SMART SHEAD NET HOUSE STRUCTURE HISTORY Presentation of

SMART SHEAD NET HOUSE STRUCTURE

HISTORY § Presentation of smart Shadenet Structure by PMarom Experts. (Israel) § Explaining Esrael-Eropean shadenet technology.

SUPPORT BY ISRAEL TEAM § § Staff training with P-Marom Technician. Import support given by SFPCL. India's First International standard shadenet material with expert technician of PMarom. Project supported by NHB.

STRUCTURE FEATURES q q q q Custom Design Structure for Optimum USE of Field. Made of ISI hot deep GI PIPES and GI steel core WIRE Ropes. Design to meet International Standards withstand in winds speed up 130 km/hr. Crop Protection from High Radiation, winds and Hail storms. Various nets types for different agricultural land use application. Internal Screen ( optional ) With Wider Span, ( 6 m x 9 m ) and due to 4 m height intercultural operations are easy by Mechanical Implements. Easy to assemble with latest Modern German Tools.

VISIT TO AGRI TECH ASIA, 2012 ISRAEL

VISIT TO AGRI TECH ASIA, 2012 ISRAEL

PROFESSIONAL SERVICES Ø Ø Ø Ø Each structure is designed analyzed with specific agro climatic conditions. Feasibility studies with thorough climate and land use analysis. Designing an engineering and economic structural plans. Construction of custom-made structures. designed specifically to full fill client requirement. Delivery and assembly on site. Providing with any supplementary equipment as required. Further support to ensure the success of the project.

FOUNDATION Ø Ø Ø Anchor Foundation Depth is 1. 2 meter Deep. Each Main Side Colum is supported by double Anchor with Tension up to 2 Tone Force. Tensioned structure is very stable against winds.

STRUCTURAL FRAME Internal support 2” B Class GI Pipe, 4 Meter height, Wall thickness 3. 6 mm, 5. 03 Kg/m, IS 1161: 1998. Main Corner 2” C Class GI Pipe, 4 Meter height, Wall thickness 4. 5 mm, 6. 19 Kg/m, IS 1161: 1998. Side Tension 6 mm wire rope Counter support 5 mm wire rope Internal support 2” A Class GI Pipe, 4. 5 Meter height, Wall thickness 2. 9 mm, 4. 08 Kg/m, IS 1161: 1998. Foundation Pit 1. 5 X 4 Ft Top Tension 6 mm wire rope

STRUCTURAL STABILITY ANALYSIS Ø Structural Stability Analysis is done by Engineering Formulas. Ø Structural Analysis Software ( Ansys Cad ). Ø Ø Ø Wind Load Analysis up to 200 km / hrs. Crop Load Analysis. ( up to 25 Kg par Sq. Meter ) Wind Load with Crop Load and Hail Load Analysis. Bending Analysis Of GI Pipe. While Design, all Material Properties are applied as par IS standers or 3 rd Party Material Test Reports.

WIND LOAD ANALYSIS VIDEO

CROP LOAD ANALYSIS

CLADDING MATERIAL Top Shade Net 125 GSM Garwaray Monofilament Internal Double Shading Net 115 GSM 50 Mesh Insect Net 140 GSM Woven Fabric for Carbon Effect.

SHADENET FITTINGS TO STRUCTURE Net Fixing Material Cost Rs 15 par Meter

SKILLED ERECTION TEAMS v v We have 60 tribal trained and skilled Youth. Their annual Income Raised up to 1. 5 lakh per Family. All are covered with works mans insurance policy. Quality Check list for erection Work chart.

COLOR CAPSICUM

HUGE PRODUCTION

GREEN CAPSICUM

BRINJAL

CUCUMBER

ROSE

ORCHID

MARIGOLD

SHADE NET VIEW

DETAILS 1. 2. 3. 4. 35% BLACK SHADE NET. POLY FILM TUNNELS WITH GI FRAMEWORK POLY MULCH TO AVOID SOIL BORNE DISEASES. PREPARING SEEDLINGS UNDER NATURAL LOW COST NURSERY STRUCTURE

ADVANTAGES 1. 2. 3. 4. MAINTAINING TEMPERATURE AT NIGHT. PROTECTION FROM RAINFALL. IN DAY TIME THIS POLY FILM WILL BE RAISED BY HANDLE TO PROVIDE SUFFICIENT LIGHT TO SEEDLINGS. VERY EFFICIENT TECHNIQUE & SEEDLINGS WILL BE STRONGER. POLY FILM TUNNEL TECHNIQUE

