Sustainable Shed Solar Air Heater Entire BE 4730 Class Prepared by: Carolyn Coffey, Ben Leppard, and Matt Rosen

Purpose -The solar air heater (SAH), along with the entire sustainable shed, got destroyed while in transit from Mc. Adams to the Aquaculture facility. Our project was to design, fabricate, implement and analyze the a new SAH for the sustainable shed.

Design ❖ Passive flow, split-channel system separated by absorber plate ➢ ➢ Inlet is perpendicular to the ground Outlet is parallel to the ground ❖ Asymmetrically tapered from outside to inside in order to fit into 21” window.

Autocad Drawing w/ Dimensions (side view -in) Exterior Pieces - 24” wide Interior Pieces - 21” wide Interior Exterior

Rendering by Ray Outside Rendering

Inside Rendering

Side View Rendering

Using Methylene Chloride to bind sheets of acrylic

Piecing it all together

Installing into the sustainable shed!

Surface of Absorber plate ❖ Use of black paint increased emissivity to 0. 98 ❖ Graphite increased surface area ❖ Maximizing efficiency

Completed Project

Inlet/Outlet Data

Determining Effective Heat Transfer Assumed v=0. 1 (m/s) (v=velocity of air) u can be calculated through smoking technique

Determining Heat Generation Assumed v=0. 5 (m/s) v can be calculated through smoking technique

References ❖ Graphite for surface of absorber plate: http: //www. builditsolar. com/Projects/Solar. Homes/constructionps. htm ❖ Video ❖ Languri and Ganji. Thermal Aspects of Solar Air Collector. Heat Transfer - Mathematical Modelling, Numerical Methods and Information Technology. 2011. http: //cdn. intechopen. com/pdfs-wm/13434. pdf ❖ Convective Heat - Air velocity and volume of air flow. The Engineering Toolbox. http: //www. engineeringtoolbox. com/convective-air-flow-d_1006. html ❖ Credit Ray Middleswarth for the renderings
