Sensor Training Exhibition Fair Light Buildung 2010 Frankfurt
Sensor Training: Exhibition / Fair „Light & Buildung 2010“ Frankfurt / M. (Germany) 10. 04. 2010 Titel der Präsentation 2 Präsentationsdatu
New sensors: High-Frequency-Sensors: Infrared-Sensors: IS 3360 ECO HF LUM I IS 345 MX Highbay HF LUM II (Passiv-Sensor) (Heat detection sensor) (Active-sensor) Titel der Präsentation (Transmit and receive radiation) 3 Präsentationsdatu
Infrared sensor IS 3360 ECO („ECO“ for economic) Titel der Präsentation 4 Präsentationsdatu
Pictures of both sensors: The sensors IS 3360 and IS 3360 ECO have both the same design! You can´t see a difference from the outside! NEW IS 3360 ECO Titel der Präsentation 5 Präsentationsdatu
Coverage pattern diagrams: IS 3360 ECO IS 3360 Lense Movable! Titel der Präsentation 6 Präsentationsdatu
Technical Information „IS 3360“ und „IS 3360 ECO“: Cost-situation (old/new): „ECO“ is a little bit less expensive (appr. 10 %) Info: ECO without potential-free contact ! Colour: only white! Switching capacity: 2000 W / 10 ax Availability: in the Steinel stock! Amount/year: both the same Download owner manuals: www. steinel. de end: IS 3360 ECO Titel der Präsentation 7 Präsentationsdatu
New sensor: IS 345 MX Highbay: („MX“ for maximum, „Highbay“ for high warehouses…) Feature: - New and special lense (and a special design) - For precisian movement detection If very highly mounted. Titel der Präsentation 8 Präsentationsdatu
Difference between IS 345 and IS 345 MX Highbay : The lense: IS 345 MX Highbay IS 345 Titel der Präsentation 9 Präsentationsdatu
Coverage pattern diagrams: IS 345 MX Highbay IS 345 Tangential and radial detection! Very good radial detection, tangential with some gaps… Titel der Präsentation 10 Präsentationsdatu
Technical information „IS 345“ und „IS 345 MX Highbay“: IS 345 MX Highbay: - Lense not movable! IS 345 - Lense movable to adjust the coverage area! Advantage: - Special „High“-bay detection up to 12 m with a radial detection of 15 x 4 m both sides! - For universal application up to 3 m with a radial detection of 6 x 4 m both sides! - Tangential detection: Disadvantage: - Some gaps or holes in the tangential detection (because of the hight of max 12 m!) 20 x 4 m Both: Using and fitting the shrouds: same as IS 345! Titel der Präsentation 11 Präsentationsdatu
Further technical information „IS 345“ und „IS 345 MX Highbay“: Cost-situation: MX appr. 10% higher as IS 345 Setting options with pots: ->Twilight setting -> time setting Enclosure: IP 54 Switching capacity: 2000 W Temperature range: - 20°C to + 50°C or - 4°F to + 122°F Availability: in June 2010 end: IS 345 MX Highbay Titel der Präsentation 12 Präsentationsdatu
Two new sensors: High frequency sensor HF LUM 1 HF LUM 2 („LUM“ for lumen/lumina) Titel der Präsentation 13 Präsentationsdatu
New HF-Sensor for OEM´s: HF LUM I (high-frequency sensor with patch-antenna) HF LUM II (high-frequency sensor with aerial-antenna) HF-Technologie: - Permanent transmission of electro-magnetic signal with minimal output (1/1000 of a cell phone) - Reflection of moving object - Difficult distance determination Invisibly mounted into fixtures Titel der Präsentation 14 Präsentationsdatu
New sensor: HF-LUM 1: (with patch-antenna) Advantages: - Small measurements -Plug-in cabel connection (quickly mountable) - Especially for wall mounting - Individual design - Parts are available and in the Steinel stock! Titel der Präsentation 15 Präsentationsdatu
New sensor: HF LUM 2 HF-LUM 2: (with stick-antenna) Advantages: -Small measurements -Plug-in cabel connection (quickly mountable) - Especially for ceiling mounting - Individual design - Parts are available and in the Steinel stock! Titel der Präsentation 16 Präsentationsdatu
Coverage pattern diagram HF LUM II Ideal for detecting movement in front! (wall mounting) Ideal for detecting movement at the side! (ceiling mounting) Titel der Präsentation 17 Präsentationsdatu
Technical Information HF-LUM I and HF-LUM II: Cost-situation: Scaled pricing Info: Without potential-free contact ! Enclosure: IP 20 Colour: Only white! Switching capacity: 1000 W no more than 2 electronic ballasts (54 W each) Availability: Directly availability! Contact at Steinel: Mr Donald Schmilewski (OEM sales manager) Download owner manuals: www. steinel. de Titel der Präsentation 18 Präsentationsdatu
Samples for installation HF-LUM 1 and 2: HF-LUM 1 HF-LUM 2 In the fixtures at the end! Unvisible mounted! Titel der Präsentation Not between the bulbs/tubes! 19 Präsentationsdatu
Available flyer for HF-LUM I and HF-LUM II end: LUM 1+2 Titel der Präsentation 20 Präsentationsdatu
Thank you very much for your attention! Martin Kröger (Project-Manager) Titel der Präsentation 21 Präsentationsdatu
Titel der Präsentation 22 Präsentationsdatu