COMPARISON Sr. No. Component 1 Foundation Single Side Support as Hokey with Double Anchor Wire Rope Support with Ground Foundation Depth 0. 6 Meter Anchoring of 1. 1 Meter Depth with Tension. Main Colum 2" A Class GI Pipes as Total Structure Having Corner Member - 2" C Class GI Pipe as Having Wall thickness 2. 85 mm and weight per Wall thickness 4. 5 mm and weight per Meter is 3. 80 Kg 6. 19 Kg. IS 1161: 1998. 2 3 4 5 Purlin Total GI Pipe Structure GI Pipe Wire Rope Smart Structure Side Supporting Member - 2" B Class GI Pipe as , Having Wall thickness 3. 60 mm and weight per Meter is 4. 80 Kg. IS 1161: 1998. Internal Supporting Member - 2" A Class GI Pipe as , Having Wall thickness 2. 85 mm and weight per Meter is 3. 80 Kg. IS 1161: 1998. 6 mm and 5 mm Wire Rope of Total Member 42 mm and 32 mm Member of 6 and 4 Length ( up to 150 Rmt ) Joint Free fix with Meter Length use ( Par Running Mtr Cost Rs Compressed Clips. ( Par Running Meter Cost is 115. ) I. e Rs 87 par Sq. Meter Rs 55 )i. e. Rs 31 par Sq. Meter

Sr. No. Component Total GI Pipe Structure GI Pipe Wire Rope Smart Structure 6 Grid Size 4 x 4, 8 x 4, 6 x 4 Diffucult to Inter culturing Opration 8 x 6 and 9 x 6 Easy to Interculturing Opration. 7 Net Fixing Component Al Profile + Zig Zag Spring Cost Par Rmt Rs 50 Only HDPE Net Fixing Pins ( Rs 15 Par Meter ) 8 Withstand in wind Takes wind speed up 120 Km / hr Takes wind and Hail Pressure up 130 Km / hr 9 Crop Support System Additional Support Frame will Required Approximately Cost par Sq. Meter is Rs 50 On Structure Frame Crop Load is Consider, Only Bamboo and Support Poly Wire or GI Wire Required ) Cost Par Sq. Meter is Rs 20 10 Construction Cost Par Acre Rs 14, 000 ( Rs 350 Per Sq. Meter ) 40 % More Rs 10, 000 ( Rs. 250 per Sq. Meter ) 11 Production Rs. 6, 02, 169 (Planting Material, Inputs, Drip, Cost per Acre Support System, Etc ) 12 Total Cost of Project Rs 19, 08, 000 Lakh Rs. 4, 75, 131 (Planting Material, Inputs, Drip, Support System, Etc ) Rs 14, 79, 000 Lakh

Sr. No. Component Total GI Pipe Structure GI Pipe Wire Rope Smart Structure 13 Loan Amount Rs 14, 31, 000 Lakh (75% of Total Cost) Rs 11, 09, 000 Lakh (75% of Total Cost) 14 Income of Seasional Vegetable Rs 6, 90, 000 Lakh 15 Loan Installment Rs 2, 38, 000 Lakh (Per Year) Rs 1, 85, 000 Lakh (Per Year) 16 Intrest on Loan Rs 1, 15, 000 Lakh (Avg. Per Year) Rs 89, 000 Thusand (Avg. Per Year) 17 Net Surplus Rs 41, 573 Thousand (Avg. Per Year) Rs 1, 55, 500 Lakh (Per Year) 18 Repayment Period 7 Years 19 Avg. DSCR 2. 57 2. 98 20 BEP 0. 48 To 0. 89 0. 41 To 0. 75

STRUCTURAL STRENGTH AGAINST HAIL STORMING

RIGID GI PIPE STRUCTURE COLLAPSE

MINIMUM DAMAGE DUE TO EXTERNAL IMPACT

IMPORTANCE OF HEIGHT

SELF SUPPORT SYSTEM

STRUCTURAL SUSTAINABILITY Ø Guaranty / Warranty q Structural Strength § § § q 5 years anti rust warranty for GI pipe and GI steel core wire rope. 10 years structural warranty against natural wear and tear. Structure will withstand in wind speed up 130 km/hr. Structure will Safe for crop load up to 25 kg /Sq. Mtr. Structure will Safe for hail load up to 500 kg on 9 x 6 Meter span on top. Cladding material: § § One years replacement guaranty against natural wear and tear. Second year (66 %) and third year (33 %) purchase price compensation warranty against natural wear and tear. ( as per manufacturers terms and conditions )

OUR SUCSSES We have no any maintains call due to natural calamity from last five years. Ø Farmers are demanding our structure and willing to wait for month period. Ø In market, competitors are following our standards. Ø

STRENGTH OF JAIHIND AGRO q q q Experienced professional team q B. Tech. Agri. Engineers. q Wide Exposure of International Farming System 25 years participatory practical field experience of agricultural development. Well equipped with all modern infrastructure facilities. Innovative and practical solutions to clients. Strong HRD with all stake holders.

JAI HIND
