반도체(SEMICONDUCTOR) 발광다이오드(LED - Light Emitting Diode) p-n diode → n-type 에 더 많은 전자를

반도체(SEMICONDUCTOR) 발광다이오드(LED - Light Emitting Diode) p-n diode → n-type 에 더 많은 전자를 다량 doping 전자(electron) → 양공(hole) 빛(light) – emitting!! 반도체 소자의 종류 p-type 과 n-type 의 에너지 준위차 → 빛의 색(color) 결정 Diamond(C) - UV Al. Ga. As – IR, red Zn. Se - green, blue In. Ga. N/Al. Ga. N/Ga. N – orange, yellow, green, blue, violet, UV Zn. Se – green, blue 특징 1. 작은 크기(small size) 2. 긴 수명 → 영상표시장치, 조명, LED 전광판, 신호등 etc.
