Station Metadata The NRL (Nominal Response Library) Dr. Mary Templeton IRIS Data Management Center Data Management Workshop Bogotá, Colombia July 2014

What is the NRL? n Library of manufacturers’ recommended nominal instrument responses n n n SEED RESP files Help matching an instrument’s configuration with the correct response Notes describing instrument and response differences

What is the NRL? �� n Includes n n 62 sensor models (14 manufacturers) 37 datalogger models (11 manufacturers) 11452 RESP files (98% are datalogger)� Constantly growing���

How is the NRL Constructed? n n Response information from manufacturer Instruction file links instrument configuration with pole/zero or FIR coefficient files Generate RESP files from instruction file Accuracy checking

How Can You Use the NRL? n Web version (http: //www. iris. edu/NRL/) n Follow links for manufacturer and model Notes are at the top n Table helps locate the correct RESP file n Example: STS-2 sensors n (http: //www. iris. edu/NRL/sensors/streckeisen_sts 2_sensors. htm)

How Can You Use the NRL?

How Can You Use the NRL? n n Copy PDCC from a memory stick In PDCC: n n Select a channel Launch “Select Instrumentation” n Download latest version of the Library (but not this week!) n n PDCC checks the IRIS website for NRL changes Answer questions to find the correct responses

How Can You Use the NRL? n Update your Nominal Response if: n n n you have calibration info your accelerometer full scale voltage and/or clip level differs you have a passive sensor and your resistors differ� n you need to take sensor-amplifier impedance into account� n n You’ve set a software gain on your datalogger

Two Things You Need To Know n n If you change a stage gain, you must recalculate the final (stage 0) gain The final (stage 0) normalization frequency must lie within the passband of the response curve: passband

What Does the NRL Still Need? n Contact Mary Templeton n met@iris. washington. edu
