Separators in the Oil and Gas Industry PTRT

Separators in the Oil and Gas Industry PTRT xxxx Chapter xx Source: xx 1

Separators in the Oil and Gas Industry Functional Descriptions of Separators for O&G • • x An oil/gas separator is a pressure vessel used for separating a well stream into gaseous and liquid components and applicable on shore and offshore Based on the vessel configurations, the oil/gas separators can be divided into horizontal, vertical, or spherical separators In terms of fluids to be separated, the oil/gas separators can be grouped into gas/liquid two-phase separator or oil/gas/water three-phase separator Based on separation function, the oil/gas separators can also classified into primary phase separator, test separator, high-pressure separator, low-pressure separator, deliquilizer, degasser, etc. Source: Petrowiki 2

Separators in the Oil and Gas Industry Functional Descriptions of Separators for O&G • • To meet process requirements, the oil/gas separators are normally designed in stages, in which the first stage separator is used for preliminary phase separation, while the second and third stage separator are applied for further treatment of each individual phase (gas, oil and water) Depending on a specific application, oil/gas separators are also called deliquilizer or degasser The deliquilizers are used to remove dispersed droplets from a bulk gas stream Degassers are designed to remove contamined gas bubbles from the bulk liquid stream x Source: Petrowiki 3

Separators in the Oil and Gas Industry Separator Components • An oil/gas separator generally consists of following components x Source: Petrowiki - inlet device located in pre-separation zone/section for preliminary phase separation - baffles downstream the inlet component to improve flow - separation enhancement device in the primary separation (gravity settling) section for major phase separation - mist extraction device located in gas space to further reduce liquid content in the bulk gas stream - various weirs to control the liquid level or interface level - vortex breaker to prevent gas carryunder at outlet of liquid phase - liquid level/interface detection and control, etc. - gas, oil, water outlet - pressure relief devices 4

Separators in the Oil and Gas Industry Separator Components • • In most oil/gas processing systems, the oil/gas separator is the first vessel the well stream flows through after it leaves the producing well However, other equipment such as heaters may be installed upstream of the separator. x x x Source: Petrowiki 5

Separators in the Oil and Gas Industry Functions of a Separator • • • The primary functions of an oil/gas separator, along with separation methods, are summarized in table x x x Source: Petrowiki 6

Separators in the Oil and Gas Industry Requirements of Separators • • • Separators are required to provide oil/gas streams that meet saleable pipeline specification as well as disposal Oil must have less than 1% (by volume) water and less than 5 lbm water/MMscf gas Water stream must have less than 20 ppm oil for overboard discharge in the Gulf of Mexico (GOM). x x x Source: Petrowiki 7

Separators in the Oil and Gas Industry Separator Depressurization • • Stage recovery of liquid hydrocarbons - Staged separation (depressurization) - to maximize the liquid hydrocarbon volumes from the figure on the next slide shows a typical deepwater GOM (Gulf of Mexico) process train There are four stages of depressurization • Terms/acronyms to remember - high pressure (HP) - intermediate pressure (IP) - free water knockout (FWKO) - the degasser/bulk oil treater (BOT) combination x Source: Petrowiki - GOM - BOT - FWKO - FGC - VRU Gulf of Mexico bulk oil treater free water knock out 8

Separators in the Oil and Gas Industry GOM Process Train Typical GOM production separation train consisting of HP, IP, FWKO, degasser, and BOT (courtesy of CDS Separation Technologies Inc. ) 9 Source: Petrowiki

Separators in the Oil and Gas Industry Bulk Water Removal • • x • Bulk water is removed in the third stage, FWKO, and final dewatering is accomplished in the BOT In the North Sea and other locations, water may be removed in the HP and/or IP vessels The BOT is typically an electrostatic treater. Sometimes, the BOT will include a degassing section, eliminating the need for a separate degasser vessel Typical deepwater GOM platform pressures for degasser stages are: - 1, 500 psig for HP - 700 psig for IP - 250 psig for IP - 50 psig for FWKO x Source: Petrowiki 10

Separators in the Oil and Gas Industry Metering • Metering is performed for • • x - protection of pumps and compressors - booster compressor unit x x Source: Petrowiki 11

Separators in the Oil and Gas Industry Three-stage Compressor Train Typical three-stage compressor train (courtesy of CDS Separation Technologies Inc. ). Source: Petrowiki 12

Separators in the Oil and Gas Industry Glycol Dehydration • • • F The glycol dehydration unit. Both systems make use of separators as a major component in their design. x x 13

Separators in the Oil and Gas Industry Glycol Dehydration System Figure showing typical glycol dehydration system (Courtesy of CDS Separation Technologies Inc. ) 14

