squid Request Hit Ratios Byte Hit Ratios 5

  • Slides: 30
Download presentation

squid Request Hit Ratios: Byte Hit Ratios: 5 min: 46. 8%, 60 min: 44.

squid Request Hit Ratios: Byte Hit Ratios: 5 min: 46. 8%, 60 min: 44. 8% 5 min: 10. 2%, 60 min: 11. 6% Request Memory Hit Ratios: 5 min: 29. 7%, 60 min: 25. 1% Request Disk Hit Ratios: 5 min: 2. 7%, 60 min: 7. 6%

七层负载均衡 acl free_content path_beg -i /publicforum/content/free acl free_list path_end -i free. shtml acl asp

七层负载均衡 acl free_content path_beg -i /publicforum/content/free acl free_list path_end -i free. shtml acl asp path_end -i. asp acl static path_end -i. js. css. gif. jpg. html use_backend asp if asp use_backend static if static use_backend pub_hot_1 if free_content OR free_list

结构 F 5 -GTM F 5 -LTM Haproxy 根据URL分拆版块应用 Squid squid WWW WWW 写

结构 F 5 -GTM F 5 -LTM Haproxy 根据URL分拆版块应用 Squid squid WWW WWW 写 DB主 读 DB从

varnish • 热门版块命中率70% • 流量节约 70% • 上午9时 40分varnishstat输出结果: Hitrate ratio: 10 100 137

varnish • 热门版块命中率70% • 流量节约 70% • 上午9时 40分varnishstat输出结果: Hitrate ratio: 10 100 137 Hitrate avg: 0. 7300 0. 7206 0. 7196 56322971 45186154 48. 96 42. 97 45. 05 Client connections accepted 36. 14 Client requests received

ASP对memcache的操作 set cache = Server. Create. Object("Tianyamemcached. Client") cache. set. Group("group_test") content = cache.

ASP对memcache的操作 set cache = Server. Create. Object("Tianyamemcached. Client") cache. set. Group("group_test") content = cache. get("key") add_action = cache. add("key", content, Out. Time) del_action = cache. Delete ("key") set cache = nothing

F 5 -GTM F 5 -LTM Haproxy 根据URL分拆版块应用 Varnish WWW WWW Memcache 写 DB主

F 5 -GTM F 5 -LTM Haproxy 根据URL分拆版块应用 Varnish WWW WWW Memcache 写 DB主 读 DB从 Redis

监控平台结构 Watch. Dog Agent Server XML Switch WEB Server Socket Server SNMP XML Agent

监控平台结构 Watch. Dog Agent Server XML Switch WEB Server Socket Server SNMP XML Agent Server DB

其它运维开源 具 • • Nagios Cacti Func Python

其它运维开源 具 • • Nagios Cacti Func Python
