SUBMARINE CONTROL SYSTEM Imran Ali Namazi Final Year

SUBMARINE CONTROL SYSTEM Imran Ali Namazi Final Year Electrical KCG College of Technology

Project Timeline Phase Who Help Tools Time Hull Design Fabrication Assembly Electronics Testing (Mech) Testing (Elec) Control System Sonar Mapping DSP PCB Work Modem Design KP KP KP IAN IAN Krishnan Engel Imran KP S. Kumar Andre CAD CNC (Mech) (Elec) 2003 Dec 04 Feb 05 Feb-Mar 28 Mar 05 9 Apr 05 Mar-Apr 05 Ongoing Vivek Subrat Vishy Anupam VB 6 VB. net MATLAB E-CAD (RF) IAN = Imran Ali Namazi; KP = K. P. Subramanian

Project Report Excerpt Taken from Chapter 1. 2 “Literature Survey” on page 4

Other Projects Project Field Time Speedometer / Odometer Chiming n Striking Clock File Viewer Inventory & Room Allocation Quiz Buzzer Employment Exchange Micromouse (Techfest) Energy Meter Electronics VB 6 / SQL m. P VB 6, CSS, SQL Elec/Mech m. P May 98 Aug-Dec 98 2000 -2004 2003 Aug 04 Oct 04 Jan 05 Feb 05 *These projects are listed here as illustrative of the areas in which skills have been picked up and to show valuable they were over the course of our submarine project.

Projects - Speedo • for my bicycle - using dynamo as i/p • 2 digit display (99 kph / 9. 9 km) • Display using 4518 / 4511 • 40106 to generate latch & reset • 4040 / 4068 for division (÷ 8 for speedo & ÷ 1440 for odo) • Acrylic cabinet and Al. mounting

Projects – Nathella* • • 4 Channel Clock Hourly Chime Battery Backup Lighting Control *Worked only as assistant. Helped in developing, fabrication, testing and commissioning.

Projects – IViewer (VB 6) • Capable of viewing Images, Html, Text, Office, PDF mp 3 & even videos. • Built in File Explorer • Knowledge of shell, API, registry • Uses listview, treeview, icons toolbar options dialog, paning etc. • Current version 3. 5. 394 (394 builds) • Over 6000 lines of code

Projects – Inventory

Projects – Room Alloc (NLDS)

Projects – Buzzer (m. P)

Projects – Buzzer (m. P) • Single digit (Max 8 contestants) • Stores sequence of pressing. • Can scroll up/down to Learnt: ALP, m. P based system design Learning /Development Time 1. 5 m

Projects – Emp. EX

Projects – Micromouse

Projects – Micromouse • 6 legged • Aluminum frame • 2 IR-LEDs for detecting obstacles • 3 servomotors – (left legs, right legs & tilt legs) – Done in conjunction with Narendran and Sriram, – 3 rd year Sathyabama Engineering college.

Projects – Energy Meter (m. P)

Projects – Energy Meter (m. P) • 3 digit multiplexed display • Opto-coupler as input. • Switches to show rate • Uses recursion for addition • Optimized algorithm for multiplication.

THANK YOU • Also in the presentation: – Testing Videos (Lafayette) – Software Demo (Delphi) • Buzzer (OHP) • Other Projects (on request) • Assembly Programming (e-Meter)