Separators in the Oil and Gas Industry Vertical vs. Horizontal Separators x 15

Separators in the Oil and Gas Industry Design Considerations • • x The oil/gas separators are typically sized by the settling theory or retention time for the liquid phase To handle the liquid surges or production fluctuation frequently encountered during oil/gas production, it is a common practice to size the oil/gas separators with a sufficient margin. x x 16

Separators in the Oil and Gas Industry Design Considerations • • x The separator is generally divided into the following functional zones - inlet zone - flow distribution zone - gravity separation/coalescing zone - outlet zone Each zone has to be carefully designed to achieve the designated overall separation performance. x x 17

Separators in the Oil and Gas Industry Separator Inlet Zone • • • x Appropriate inlet device is needed to obtain an initial bulk separation of liquid/gas In most cases, gas will have already come out of solution in the pipeline, leading to the separator (because of pressure drop across an upstream choke or a control valve) Hence, the majority of the gas is separated from the liquid in the inlet zone x x 18

Separators in the Oil and Gas Industry Separator Inlet Zone • • Because of foaming issues and the need for higher capacities, cyclonic inlets are now becoming increasingly popular For applications with inlet momentum saying less than 9 k. Pa, a vane inlet can be used Typical inlets include: • x - flat impact plates - dished-head plates - half-open pipes - vane-type inlet - cyclone-cluster inlet 19

Separators in the Oil and Gas Industry Separator Inlet Zone • • x These inlets, although inexpensive, may negatively affecting separation performance especially for highermomentum fluids The flat or dished-head plates can result in small drops and foam. The open-pipe designs can lead to fluid short-circuiting or channeling Although inlet momentum is a good starting guideline for selection, the process conditions, as well as the demister choice, should also be considered For example, if the liquid loading is low enough that a demister can handle all the liquid, then inlet devices can be applied beyond their typical momentum ranges 20

Separators in the Oil and Gas Industry Flow Distribution Zone • x Regardless of the size of the vessel, short-circuiting can result in poor separation efficiency. Integral to any inlet device is a flow straightener such as a single perforated baffle plate. A full-diameter plate allows the gas/liquid to flow more uniformly after leaving the vane-type inlet, inlet cyclones, or even the impact plates. The plate also acts as an impingement demister and foam breaker as well. Typical net-free area (NFA) ranges in the 10 to 50% range. As the NFA lowers, the shear of the fluids gets higher, so the NFA should be matched to the particular application. One concern of these plates is solids buildup on the upstream side. Generally, the velocities are high enough in the inlet zone to carry the solids through the perforations. In any case, a flush nozzle should be installed in the inlet zone. Other designs include flow straightening vanes. However, the open area is generally too high to be effective. 21

Separators in the Oil and Gas Industry Gravity / Coalescing Zone • To assist in separation (and foam breaking), mesh pad, vane pack, and/or plate/matrix packs are sometimes introduced in the gas/liquid separator. These internals provide more impingement or shearing surfaces to enhance coalescing effect of the dispersed phase. For the gas phase, matrix/plate packs and vanes have been used to aid in liquid drop coalescence or foam breaking. The theory behind installing the high surface internals such as plate packs for foam breaking is that the bubbles will stretch and break as they are dragged along the surfaces. However, if most of the gas flows through the top portion of the pack, the foamy layer will not be sufficiently sheared, and the bubbles will meander through to the other end. • x • x x 22

Separators in the Oil and Gas Industry Outlet Zone • Mist capture can occur by three mechanisms; it should be kept in mind that there are no sharply defined limits between mechanisms. As the momentum of a droplet varies directly with liquid density and the cube of the diameter, heavier or larger particles tend to resist following the streamline of a flowing gas and will strike objects placed in their line of travel. This is inertial impaction, the mechanism responsible for removing most particles of diameter > 10 μm. Smaller particles that follow the streamlines may collide with the solid objects, if their distance of approach is less than their radius. This is direct impaction. It is often the governing mechanism for droplets in the 1 - to 10 -μm range. With submicron mists, Brownian capture becomes the dominant collection mechanism. This depends on Brownian motion—the continuous random motion of droplets in elastic collision with gas molecules. As the particles become smaller x and the velocity gets lower, the Brownian capture becomes more 23

Separators in the Oil and Gas Industry Separator Performance • Separation performance can be evaluaed by liquid carrying over and gas carrying down rates, which are affected by many factors, such as: • Flow rates • Fluid properties • Vessel configuration • Internals • Control system • ETC. • The gas capacity of most gas/liquid separation vessel is sized on the basis of removing a certain size of liquid droplets. The main x unknown is the incoming drop-size distribution. Without this, the 24

