Shuffling by semirandom transpositions Elchanan Mossel U C

Shuffling by semi-random transpositions Elchanan Mossel, U. C. Berkeley Joint work with Yuval Peres and Alistair Sinclair

Shuffling by random transpositions • At each step choose two independent uniformly chosen cards and exchange them. A 2 3 4 5 6 7 8 A 6 3 4 5 2 7 8

Shuffling by random transpositions Thm[Diaconis-Shahshahani-81]: The mixing time of the random transpositions shuffle is (½ + o(1)) n log n. • One can prove an O(n log n) upper bound can using “marking” (more later). • Proof of an (n log n) lower bound: • At each step “touch” 2 random cards. • Until time (n log n)/4 there are (n 1/2) untouched cards • ) permutation is not random.

The cyclic to random shuffle • At step i exchange card at location (i mod n) with a uniformly chosen card. A 2 3 4 5 6 7 8

History of the cyclic to random shuffle • Shuffle introduced by Thorp (65). • Aldous and Diaconis (86) asked what is the mixing time? • Mironov posed again and proved O(n log n) upper bound using marking.

Why do we care? • General question: Is systematic scan faster than random update? (other examples: Diaconis-Ram ; Benjamini-Berger. Hoffman-M for asymmetric exclusion; Gaussian fields etc. ). • Would be nice to find a “natural problem” where the mixing time is strictly between (n) and (n log n) • Mironov: Cyclic to random may tell us a lot about a widely used crypto algorithm RC 4.

More than 106 hits in google The RC 4 algorithm • Mironov: Let’s study algorithm assuming j is random. • Slow mixing corresponds to weak crypto.

Upper Bounds - Broder’s Marking • Broder’s Marking argument: • Call the two pointers Lt and Rt. • Start by marking the first card that is pointed by L 1. • At time t, mark card pointed by Lt if either: • The card at Rt is marked or • R t = L t.

Broder’s Marking A 2 3 4 5 R A 6 6 7 8 L 3 4 5 2 R=L A 6 3 4 5 2 7 8

Broder’s marking • By induction: Given the time and • set of marked cards and • their positions, • the permutation on the marked cards is uniform. • ) The time when all cards are marked is a strong uniform time (permutation is random given the time). • In order to prove upper bound, need to bound the “marking time”. • For random transpositions easy: By coupon collector estimate this time is O(n log n). • Mironov: delicate analysis for cyclic to random.

A general n log n upper bound • Thm: [M-Peres-Sinclair] An O(n log n) upper bound on the mixing time holds for any shuffle where: • At step t we exchange cards Lt and Rt where • Rt are i. i. d. uniform in {0, …, n-1}. • The sequence Lt is independent of Rt. • Lt can be random, deterministic etc. • Cyclic to random is given by Lt = t mod n. • Top to random is given by Lt = 0 for all n. • Random transpositions is given by Lt i. i. d uniform. • Pf: Careful analysis of the marking process.

A general n log n upper bound • Proof In more detail: • May assume that Lt is deterministic. • Partition time into intervals of length 2 n. • In such an interval look at pairs of times s < t such that Ls = Lt (there at least n such pairs). • We can mark card x if: • at time s, x is chosen by Rs. • Rr Lt for s < r < t. • Rt is one of the marked cards. • Letting mi (ui) be the (un)-marked card at interval i, gives • E[ui+1 | Fi] · ui (1 – c mi) for c > 0. • Will skip the rest of the proof. Rs Ls x Lt x Rt

Cyclic to random shuffle – lower bound? • Mironov proved c n lower bound for some c > 1 using parity as a test function: • Each shuffle changes the parity with probability (1 – 1/n). • After t steps, resulting parity = original parity with probability: • Q: Is next to random faster than random transpositions? • Note: All cards are touched by time n.

n log n lower bound for cyclic to random shuffle • Thm[M-Peres-Sinclair]: The cyclic to random shuffle has a mixing time (n log n). More precisely: • And here is how the proof goes:

Step 1: Homogenizing the chain • Problem: The chain is not time homogenous. • Can be easily fixed: Consider a chain where at time t: • (0) swaped with (U), where U is uniform. • Rotate all cards to the left: ’(k) = (k+1 mod n). • Clearly chain is equivalent + • It is homogenous. • From now on study homogenized chain.

One card chain Markov chain for a single card: • Eigenvalues satisfy = (1 – 1/n) where • (n-1) n – n n-1 + 1 = 0. • Want to show slow mixing ) want close to 1.

Asymptotics of eigen values and functions • = (1 – 1/n) where (n-1) n – n n-1 + 1 = 0. • Let -1 = 1 + z/n and get • (1+z/n)n – n (1+z/n) + (n-1) = 0 ! ez – 1 = 0. • Lemma 1: ez – 1 has non-zero complex roots. • Lemma 2: If is a root, then M has an eigenvalue such that 1 -| | = (1+< )/n + O(1/n 2). • Lemma 3: The eigenvector f corresponding to is “smooth”: |f|1 · C |f|2. Will write |f| for either. • Pfs: Complex analysis … • Remark: Numerically, the smallest non-zero root is = 2. 088… + 7. 416… i

The test function • Take f to be an eigenfunction of M corresponding to the eigenvalue closest to 1. • Define the test function F • Easy: E[f] = 0 ) E[F] = 0. • Easy: E[F(idt)] = t |f|2. • A Longer calculation gives: E(F 2) = |f|4/n E(F) = 0 E(F(idt)) = t |f|2

Proof of main Lemma • The main lemma can be proved using Wilson’s method and the properties of and f. • Or it can be done more directly using coupling: • Lemma:

Proof of main Lemma • Pf idea: “Couple” the following two processes: • Process 1: cards i and j move independently. • Process 2: The location of cards i and j in the real process. • In process 1: • Remains to bound the difference between the processes using coupling. • Will skip the details …

Conclusion and Open problems • We’ve seen that the mixing time of the pseudo-random next to random shuffle has the same mixing time as the random transposition shuffle. • Proof is not that hard. • Problem: How general is the phenomenon? • In particular: • Open problem: Are there any sequences (deterministic/random) It, such that the It to random shuffle mixes in less than n log n time?
