© WEINMANN GERÄTE FÜR MEDIZIN GMBH+CO. KG SOMNOcheck micro 2009 Features of SOMNOcheck micro u Uncomplicated and easy diagnostics for sleep related breathing disorders u Innovative Puls-Wave-Analysis (PWA) • Differentiated and high-quality information • Differentiation between obstructive and central apnea, hypopnea • Sleep fragmentation u Results are shown on the display directly after recording – No PC required u RAG rating for just in time risk evaluation u Fault tolerant system u Reliable and significant results u RAG = „traffic light like display“ • RED • AMBER • GREEN 4

SOMNOcheck micro 2009 © WEINMANN GERÄTE FÜR MEDIZIN GMBH+CO. KG Application • Worn like a watch • No effort belts required • Only two sensors • Intuitive application • Wrist band also suitable for sensitive skin • Easy cleaning of wrist band • Ideal for people who usually sleep in frontal position 5

SOMNOcheck micro 2009 © WEINMANN GERÄTE FÜR MEDIZIN GMBH+CO. KG Displayed values SOMNOcheck micro shows the results of the recording by RAG rating. With this system a quick overview is warranted. 6

SOMNOcheck micro 2009 © WEINMANN GERÄTE FÜR MEDIZIN GMBH+CO. KG Overview results 7

SOMNOcheck micro 2009 © WEINMANN GERÄTE FÜR MEDIZIN GMBH+CO. KG Overview results 8

© WEINMANN GERÄTE FÜR MEDIZIN GMBH+CO. KG SOMNOcheck micro 2009 9 Risk for sleep disturbance u The risk is shown by simple RAG rating u Risk Level: LOW, MEDIUM, HIGH (Green, Amber, Red) u Evaluation of risk: • The recorded parameters Apnea/Hypopnea-Index (AHI/RDI) and Autonomous Arousal-Index (AAI) define the risk. • The concept of „worst case“ is used. AHI / RDI < 10/h AAI < 30/h AHI / RDI 10 – 15/h AAI 30 - 40/h AHI / RDI >= 15/h AAI >= 40/h

SOMNOcheck micro 2009 © WEINMANN GERÄTE FÜR MEDIZIN GMBH+CO. KG SOMNOcheck micro – Highlights 1 u Identification of central Apnea/Hypopnea, for the first time, with a small diagnostic device on the wrist. u RAG rating for fast interpretation u Easy and quick identification of patients with a high risk for sleep related breathing disorders (SRBD) u sophisticated results for disease specific referral u Evidence for sleep disorders by arousals and autonomic RERAs 10

SOMNOcheck micro 2009 © WEINMANN GERÄTE FÜR MEDIZIN GMBH+CO. KG SOMNOcheck micro – Highlights 2 u reliable because of automatic and qualitative self estimation of results u One-button-operation: easy access to detailed results u function control with online displayed pulse and flow u smart, lightweight and comfortable – uncomplicated screening at home u valide analysis: sensitivity 96, 2%, specifitivity 91, 7% u quick an easy documentation by report 11

SOMNOcheck micro 2009 © WEINMANN GERÄTE FÜR MEDIZIN GMBH+CO. KG Patient‘s instructions 12

© WEINMANN GERÄTE FÜR MEDIZIN GMBH+CO. KG SOMNOcheck micro 2009 13 Pulse wave u The pulse wave is measured by the optical methode of Photoplethysmography. The procedure is already known from pulse oxymetrie. u Pulse waves are affected by: • Rhythm (heart rate), Regularity (changes or stability of frequency), Blood vessel filling, Amplitude, Slew rate (shape of the curve), Dikrotie (second peak of the peripheral pulse wave), Stiffnes (duris or mollis) u Respiratory events and arousals induce characteristic changes in the pulse wave. Although the intrathoracic pressure changes are minor, the effect is consistently seen in a peripheral pulse trace. u With an innovative algorithm and the characteristics of the pulse trace it is possible to detect the events. Characteristics of pulse wave Volume u A distinction between obstructive and central events is also realised in SOMNOcheck micro. This is a very good option for disease-specific referral. Reflektion PWA Pulsfrequenz Time
