Station Model Eric Angat Teacher Station Model 1

Station Model Eric Angat Teacher

Station Model 1. 2. 3. 4. 5. 6. 7. 8. 9. What is a station model? What is the weather data in the center circle? How do you determine the direction of the wind? How do you determine the wind speed? What does the number on the top left indicates? How do you determine the visibility? Where do you find the symbol for the current weather What does the number at the bottom left indicates? The closer the values of the temperature and dew point temperature the higher is the ____________. 10. What does the number on the bottom right indicates? 11. What does the number on the top right indicates? 12. Why do meteorologist use codes or shorten the air pressure? 13. What is the rule in adding 10 or 9 before the coded air pressure? 14. Why is barometric trend important in the station model? 15. What does +19/ mean?

Station Model

A Station Model Is a system that uses symbols and numbers to communicate the present weather condition.

Station Model https: //www. youtube. com/watch? v=h 9 pwd. Hz 0 S 5 M

75% cloud cover

100% cloud cover West Wind is described where it is coming from.

North Wind is described where it is coming from. Southwest

Long line is 10 knots Short line is 5 knots Speed of Wind is 15 knots.

5 knots 10 knots

snow There a lot of symbols used for the current weather. Some of them are in pp. 915

This are some of the current weather symbols.

100 % relative humidity means precipitation. 27 / 28 =. 96 X 100 = 96%

After 6 hours.

How to get the complete air pressure. Less than 500, add 10 at the beginning means… 10 196 1019. 6 mb

Station Model 1. 2. 3. 4. 5. 6. 7. 8. 9. What is a station model? What is the weather data in the center circle? How do you determine the direction of the wind? How do you read the wind speed? What does the number on the top left indicates? How do you determine the visibility? Where do you find the symbol for the current weather What does the number on the bottom indicates? The closer the values of the temperature and dew point temperature the higher is the ____________. 10. What does the number on the bottom right indicates? 11. What do the two numbers on the top right indicates? 12. What is the typical air pressure range? 13. Why do meteorologist use codes or shorten the air pressure? 14. What is the rule in adding 10 or 9 before the coded air pressure? 15. Why is barometric trend important in the station model? 16. What does +19/ mean?

Station Model 1. Cloud cover = ____________ 2. Temperature = ____________ 3. Visibility= ______________ 4. Type of weather=___________ 5. Wind direction=___________ 6. Wind Speed=____________ 7. Dew point= ____________ 8. Amount of precipitation in inches=______ 9. Air pressure=____________

Station Model

Station Model 75 % 1. Cloud cover = ____________ 43 F 2. Temperature = ____________ ¾ mile 3. Visibility= ______________ Fog 4. Type of weather=___________ Southwest 5. Wind direction=___________ 15 knots 6. Wind Speed=____________ 40 F 7. Dew point= ____________ 8. Amount of precipitation in. 06 inches=__________ 1014. 6 mb 9. Air pressure=____________

10. What is the temperature? _____ 11. What is the dew point temperature? ______ 12. What is the approximate amount of sky coverage? _____ 13. What is the current barometric pressure? _________________ 14. What was the barometric pressure three hours ago? __________ 15. What is the wind direction? ______ 16. What is the wind speed? ______

10. 75 degrees Fahrenheit 11. 61 degrees Fahrenheit 12. about 50% 13. 998. 7 millibars (987 is 98. 7 and to make it nearest to 1013. 3 it is 998. 7) 14. 997. 6 mb (998. 7 minus 1. 1, since the barometer has been rising, it was lower in the past, and the amounts are reported to the nearest tenth of a millibar) 15. east (winds are described as where they are from) 16. 25 knots
