TCOO Charging Basics Charge Faster Charging Standards Level

TCOO Charging Basics

Charge Faster!

Charging Standards • Level 1 • 120 V AC (Single Phase) • 15 A Circuit – 12 A Max Continuous – 1. 44 k. W • 20 A Circuit – 16 A Max Continuous – 1. 92 k. W • Level 2 • 208 V – 240 V AC (Single Phase) • 100 A Circuit – 80 A Max Continuous – 19. 20 k. W • Level 3 • Tesla CHAde. MO: 400 V DC – 125 A – 62. 5 k. W • Tesla Supercharger: 400 V DC – 250 k. W

Onboard Charger • Model 3 • Long Range 3 = 48 A Max • Short / Mid Range 3 = 32 A Max • Model S/X • • Refresh 75 k. Wh S/X = 48 A Max Refresh 100 k. Wh S/X = 72 A Max Nosecone S (Single Charger) = 40 A Max Nosecone S (Dual Charger) = 80 A Max

Mobile Connector (UMC) • Gen 1 -- 40 A Max – 9. 6 k. W

Mobile Connector (UMC) • Gen 2 – 32 A Max – 7. 7 k. W

Wall Connector (HPWC) • Gen 1 & 2 – 80 A Max – 19. 2 k. W

J 1772 Plug

CHAde. MO Plug

CCS Combo Plug

J 1772 Adapter

CHAde. MO Adapter

Things To Consider • Caution - charging too high will reduce regenerative braking. • It is normal for the cooling fans to be loud when Supercharging. • Charging will be much slower at low & high SOC. • You will lose some charge, even when plugged-in. • Use Plug. Share to find charging locations. • Charging Etiquette… a topic of it’s own.

Best Practices • Stay between 20% - 80%. • It’s okay to go to 10% - 90%. • Try to avoid less than 10% or more than 90%. • Charge at Level 2 if feasible. • Keep Regen at Standard. • Supercharging on trips – stay low, don’t go too high.
