Smart Diagnosis Tool Trouble Shooting January 2019 V
Smart. Diagnosis Tool Trouble Shooting January 2019 V 3. 0
Document history 3. 0 2019 -01 -07 Update with setting for log fail upload Add http: //dfetch. tctsdc. com/notify. php As exception on firewall or gateway Page 5 2. 0 2018/11/09 Update with code Error=10006 Page 4 1. 0 2018/06/21 Creation Rev, Date Modification description Fisherman Page Number Modified By
Error code: None Symptom: Install failed. ADB: Invalid APK file. E: testing_folderSmart. Diagnosis 2. 3. 1ApkSmart. Dignosis_Signed_For_All_v 2. 4. 5. apk Root cause: Coding wrong with Smart. Dignosis_Signed_For_All_v 2. 4. 5. apk on Version 2. 3. 1 that should be mart. Dignosis_Signed_For_All_v 2. 4. 7. apk Solution: Update source code with mart. Dignosis_Signed_For_All_v 2. 4. 7. apk and release new tool version 2. 3. 2
Error code: 10006 Symptom: Report reuploaded failed! (Error=10006) Root cause: Because some RC has Firewall block SDT tool to upload report to outside network. That induces report could NOT be uploaded to server manually or automatically. Solution: Enable report server IP 34. 203. 66. 129 on Gateway/ firewall. Meanwhile
Error code: 10006 Symptom: Report reuploaded failed! (Error=10006) Root cause: 1. Because some RC has Firewall block SDT tool to upload report to outside network. That induces report could NOT be uploaded to server manually or automatically. 2. Report Server employs UTF-8 coding. But tool deploys coding according to RC PC. Smart. Diagnosis 2. 4. 4 R transfters report format to UTF-8 before uploading. Solution: Enable report server IP 34. 203. 66. 129 and http: //dfetch. tctsdc. com/notify. php on Gateway/ firewall. Meanwhile, please update tool higher or Smart. Diagnosis 2. 4. 4 R.
THANK YOU
