SUNBURST TECHNOLOGY CORPORATION TEAM1 SUNFLOWER Nil Tue Patan
SUNBURST TECHNOLOGY CORPORATION TEAM#1 SUNFLOWER Nil Tuğçe Patan İrem Akdaş Ali Öztaş Berkay Öğdük Betül Örün Tuğçe Kartalkanat INTERMEDIATE PRESENTATION
OUTLINE • Description of Sunflower • Product Tree • User Interface • Hardware Design • Changes in the Design • Current State of the Project • Road Map
DESCRIPTION OF SUNFLOWER Sunflower is an innovative self-operating parasol that runs without requiring any considerable effort from users at the beaches, hotels, cafes and restaurants. • Sunflower protects users against burning sunlight and rain. • It can provide shadow continuously. • It can be opened and closed using the buttons on it. • The main functions of the Sunflower are achieved via rain sensor and phototransistors.
PRODUCT TREE
USER INTERFACE – CONTROL PANEL
FLOW CHART DIAGRAM
CIRCUIT DIAGRAM
CHANGES IN THE DESIGN üPIC 16 f 876 instead of 8051 üPhototransistors instead of LDRs üBasic instead of Assembly üImplementation of the Sun sensor üCheaper Motors üReduced Production Cost
CURRENT STATE OF THE PROJECT üElectrical Design üSoftware Design üMechanical Design üIndustrial Design üMovement in one direction üPrinted Circuit Boards
ROAD MAP üWeek 1: Research and procurement of equipment üWeek 2: Configuration Management üWeek 3: Revisions of Documents üWeek 5: Electrical Design Package – Progress Report 1
ROAD MAP üWeek 6: Printed Circuit Boards üWeek 7: Trader’s Conference üWeek 8: Mechanical & Industrial Designs üWeek 9 -10: Improving the prototype to operate in more directions üWeek 11 -12: Implementation of Rain Sensor