Separators in the Oil and Gas Industry x • x. Vessel Internals • It is evidenced that tvessel internals could significantly affect the operating performance of an oil/gas separator through the following ways: • Flow distribution • Drop/bubble shearing and coalescence • Foam creation • Mixing • Level control x • x 25

Separators in the Oil and Gas Industry x • x. Performance impediments • Foaming • When pressure is reduced on certain types of crude oil, tiny bubbles of gas are encased in a thin film of oil when the gas comes out of solution. This may result in foam, or froth, being dispersed in the oil and creates what is known as “foaming” oil. In other types of crude oil, the viscosity and surface tension of the oil may mechanically lock gas in the oil and can cause an effect similar to foam. Oil foam is not stable or long-lasting unless a foaming agent is present in the oil. • Whether crude oil is foamy is not well known. The presence of a x surface active agent and process conditions play a part. The literature 26

Separators in the Oil and Gas Industry x • x. The main factors that assist in “breaking” foaming oil are: • Settling • Agitation (baffling) • Heat • Chemicals • Centrifugal force • These factors or methods of “reducing” or “breaking” foaming oil are also used to remove entrained gas from oil. Many different designs of separators for handling foaming crude oil have evolved. They are available from various manufacturers—some as standard x foam handling units and some designed especially for a specific 27

Separators in the Oil and Gas Industry x • x. Fig. 4 is a gamma ray scan of a 48 -in. -diameter horizontal gas separator showing the problems resulting from foam. The horizontal axis is signal strength, and the vertical axis is height within the separator. High signal strength indicates less mass or more gas. Less signal strength indicates more mass or liquid. As the chemical rate is decreased, the interface between gas/liquid becomes less defined. The bottom of the vessel becomes gassy (more signal), while the upper portion becomes foamy (less signal). Liquid carryover occurs as the foam is swept through the demister. Gas carry-under occurs as the bubbles cannot be separated. • Fig. 4—Example of gamma scan results (courtesy of CDS x 28 Separation Technologies Inc. ).

Separators in the Oil and Gas Industry x • • x x x x 29

Separators in the Oil and Gas Industry x • x. Fig. 5 shows a horizontal separator used to process foamy crudes. The fluids flow through inlet cyclones, where the centrifugal action helps break the large bubbles. A perforated plate downstream of the inlet cyclones aids in promoting uniform flow as well as demisting and defoaming. Demisting cyclones in the gas outlet remove large amounts of the liquid that results from a foamy oil layer. The foamy oil pad results from the small bubbles that cannot be removed in the inlet cyclones. • Fig. 5—Two-phase separator designed for foam breaking (courtesy of CDS Separation Technologies Inc. ). x 30

Separators in the Oil and Gas Industry x • • x x x x. Fig. 5—Two-phase separator designed for foam breaking 31

Separators in the Oil and Gas Industry x • • x • x x. In between the perforated plate and the demister, high-surface internals such as plate or matrix packs are sometimes installed to break the large bubbles. As previously discussed, theory behind the high-surface internals is that the bubbles will stretch and break as they are dragged along the surfaces. However, if most of the gas flows through the top portion of the pack, the foamy layer will not be sufficiently sheared, and the bubbles will meander through to the other end. x x 32

Separators in the Oil and Gas Industry x • x. Paraffin • Paraffin deposition in oil/gas separators reduces their efficiency and may render them inoperable by partially filling the vessel and/or blocking the mist extractor and fluid passages. Paraffin can be effectively removed from separators by use of steam or solvents. However, the best solution is to prevent initial deposition in the vessel by heat or chemical treatment of the fluid upstream of the separator. Another deterrent, successful in most instances, involves the coating of all internal surfaces of the separator with a plastic for which paraffin has little or no affinity. The weight of the paraffin causes it to slough off of the coated surface before it builds up to a x 33 harmful thickness.

Separators in the Oil and Gas Industry Solids and Salt Handling • x • x. Solids and salt • If sand other solids are continuously produced in appreciable quantities with well fluids, they should be removed before the fluids enter the pipelines. Salt may be removed by mixing water with the oil, and after the salt is dissolved, the water can be separated from the oil and drained from the system. • Vertical vessels are well suited for solids removal because of the small collection area. The vessel bottom can also be cone-shaped, with water jets to assist in the solids removal. In horizontal vessels, sand jets and suction nozzles are placed along the bottom of the x vessel, typically every 5 to 8 ft. Inverted troughs may be placed on 34 top of the suction nozzles as well to keep the nozzles from plugging.

