy ● 260 D 03/1 5 11. 45 0. 82 0. 53 0. 73 VELFAC 200 Energy ● 270 D 03/2 5 11. 45 0. 82 0. 53 0. 73 VELFAC 200 Energy ● 280 D 04 1 1. 89 0. 65 290 D 05/1 1 1. 46 1. 05 0. 75 0. 53 0. 73 VELFAC 200 Energy ● 300 D 05/2 1 1. 00 1. 10 0. 69 0. 53 0. 73 VELFAC 200 Energy ● 310 D 05/3 1 2. 50 0. 87 0. 64 0. 53 0. 73 VELFAC Ribo alu 2 ● 320 D 05/4 1 3. 80 0. 85 0. 53 0. 73 VELFAC 200 Energy ● 330 D 05/5 1 4. 03 0. 92 0. 81 0. 53 0. 73 VELFAC 200 Energy ● 340 D 05/6 1 4. 03 0. 92 0. 79 0. 53 0. 73 VELFAC 200 Energy ● Total / average: 53 127. 5 0. 88 0. 74 0. 51 VELFAC Ribo alu 2 0. 71 Empty fields can be due to values for chosen system does not exist or cannot be calculated. Window U-values calculated in accordance with EN ISO 10077 -1 and EN ISO 10077 -2. The given U-values are valid for elements without ventilation. Energy Data N/A: Area: Uw: Ff: Values not available or cannot be calculated Area window/element U-value of the element Area glass/area window VELFAC A/S | Bygholm Søpark 23 | DK-8700 Horsens | Tel. : +45 7011 0200 | Reg. no: 24347214 | VAT no. : DK 24347214

16. 10. 2018 Quotation no. : Project name: Page 20050233 QTE 1985 20 gg: LTg: System: Class: EW: / 20 Share of solar energy reaching into the building Light transmission. Share of sun light reaching into the building Quoted window system N/A Variations in glass coatings between different suppliers can give marginal deviations in U-, g- and LT-values from the values detailed in the order confirmation. FSC® • The product is FSC® certified: FSC Mix 70%. FSC® NC-COC-012338. VELFAC A/S | Bygholm Søpark 23 | DK-8700 Horsens | Tel. : +45 7011 0200 | Reg. no: 24347214 | VAT no. : DK 24347214
