SIM 336 Fabric Deployment Infrastructure Enhancements Fabric Management

SIM 336

Fabric Deployment Infrastructure Enhancements Fabric Management HA VMM Server Hyper-V Bare Metal Provisioning Update Management Upgrade Hyper-V, VMware, Citrix Xen. Server Dynamic Optimization Custom properties Network Management Powershell Storage Management Cluster Management Cloud Services Cloud Management Service Management Application Owner Usage Service Templates Capacity and Capability Delegation and Quota Application Deployment Custom Command Execution Image Based Servicing

VMM Admin Fabric Administrator Scope: Entire system Can take any action Can use Administrator console or Power. Shell Delegated Admin Fabric Administrator Scope: Host groups and clouds Set up fabric by configuring hosts, networking and storage Create cloud from physical capacity Assign cloud to self-service users Can use Administrator console or Power. Shell Self-Service User Application Owner Scope: Clouds only Author templates Deploy/manage VMs and Services Share resources Can use Administrator console, Power. Shell and Self-Service portal Revocable actions Quota as a shared and per-user limit Read-only Administrator Help Desk Scope: Host groups and clouds, No actions

Logical Network Host Group IP Subnets/ VLANS IP Pools Pool 01 BOSTON Pool 02 FRONTEND Pool 03 NEW YORK Pool 04

IP Range: 10. 70. 23. 1/24 (254 addresses) Static IPs Define Pool Set IP range Static, reserve, VIP Reserved IPs IP check -out New VM creation VIPs (Virtual IPs) IP check -in VM Deletion, Migration

MAC Range: 00: 1 D: D 8: B 7: 1 C: 00 - 00: 1 D: D 8: F 4: 1 F: FF (3, 998, 720 addresses) Static MACs Define Pool Set MAC range Allocate Pool Associate to host group MAC checkout New VM creation MAC check-in VM deletion

demo

IP Range: 10. 70. 23. 1/24 (254 addresses) Static IPs Reserved IPs VIPs (Virtual IPs)

Add Load Balancer Provider Power. Shell provider Add a Load Balancer Connection properties Validate connection Define VIP Template Protocol LB method Persistence Health Monitors

New York VMM uses the Citrix Net. Scaler provider to create VIP in the load balancer Placement picks same IP pool that’s used to allocate IPs for DIPs Citrix Netscaler F 5 Big. IP User chooses VIP template to use when creating service instance Library

announcing

demo

Discovery of LUNS Mask and Unmask Set ISCSI CHAP Discovery of portals and targets Log on & log off Port to LUN mappings Virtual to Physical port mappings Create & delete Virtual Ports Enumerate Rescan Mount/Un. Mount Volume to Disk mapping Disk to LUN mapping

Discovery of portals and targets Log on & log off Port to LUN mappings Virtual to Physical port mappings Create & delete Virtual Ports Enumerate Rescan Mount/Un. Mount Volume to Disk mapping Disk to LUN mapping

VMM 2012 SERVER CIM-XML

VMM Storage Management Service Storage Provider Array Pool Unallocated Array Pool Allocated Logical Unit Unallocated … … Allocated Logical Unit …

VMM Agent Machine Resources FCHBA i. SCSI Initiator FCHBA Port v. Ports IQN Disk Manager Disk Volume Disk

Service Instance Machines Virtual Layer Logical Disk Virtual Layer In Guest

Logical Disk Virtual Layer In Guest Volume Physical Layer In host OS Logical Disk Physical Layer In Host OS Logical Unit Array Layer

Logical Unit Array Layer Pool Array Layer Array Provider

Available storage disks Cluster 1 Dedicated Storage Available storage pools CSV, available disks Assign Storage Shared Storage Host groups Available disks Host 1

demo

VM OS Profile VM SCC Template VHD HW profile VHD is SAN Copy Capable (SCC) VHD Host New VM Wizard Storage Disk Host Array supports snapshot/clone Array creates a copy using snapshot/clone SAN