Separators in the Oil and Gas Industry x • • x x x x. Fig. 6—Sand-jet system (courtesy of CDS Separation 35

Separators in the Oil and Gas Industry x • x • Corrosion • Produced well fluids can be very corrosive and cause early failure of equipment. The two most corrosive elements are hydrogen sulfide and carbon dioxide. These two gases may be present in the well fluids in quantities from a trace up to 40 to 50% of the gas by volume. A discussion of corrosion in pressure vessels is included in the page of water treating. • x x • x 36

Separators in the Oil and Gas Industry Sloshing • x • x. Sloshing • Because of the action of waves or ocean current on a floating structure, liquid contents in an oil/gas separator would be excited, which results in internal fluid sloshing motions. It is particularly a problem in long horizontal separators. Sloshing degrades the separation efficiency through additional mixing, resulting in liquid carry-over in the gas line, gas carry-under in the liquid line, and loss of level control. In three-phase separators, oil/water and gas/liquid separation efficiency is degraded. It is therefore necessary to design internal baffle systems to limit sloshing. Emphasis is generally placed on internals for wave dampening in gas-capped separators because of x 37 the larger fluid motions.

Separators in the Oil and Gas Industry x • • x • x x. Table 3 gives some estimates of the natural period of the liquid for vessels undergoing lengthwise motions (sway). The periods are in the order of 10 s, which is similar to the period found for floating platforms such as tension leg platforms (TLP) and floating production, storage and offloading (FPSO) vessels under a 10 -year storm condition. x x 38

Separators in the Oil and Gas Industry x • • x x x x 39

Separators in the Oil and Gas Industry x • x • The alignment of the separators with the structure motion should be considered when designing the layout. For example, on TLP, the vessels are recommended to be aligned with their long dimension, perpendicular to the TLP prevailing motion. On ships, the magnitude and period of the pitch and roll should be considered when aligning the vessels. Normally, it is recommended to align the separators with their long dimension along the length of the ship. • The available literature, as described by Roberts et al. [2], highlights x two main features of wave-damping internals: 40

Separators in the Oil and Gas Industry x • x. Shifting the natural frequency is usually accomplished by segmenting the vessel with transverse baffles. The baffles are perforated, can be placed throughout the liquid phase, or can be placed in the region of the oil/water interface. However the following are major concerns: • Vessel access • Solids collection • Mixing are major concerns • Horizontal perimeter baffles can be used, but they have disadvantages as well. Other baffle shapes include angled wings x along the length of the vessel to mitigate waves because of roll as 41

Separators in the Oil and Gas Industry x • • x x x x 42

Separators in the Oil and Gas Industry x • x. Level controls • Stable control of the oil/water and gas/oil interfaces is important for good separation. The typical two-phase separator level settings are shown in Table 5. For three-phase operation, level settings are placed on both the oil/water interface and oil/gas interface levels. • • x • x x x 43

Separators in the Oil and Gas Industry x • • x x x x 44

Separators in the Oil and Gas Industry x • x. Typically, the spacing between the different levels is at least 4 to 6 in. or a minimum of 10 to 20 seconds of retention time. The location of the lowest levels must also consider sand/solids settling. These levels are typically 6 to 12 in. from the vessel bottom. Minimum water/oil pad thicknesses are approximately 12 in. Note that these minimum settings may dominate the vessel sizing as opposed to the specified retention times. • In a two- or three-phase horizontal separator with very little liquid/water, a boot or “double-barrel” separator configuration is used. All the interface controls are then located within the boot or lower barrel. Examples of these types of separators can be seen at Separator x 45 types.

Separators in the Oil and Gas Industry x • • x x x x Nomenclature ρc = continuous phase density, kg/m 3; μc = continuous phase dynamic viscosity, kg/(m∙s) or N∙s/m 2; Vc = continuous phase velocity, m/s; dh = hydraulic diameter. Vr = drop/rise velocity, m/s; Vh = horizontal water velocity, m/s; L = plate-pack length, m; dpp = plate-pack perpendicular gap spacing, m. ρw = water density, kg/m 3; ρo = oil density, kg/m 3; μw = water dynamic viscosity, kg/(m∙s) or N∙s/m 2; g = gravitational acceleration, 9. 81 m/s 2; Do = drop diameter, m. Vm = design velocity, m/s; ρg = gas-phase density, kg/m 3; ρl = liquid-phase density, kg/m 3; K = mesh capacity factor, m/s 46

Separators in the Oil and Gas Industry x • x. References • ↑ Callaghan, I. C. , Mc. Kechnie, A. L. , Ray, J. E. et al. 1985. Identification of Crude Oil Components Responsible for Foaming. SPE J. 25 (2): 171– 175. SPE-12342 -PA. http: //dx. doi. org/10. 2118/12342 -PA. • ↑ Roberts, J. R. , Basurto, E. R. , and Chen, P. Y. 1966. Slosh Design Handbook I, NASA-CR-406, Contract No. NAS 8 -11111. Huntsville, Alabama: Northrop Space Laboratories. • x • x x 47
