Senior Design Project Office Building By Heath Yeager
Senior Design Project Office Building By: Heath Yeager ET – 494 Fall 2014 Instructor: Chris Koutsougeras Advisors: Mr. E. Rode and M. Zeidan
Objective • To design an office building that can be used by multiple companies
Location • Riverside Dr. and Nouveau Dr. , Metairie, LA 70003 • 78, 179. 89 sf. • 335’ x 215’
Survey of Land • • • Trees Low spots Apartment complex on left Future doctors office on right Another office building across the street
Zoning • • General Office 2 (GO-2) The purpose of this district is to create an environment especially suited to a group of professional, general administrative, and general sales offices, together with certain commercial uses primarily to service employees in the district. The district regulations are such as to protect adjacent commercial and residential uses. • • • Banks and homesteads Clinic, medical, dental, or chiropractic General and professional offices Laboratories, medical and dental Public utility structures Residential dwelling
Description • Size of Building: 155’ x 100’ • Basic Office Building • 3 Stories tall • Open floor plan – renters of space can determine the design • Glass façade
Elevations
Floor Plan - 1 st floor
Floor Plan - 2 nd and 3 rd floor
Soil Test • Kenner dirt, drained • Has multiple layers • Black to dark gray in color
Foundation • Concrete pilings • Pilings create more friction • Used in softer ground
Structural Plan
LRFD Calculations •
LRFD Calculations cont’d •
LRFD Calculations cont’d •
Other Plans
Estimation • Structure……………………………. $ 1, 691, 624. 16 • Walls/Ceiling…………………………. $ 38, 017. 10 • Electrical……………………………. $ 60, 289. 98 • Plumbing……………………………. $ 42, 293. 64 • HVAC………………………………. $ 47, 705. 57 • Miscellaneous…………………………$ 122, 945. 67 Grand Total: $2, 002, 876. 12
Schedule
Questions? ?
