Software Analysis What Is Analysis and Why Transform

Software Analysis

What Is Analysis, and Why? • Transform use case model into logical design, without(*) considering implementation conditions, constraints and details. • Product: The analysis model • Why do we need analysis? – Handle complexity via separation of concerns – A platform, implementation independent design that precisely reflect the requirements, that can be reused, that can sustain technological and environment changes, and that serves as the basis for stable and extensible system structure

Comparison Between Use Case and Analysis Models

Workers and Artifacts

Overview of Relevant UML Notations • Structural views and relationships

Generalization

Multiplicity

Aggregation

Inheritance

Structural Relationships

Class Diagram

Modeling Collaboration Relationship

Modeling Schema

Advanced Classes

Structure and Composition of Analysis Model

Analysis Class • An analysis class represents an abstract of one or more classes and/or subsystems in (subsequent) design • Characteristics – focuses on handling functional requirements (? **) – seldom defines and provides any interface in terms of operations and their signatures (? **) – defines attributes (high level, and recognizable from problem domain – is involved in relationships at conceptual level – always fit one of 3 basic stereotypes: boundary, control and entity to achieve model robustness

Key Attributes and Subtypes of Analysis Class

Boundary Class • Models interaction between actor and system • Models parts of system that depend on its actors - they clarify and collect requirements on the system’s boundary • Often represents abstractions of windows, forms, panes, communication interfaces, printerfaces, sensors, terminals, and possibly APIs • Each boundary class should be related to at least one actor and vice versa

Example

Entity Class • Used to model long lived information, and thus often persistent • Models information and associated behavior of some phenomenon or concept, e. g. individual, real-life object, or reallife event • In most cases, entity class are derived from corresponding business class (domain class), but reflect the information that benefits the developers • Used to isolate changes that they represent

Example

Control Class • Represent coordination, sequencing, transactions and control of other objects • Often used to encapsulate control related to a specific use case • Also represent complex derivations and calculations, e. g. business logic, that cannot be related to any specific, long-lived information • Therefore, control classes model the dynamics of the system • Used to encapsulate, thus isolate, change to control, coordination, sequencing, transactions and complex business logic

Example
