SIA 205 Active Directory Domain Services on Windows Azure Virtual Machines Samuel Devasahayam Active Directory Product Group Microsoft
Why are we even discussing Active Directory? “Is there a session on running NOTEPAD. EXE in Windows Azure, too? ” Vernacular (no, there isn’t) … terminology specific to Windows Azure that will get us all on the same page Considerations for a cloud-deployment … optimal configuration knobs and deployment topologies
Why are we even discussing Active Directory? “Is there a session on running NOTEPAD. EXE in Windows Azure, too? ” Vernacular (no, there isn’t) … terminology specific to Windows Azure that will get us all on the same page Considerations for a cloud-deployment … optimal configuration knobs and deployment topologies
Objectives Why are we even discussing Active Directory? IMPLICATION: “there’s something specific to its deployment in Azure” Vernacular … terminology specific to Windows Azure that will get us all on the same page Considerations for a cloud-deployment … optimal configuration knobs and deployment topologies
Objectives Why are we even discussing Active Directory? IMPLICATION: “there’s something specific to its deployment in Azure” Vernacular … terminology specific to Windows Azure that will get us all on the same page Considerations for a cloud-deployment … optimal configuration knobs and deployment topologies
see http: //www. windowsazure. com/en-us/home/features/identity/
Objectives Why are we even discussing Active Directory? IMPLICATION: “there’s something specific to its deployment in Azure” Vernacular … terminology specific to Windows Azure that will get us all on the same page Considerations for a cloud-deployment … optimal configuration knobs and deployment topologies
Deploy DC in Separate Cloud Service ADVNET Cloud Service for AD Domains Cloud Service for AD Clients Location: North Central US Name: ad-cloudservice. cloudapp. net Affinity Group: ADAG Location: North Central US Name: app-cloudservice. cloudapp. net Affinity Group: ADAG Deployment Virtual Network: ADVNET DNS Ips: (On-Premise AD IP) Virtual Machine Role Name: ad-dc Subnet: ADSubnet IP Address: 192. 168. 1. 4 Deployment DIP Virtual Network: My. VNET DNS Ips: 192. 168. 1. 4 Virtual Machine Role Name: advm 1 Subnet: App. Subnet IP Address: 192. 168. 2. 4
Contoso. com Active Directory Site to Site VPN Tunnel AD Authentication + On-Premises Resources Load Balancer Public IP
Contoso. com Active Directory Site to Site VPN Tunnel AD Authentication + On-Premises Resources AD Auth Load Balancer Public IP
DC 2 Timeline of events DC 1 TIME: T 1 Create Snapshot USN: 100 ID: A RID Pool: 500 - 1000 +100 users added TIME: T 2 USN rollback NOT detected: only 50 users converge across the two DCs 200 on one or the other DC All others. USN: are either DC 2 receives updates: USNs >100 RID Pool: 600 ID: Aprincipals 100 security (users in 1000 this example) with RIDs 500 -599 have conflicting SIDs DC 1(A) @USN = 200 TIME: T 3 T 1 Snapshot USN: 100 Applied! ID: A RID Pool: 500 - 1000 +150 more users created TIME: T 4 USN: 250 ID: A RID Pool: 650 - 1000 DC 2 receives updates: USNs >200 DC 1(A) @USN = 250
Windows Azure Asia US Windows Azure Virtual Networks HQ CORP
Questions? Thank you samueld@microsoft. com
